Product Overview
The Bently Nevada 330101-00-43-10-02-CN is a high-performance proximity probe from the 3300 XL 8mm series, engineered for precise, non-contact measurement / shaft vibration and position in rotating machinery. Widely adopted in the energy, petrochemical, and manufacturing sectors, this probe plays a critical role in real-time condition monitoring and machinery protection.
This specific model features a 1 meter total length, and includes configuration code “02” (typically referring to connector type and approvals). Designed for use in harsh industrial environments, the 3300 XL probes are known for their exceptional durability, high accuracy, and seamless integration with Bently Nevada’s monitoring systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル Number | 330101-00-43-10-02-CN |
| Series | Bently Nevada 3300 XL 8mm |
| Probe Tip Diameter | 8 mm |
| Sensing Range | 2 mm (80 mils), with linear output over 200 mils |
| Total Length | 1 meter |
| Connector Type | ClickLoc™ with “02” configuration (varies per region/approval) |
| Target Material | Ferromagnetic (commonly 4140 steel) |
| Output Signal | -200 mV/mil (-7.87 mV/µm) ±5% |
| Thread Type | 1/4-28 UNF or M8x1 (thread length as per configuration) |
| Mounting Method | Threaded into brackets or direct to machine housing |
| Operating Temperature | -35°C to +177°C |
| Storage Temperature | -51°C to +177°C |
| Frequency Response | DC to 10 kHz |
| Environmental Rating | IP68 / NEMA 6P |
| Compliance | CE, RoHS, ATEX (CN code indicates China-specific compliance) |
| 重量 | 0.323 kg |
Product Applications
The 330101-00-43-10-02-CN proximity probe is designed for deployment in a wide range / industrial applications:
-
Gas and Steam Turbines
Detects shaft movement and vibrational anomalies to protect rotor dynamics. -
Compressors and Expanders
Ensures early detection / imbalance, misalignment, or shaft rub. -
Electric Generators and Motors
Used for shaft positioning, displacement monitoring, and predictive maintenance. -
Industrial Pumps
Helps prevent unplanned failures by tracking bearing and shaft condition. -
Refining & Petrochemical Plants
Core component / vibration monitoring systems integrated with DCS/SCADA. -
Mining and Metal Processing Equipment
Monitors large rotating equipment where continuous performance is essential.
Product Advantages
-
Exceptional Reliability
Proven durability even in corrosive, high-temperature, or submerged environments. -
Factory-Calibrated System Matching
Probe, extension cable, and Proximitor® are matched to ensure linearity and accuracy. -
IP68 Protection Rating
Suitable for use in environments with oil, dust, moisture, or underwater applications. -
Color-Coded ClickLoc™ Connectors
Ensures secure connection, minimizes human error during installation. -
Broad Industrial Compatibility
Integrates easily with Bently Nevada 3500 Series, System 1®, and other monitoring platforms. -
Simplified Maintenance
Long service life and modular cable system reduce maintenance complexity and cost.
よくある質問 (FAQ)
-
Is the 330101-00-43-10-02-CN probe pre-calibrated?
Yes, it’s factory-matched and calibrated as a system with its extension cable and Proximitor® sensor. -
Can this model be used in applications with chemical exposure?
Yes, the stainless steel housing and sealed connector system make it resistant to most industrial chemicals. -
What is the recommended torque for installation?
For the 1/4-28 thread, use around 1.5–2.0 N·m (13–18 in-lb) to avoid over-tightening. -
What is the “CN” suffix in the part number?
It typically indicates compliance with Chinese regulatory and certification standards. -
Does the cable length impact accuracy?
Yes, the probe and extension cable must be used together as specified. Mixing lengths can distort calibration. -
Is this probe hot-swappable?
番号 Always shut down monitoring systems before disconnecting the probe to prevent signal error or system faults. -
How can I verify proper probe gap during installation?
Use a micrometer tool or feeler gauge and check for the standard -8 VDC output at the desired gap (usually 2 mm). -
Can I cut or modify the probe cable?
No, cables are pre-terminated and matched. Modifying length or connectors voids calibration and may damage the system. -
What should I do if the probe output voltage is unstable?
Check cable integrity, grounding, and ensure the probe is securely mounted and aimed at a clean, ferrous target surface. -
Is this product compatible with wireless vibration transmitters?
Not directly. It’s designed for wired Proximitor® systems, but data can be fed into wireless transmitters via compatible interfaces.
Related モデルs – Same Series (3300 XL 8mm)
| モデル Number | 説明 | Key Feature |
|---|---|---|
| 330101-00-40-10-01-00 | 40″ probe, 10′ cable, standard configuration | Popular all-purpose configuration |
| 330101-00-20-10-01-00 | 20″ probe, 10′ cable | Shorter probe cable for compact installations |
| 330101-00-60-10-02-00 | 60″ probe, 10′ cable, alternative connector | Extended cable length for large machines |
| 330103-00-40-10-01-00 | 5mm probe variant | For applications with space constraints |
| 330105-02-12-10-02-00 | High-temperature probe | For >200°C environments |
| 330106-05-30-10-02-00 | Armored cable variant | Extra protection in abrasive or harsh conditions |
Popular Bently Nevada モデルs
| モデル Number | Product Type | Application |
|---|---|---|
| 3500/42M | Proximitor Monitor | Monitors proximity probe inputs |
| 3500/22M | Transient Data Interface | High-speed dynamic data acquisition |
| 330104-00-05-10-02-00 | Reverse Mount Probe | Applications with reverse installation access |
| 330180-91-05 | Velomitor Piezo Velocity Sensor | Monitors casing vibration |
| 3500/32M | 4-Channel Relay Module | Alarms and shutdown functions |
| 3701/55 | TSI (Turbine Supervisory Instrumentation) | Real-time turbine condition monitoring |
