製品紹介
The Bently Nevada RTD/Isolated Tip TC External Termination Block (モデル: 172115-01) is an industrial signal termination device designed for temperature measurement systems using RTD (Resistance Temperature Detector) and thermocouple (TC) inputs. It provides a secure and electrically stable interface point for connecting field sensors to monitoring or control systems.
This termination block is commonly used in machinery protection and condition monitoring applications where accurate temperature data is required for equipment health assessment. By isolating and organizing signal connections, it reduces wiring errors and improves system reliability in complex industrial environments.
Designed for field installation, the 台 /fers robust protection against vibration, electrical noise, and harsh environmental conditions. It is widely applied in turbines, compressors, pumps, and process plants where temperature monitoring is critical for safe operation.
製品仕様
| Parameter | Value |
|---|---|
| Product Type | RTD / Thermocouple Termination Block |
| モデル Number | 172115-01 |
| Function | External signal termination for temperature sensors |
| Input Types | RTD, Thermocouple (Isolated Tip) |
| System Compatibility | Bently Nevada monitoring systems |
| Connection Type | Field wiring terminal block |
| Electrical Isolation | Isolated signal design |
| Mounting Type | Panel or enclosure mounting |
| Application Area | Industrial temperature monitoring systems |
| Environmental Resistance | Industrial vibration and EMI resistant |
| Wiring Interface | Multi-channel terminal connections |
| Dimensions | 150 × 100 × 50 mm |
| 重量 | 0.8 kg |
Applications
• Turbine temperature monitoring
Provides stable termination for bearing and casing temperature sensors, ensuring accurate thermal protection.
• Compressor systems
サポートs reliable connection / RTD and TC sensors for overheat detection and performance monitoring.
• Pump monitoring applications
Enables continuous temperature feedback for bearing condition and lubrication system health.
• Industrial process plants
Used for organizing and isolating temperature signal wiring in complex control systems.
• Power generation systems
Ensures accurate temperature data collection for safe and efficient equipment operation.
Advantages
• Stable signal termination
Provides secure and organized connection points for RTD and thermocouple signals.
• Electrical isolation design
Reduces interference and improves measurement accuracy in noisy industrial environments.
• Improved wiring organization
Simplifies field wiring layout, reducing installation errors and maintenance complexity.
• Robust industrial construction
Designed to withstand vibration, temperature variation, and harsh environments.
• High system reliability
Ensures consistent temperature data transmission for critical machinery protection systems.
• Flexible installation
Suitable for panel or enclosure mounting in various industrial configurations.
