The Bently Nevada 122M3369-01 Rack Mount is a specialized mounting solution designed for securely integrating a 10-inch Advantech industrial display into a 94M rack system. It provides a stable platform for power and signal connections while maintaining the neat, modular layout / Bently Nevada’s condition monitoring racks. Built for rugged industrial environments, this rack mount features robust construction to resist vibration, electrical noise, and mechanical stress. It simplifies installation and service while ensuring reliable display performance for continuous machinery protection and monitoring.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル Number | Bently Nevada 122M3369-01 |
| Compatible Display | 10-inch Advantech industrial touch display |
| Rack Style | 94M standard rack mount |
| Power Interface | 24 VDC input routed to display |
| Signal Interface | Video, serial, and control cabling |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +80 °C |
| Humidity Range | 0–95% non-condensing |
| Electrical Protection | EMI shielding, surge suppression |
| Front Protection | IP54 typical |
| Dimensions (W × H × D) | 387.4 x 248.9 x 49.0 mm |
| 重量 | 4 kg |
| Certifications | CE, UL compliant |
| Maintenance | Front-access design for easy service |
Applications
-
Machinery Health Monitoring: Houses the display for vibration and condition monitoring data.
-
Industrial Control Cabinets: Provides a human–machine interface in rack-based control systems.
-
Power Generation Facilities: Integrates with turbine or generator monitoring racks.
-
Oil & Gas Installations: Enables local display within substation or /fshore rack systems.
-
Process Automation: Embeds a 10-inch display in modular automation racks.
-
Retr/it Projects: Upgrades legacy Bently Nevada racks to modern display capability.
Product Advantages
-
Exact 94M Compatibility for effortless installation into existing rack frameworks.
-
Reliable Signal Routing with shielded internal cabling to preserve video and data quality.
-
Rugged Construction to withstand vibration, shock, and harsh plant conditions.
-
EMI Protection ensuring stable operation in electrically noisy environments.
-
Quick Service Access from the front panel without disturbing other rack components.
-
Standardized Dimensions for easy integration with other Bently Nevada modules.
-
Thermal Resilience for operation across wide temperature ranges.
-
Efficient Power Delivery with built-in surge suppression and grounding.
FAQ
-
Which display models are supported?
Specifically designed for a 10-inch Advantech industrial display in a 94M rack. -
What signals are routed through the mount?
Video, serial, control, and 24 VDC power connections pass through the rack interface. -
Is there built-in EMI filtering?
Yes, shielding and filters protect sensitive signals from interference. -
Can it be serviced without removing the rack?
Yes, the front-access design allows easy installation and maintenance. -
What is the recommended operating temperature?
The rack mount operates reliably from –20 °C to +60 °C. -
Does it provide surge protection?
Integrated surge suppression safeguards the display’s power input. -
Is it compatible with standard 19-inch rack dimensions?
Yes, it follows the 94M form factor fitting a standard 19-inch width. -
Will vibration affect performance?
The rugged construction ensures stable operation under industrial vibration. -
Can the rack mount handle high humidity?
Yes, up to 95% non-condensing humidity is supported. -
Is the module certified for industrial use?
It meets CE and UL requirements for industrial environments.
Recommended Related モデルs (Same Series or Similar)
| モデル Number | 説明 | Key Feature |
|---|---|---|
| 122M3369-02 | Rack mount for 12-inch display | Larger screen support |
| 122M3368-01 | Rack mount for 8-inch display | Compact installation |
| 122M3370-01 | Rack mount with extended EMI shielding | Extra interference protection |
| 122M3371-01 | Dual-display rack mount | Two displays side-by-side |
| 122M3372-01 | Rack mount with integrated cooling | Enhanced thermal management |
| 122M3373-01 | Modular blank rack panel with expansion option | Future upgrade flexibility |
Popular Bently Nevada モデルs (Same ブランド)
| モデル Number | 説明 | Application Area |
|---|---|---|
| 3500/94M | VGA display & communication module | Rack-mounted monitoring |
| 3500/22M | Machinery protection monitoring module | Vibration & condition data acquisition |
| 3300 XL | Proximity & vibration sensor series | Rotating equipment measurement |
| 3500/42M | Dynamic vibration monitoring module | High-speed machinery diagnostics |
| 2201 | Data acquisition and processing 台 | Centralized condition monitoring |
| 990 VOT | Vibration & overspeed transmitter | Turbomachinery safety monitoring |
