The Allen-Bradley MPL-B4560F-SJ72AA Servo Motor is a high-performance motion control component engineered for precision, reliability, and dynamic response in industrial automation systems. As part / the MP-Series from Allen-Bradley, and developed by Rockwell Automation, this servo motor is optimized for demanding applications requiring accurate positioning, high torque output, and stable operation.
With a 130 mm frame size and robust mechanical construction, this motor is suitable for high-inertia loads and continuous-duty operations. It integrates an absolute single-turn encoder using the Hiperface protocol, ensuring precise feedback and reliable performance in closed-loop control systems. The motor is designed for seamless compatibility with Rockwell Automation motion control platforms, delivering efficient and consistent motion performance.
製品仕様
| Parameter | Value |
|---|---|
| モデル | MPL-B4560F-SJ72AA |
| Product Type | Servo Motor |
| Series | MP-Series |
| Frame Size | 130 mm |
| Rated Speed | 3000 rpm |
| Nominal Torque | 34.4 Nm |
| Continuous Torque | 14.1 Nm |
| Magnet Stack Length | 152.4 mm |
| Encoder Type | Absolute Single-turn (Hiperface Protocol) |
| Encoder Resolution | 1024 Sin/Cos |
| Shaft Type | Keyed Shaft |
| Shaft Seal | Not Included |
| Connector Type | Circular (SpeedTec) DIN Connector |
| Brake | No Brake |
| Shock Acceleration (Max) | 20 g |
| Vibration Frequency (Max) | 2000 Hz |
| Vibration Acceleration (Max) | 2.5 m/s² |
| 重量 | 11.82 kg |
Applications
• High-precision positioning systems — Suitable for CNC machinery, robotics, and automated assembly lines.
• Packaging and material handling — Provides smooth and accurate motion for conveyors, pick-and-place systems, and sorting equipment.
• Heavy-duty automation — Handles high-inertia loads with stable torque output.
• Continuous production environments — Designed for reliable long-term operation in manufacturing plants.
• Integrated motion control systems — Works seamlessly with Rockwell Automation controllers and drives.
Advantages
• High torque density — Delivers strong torque output within a compact 130 mm frame.
• Accurate feedback system — Absolute encoder with Hiperface protocol ensures precise positioning and eliminates homing requirements.
• Robust mechanical design — Withstands high shock and vibration conditions in industrial environments.
• Reliable high-speed performance — Stable operation at 3000 rpm for demanding applications.
• Flexible integration — Compatible with a wide range / motion control systems and industrial setups.
• Efficient connectivity — SpeedTec DIN connector allows quick and secure installation.
