製品紹介
The Allen-Bradley 1756-OB32 is a high-density ControlLogix DC output module designed to deliver reliable 12–24 VDC digital switching in demanding industrial automation systems. With thirty-two sourcing output channels in a single slot, this module is ideal for applications requiring large numbers / discrete outputs while maintaining compact panel design.
Engineered for integration within the ControlLogix platform, the 1756-OB32 communicates directly over the backplane and allows centralized control through Studio 5000. Its solid-state output design ensures fast switching performance and long operational stability when driving field devices such as relays, solenoids, contactors, and indicator lights.
The module supports a wide operating voltage range / 10–31.2 VDC, making it suitable for standard 24V DC industrial control systems. It is commonly deployed in manufacturing lines, material handling systems, packaging machinery, and process automation installations where high output density and stable switching performance are required.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル | 1756-OB32 |
| ブランド | Allen-Bradley |
| Series | ControlLogix |
| Module Type | DC Digital Output Module |
| Number / Outputs | 32 Outputs |
| Nominal Voltage | 12–24 VDC |
| Operating Voltage Range | 10–31.2 VDC |
| Output Type | 24V DC Sourcing |
| Continuous Current per Point | Approx. 0.5 A per channel |
| Backplane Current Draw | Approx. 300 mA @ 5.1V DC |
| Field Wiring Interface | 36-Pin Removable Terminal Block (RTB) |
| Isolation | Group-to-Backplane Isolation |
| Status Indicators | Individual Output Status LEDs |
| Dimensions | 144.5 × 34.6 × 130.18 mm |
| 重量 | 0.231 kg |
Applications
• High-density 24V DC output control in automated production environments
• Control / relays, solenoids, and contactor coils in machine automation
• Integration within material handling and conveyor systems
• Packaging, assembly, and robotic control applications
• Installations requiring compact design with large output capacity
Advantages
• Thirty-two outputs in a single slot, maximizing chassis space efficiency
• Wide 10–31.2 VDC operating range for flexible system compatibility
• Solid-state design for fast and reliable switching performance
• Clear LED status indicators per channel for simplified troubleshooting
• Seamless integration into ControlLogix distributed control architectures
• Suitable for large-scale automation systems requiring high output density
