The ABB UA D215 A102 3BHE026284R0102 PEC80 Converter Signal Interface is a specialized module designed for ABB PEC80 systems within industrial automation environments. This interface module provides accurate conversion and transmission / signals between field devices, sensors, and control systems, enabling seamless integration / analog and digital data streams into the PEC80 platform.
Engineered for industrial-grade reliability, the module features overvoltage protection, EMI shielding, and robust signal processing, ensuring stable performance even in environments with high electrical noise or fluctuations. Its design allows straightforward installation and integration into existing PEC80 control networks, supporting high-speed data acquisition, signal conversion, and real-time communication between control modules and peripheral devices.
The UA D215 A102 Converter Signal Interface is commonly employed in process automation, energy systems, and distributed control networks, serving as a critical component for accurate data handling and reliable signal routing.
Technical Specifications
| Parameter | 説明 |
|---|---|
| Product モデル | UA D215 A102 |
| 型番 | 3BHE026284R0102 |
| Module Type | PEC80 Converter Signal Interface |
| System Platform | ABB PEC80 / UA Series |
| Signal Type サポートed | Digital, Analog, and Pulse signals |
| Input Signal Range | 0–10 V / 4–20 mA (analog), TTL/CMOS (digital) |
| Output Signal Range | 0–10 V / 4–20 mA (analog), TTL/CMOS (digital) |
| Communication Interfaces | RS-485, RS-232, PEC bus |
| Power Supply Requirement | 24 VDC regulated input |
| Protection Features | Overvoltage, short-circuit, EMI protection |
| Diagnostics | LED indicators for power, signal status, and communication faults |
| Mounting Type | Rack-mounted or slot installation |
| Cooling Method | Passive convection |
| Operating Temperature Range | -20°C to +65°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5%–95% non-condensing |
| Material | FR4 PCB with conformal coating |
| Dimensions | 440 × 43 × 230 mm |
| 重量 | 0.4 kg |
| Certifications | CE, UL, RoHS compliant |
Product Applications
The ABB UA D215 A102 PEC80 Converter Signal Interface is suitable for applications requiring precise signal conversion and reliable communication:
-
Power Plants — Converts and interfaces signals from generators, turbines, and auxiliary systems.
-
Oil & Gas Automation — Interfaces field instrumentation and control devices for process monitoring.
-
Chemical Processing — Integrates analog and digital process signals into PEC80 control networks.
-
Water and Wastewater Treatment — Monitors pumps, sensors, and actuators with accurate signal translation.
-
Metals and Mining Industry — Handles input/output signals for heavy machinery and process monitoring.
-
Industrial Manufacturing — Ensures accurate signal routing and conversion for automated production lines.
Its robust design and real-time signal conversion capability make it ideal for critical control applications, reducing system latency and improving process efficiency.
Product Advantages
-
Versatile Signal Conversion
Handles both analog and digital signals, allowing flexible integration with PEC80 systems. -
High Signal Accuracy
Ensures precise conversion for critical process monitoring and control. -
Industrial Protection Features
Overvoltage and short-circuit protection, along with EMI shielding, ensure reliable operation. -
Real-Time Diagnostics
LED indicators provide immediate feedback on power, signal integrity, and communication status. -
Passive Cooling
Fanless design reduces maintenance and improves operational reliability. -
Easy Installation
サポートs rack or slot mounting for quick integration into control networks. -
Scalable Integration
Compatible with PEC80 modules for modular expansion / industrial automation systems. -
Durable Construction
Conformal coating and FR4 PCB ensure long-term durability in harsh industrial conditions.
FAQ
-
What is the main purpose / the UA D215 A102 module?
It converts and interfaces analog and digital signals between field devices and PEC80 control systems for accurate process monitoring. -
Which communication protocols are supported?
RS-485, RS-232, and PEC bus interfaces are supported for seamless system integration. -
What types / signals can this module handle?
It supports analog signals (0–10 V / 4–20 mA) and digital TTL/CMOS signals. -
Can it interface with multiple PEC80 modules simultaneously?
Yes, the module is designed for integration with multiple PEC80 system modules. -
Does it provide protection against electrical faults?
Yes, overvoltage, short-circuit, and EMI protection are built into the module. -
Is it suitable for industrial environments with electrical noise?
Yes, EMI shielding and robust design ensure reliable operation in noisy environments. -
Does it provide diagnostic indicators?
Yes, LED indicators display power, signal status, and communication faults in real-time. -
What is the required power supply for the module?
A regulated 24 VDC power supply is required. -
Is the module compatible with ABB UA automation systems?
Yes, it works with ABB UA series and PEC80 systems for modular control integration. -
Can it handle high-speed signal processing?
Yes, it supports real-time signal conversion and routing to ensure minimal latency.
Recommended Related モデルs (Same Series)
| モデル | 説明 | System | 重量 |
|---|---|---|---|
| UA D214 A101 3BHE026283R0101 | PEC80 Converter Interface | ABB PEC80 | 1.15 kg |
| UA D213 A102 3BHE026282R0102 | PEC80 Signal Module | ABB PEC80 | 1.12 kg |
| UA D212 A101 3BHE026281R0101 | PEC80 Input Interface | ABB PEC80 | 1.10 kg |
| UA D211 A102 3BHE026280R0102 | PEC80 Output Interface | ABB PEC80 | 1.08 kg |
| UA D210 A101 3BHE026279R0101 | PEC80 Analog Module | ABB PEC80 | 1.05 kg |
| UA D209 A102 3BHE026278R0102 | PEC80 Digital Module | ABB PEC80 | 1.07 kg |
Popular ABB モデルs (Same ブランド)
| モデル | 説明 | Product Type | 重量 |
|---|---|---|---|
| PM864AK01 3BSE018161R1 | Advanced CPU Controller | DCS Processor | 1.05 kg |
| PM866AK02 3BSE050198R1 | Redundant CPU Controller | DCS Controller | 1.10 kg |
| CI854AK01 3BSE025961R1 | PROFIBUS Communication Adapter | Communication Module | 0.75 kg |
| AI810 3BSE008516R1 | Analog Input Module | I/O Module | 0.65 kg |
| DI810 3BSE008508R1 | Digital Input Module | I/O Module | 0.60 kg |
| DO810 3BSE008510R1 | Digital Output Module | I/O Module | 0.62 kg |
