The ABB TY801K01 3BSE023607R1 Shunt Stick is a precision current measurement component designed for accurate current sensing and signal conditioning within industrial automation and control systems. This shunt device is engineered to convert electrical current into a proportional voltage signal, enabling monitoring, protection, and control functions in ABB distributed control systems and related power assemblies.
Manufactured with high-stability resistive materials and a compact structural format, the TY801K01 provides reliable low-voltage drop measurement while maintaining thermal stability and measurement consistency. It is commonly used in current detection circuits where precision and repeatability are critical for system feedback and diagnostic functions.
Designed for integration into ABB control racks and monitoring platforms, this shunt stick supports dependable signal acquisition under industrial operating conditions. Its compact footprint and lightweight construction allow for easy installation without imposing mechanical stress on surrounding components.
The TY801K01 reflects ABB’s industrial design philosophy—combining electrical precision, mechanical robustness, and long-term operational stability within demanding environments.
製品仕様
| Parameter | 説明 |
|---|---|
| Product Name | Shunt Stick |
| モデル | TY801K01 |
| 型番 | 3BSE023607R1 |
| メーカー | ABB |
| Rated Voltage | 50 V |
| Resistance Value | 125 / 125 OHMS |
| Measurement Principle | Precision Resistive Current Shunt |
| Signal Output Type | Proportional Voltage Drop |
| Material Type | High-Stability Resistive Alloy |
| Thermal Stability | Low Temperature Coefficient |
| Accuracy Class | Industrial Measurement Grade |
| Mounting Method | Direct Terminal Integration |
| Operating Temperature Range | -25°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Insulation Level | Industrial Insulated Structure |
| Protection Design | Mechanical Reinforced Housing |
| Dimensions | 62 × 11 × 15.5 mm |
| 重量 | 0.06 kg |
Applications
• Used in industrial control systems for accurate current measurement and monitoring
• Integrated within distributed control systems (DCS) to provide stable current feedback signals
• Applied in power monitoring circuits for low-voltage current sensing
• Suitable for protection relay systems requiring precise current detection
• Installed in automation cabinets where compact current measurement devices are needed
• Utilized in diagnostic and signal acquisition modules to enhance system supervision
Advantages
• Provides high measurement accuracy through stable resistive characteristics
• Ensures low temperature drift, maintaining consistent performance across varying environments
• Compact and lightweight design allows space-efficient integration
• Offers stable voltage output proportional to current, simplifying signal conditioning
• Industrial-grade materials enhance mechanical durability and electrical reliability
• サポートs precise monitoring and protection coordination in automation systems
• Designed for seamless compatibility within ABB control architectures
