The ABB SYN 5201a-Z, V2277 Synchronization Device (3BHB006714R2277) is a high-performance 台 designed to ensure precise and reliable synchronization between power generation 台s and the electrical grid. This device is engineered to maintain stable system frequency, voltage, and phase alignment, which is critical in both industrial and utility-scale power plants. The SYN 5201a-Z is suitable for integration into modern control systems, supporting both automated and manual synchronization operations.
The device is known for its robust design, fast response time, and compatibility with various generator types. It provides clear monitoring interfaces for operators, ensuring that synchronization procedures can be performed safely and efficiently.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル | SYN 5201a-Z, V2277 |
| ABB 型番 | 3BHB006714R2277 |
| Function | Generator synchronization with grid |
| Input Voltage | 100–240 V AC/DC |
| Input Frequency | 50/60 Hz |
| Output Signals | Binary outputs for synchronization status |
| Communication Interfaces | Analog & digital input/output signals |
| Control Mode | Automatic / Manual |
| Accuracy | ±0.1° phase, ±0.5% frequency |
| Response Time | <50 ms |
| Operating Temperature | -20°C to +60°C |
| Protection Class | IP20 |
| Mounting | Panel / Rack |
| Dimensions (W × H × D) | 226 × 171 × 220 mm |
| 重量 | 4 kg |
Applications
The SYN 5201a-Z, V2277 is widely used in the following scenarios:
-
Synchronization / generators in thermal, hydro, and renewable power plants.
-
Grid connection / standby and backup generators.
-
Integration in combined heat and power (CHP) systems.
-
Industrial facilities requiring precise load sharing and system stability.
-
Control centers for automated power distribution and grid management.
This device ensures minimal transient effects during synchronization, reducing stress on generators and grid infrastructure.
Advantages
The key advantages / the SYN 5201a-Z include:
-
High-precision synchronization with fast response.
-
Dual-mode operation: automatic and manual.
-
Comprehensive monitoring interfaces for operators.
-
Compatibility with multiple generator types and control systems.
-
Compact design with easy installation and maintenance.
-
Robust performance under extreme temperature conditions.
-
Reduced risk / generator damage and grid disturbances.
FAQ
-
What types / generators can SYN 5201a-Z synchronize?
The device supports synchronous generators / all standard sizes, including hydro, thermal, and gas turbine types. -
Can the SYN 5201a-Z handle both 50 Hz and 60 Hz systems?
Yes, it is designed to operate accurately on both 50 Hz and 60 Hz networks. -
Is it possible to integrate the device into existing SCADA systems?
Yes, it provides both analog and digital interfaces compatible with common SCADA communication protocols. -
How does the device ensure phase alignment with the grid?
It continuously measures generator and grid voltage phase angles and adjusts the closing operation until precise alignment is achieved. -
Can the device operate in fully automatic mode?
Yes, it has a fully automatic mode that allows hands-free synchronization while maintaining safety interlocks. -
Does the SYN 5201a-Z provide alarm outputs for synchronization errors?
Yes, it includes binary outputs that indicate synchronization success or failure and other alarm conditions. -
How fast is the synchronization response time?
The device achieves synchronization in less than 50 milliseconds under standard conditions. -
Can it synchronize multiple generators to the same grid?
Yes, multiple 台s can be coordinated for sequential or parallel synchronization. -
What safety measures are included in the device?
It includes over-voltage, under-voltage, and phase-angle mismatch protection to prevent generator or grid damage. -
Is manual synchronization possible in case / control system failure?
Yes, operators can switch to manual mode and perform synchronization while monitoring all relevant signals.
Related or Similar モデルs
| モデル | Function | Communication Interface | Control Mode | 型番 |
|---|---|---|---|---|
| SYN 5201a-X | Generator synchronization | Analog/Digital | Auto/Manual | 3BHB006714R2260 |
| SYN 5201b-Z | Advanced generator synchronization | Analog/Digital | Auto/Manual | 3BHB006714R2280 |
| SYN 5202a-Z | High-precision synchronization | Analog/Digital | Auto/Manual | 3BHB006714R2301 |
| SYN 5203a-Z | Multi-generator synchronization | Analog/Digital | Auto/Manual | 3BHB006714R2311 |
| SYN 5210-Z | Grid tie synchronization | Digital | Auto | 3BHB006714R2400 |
| SYN 5211-Z | Redundant generator synchronization | Analog/Digital | Auto/Manual | 3BHB006714R2420 |
Popular ABB モデルs
| モデル | Function | Communication Interface | Control Mode | 型番 |
|---|---|---|---|---|
| ABB SYN 5200a | Standard synchronization device | Analog/Digital | Auto/Manual | 3BHB006714R2100 |
| ABB SYN 5200b | Advanced synchronization | Analog/Digital | Auto/Manual | 3BHB006714R2110 |
| ABB SYN 5300 | Grid and generator synchronization | Digital | Auto | 3BHB006714R2200 |
| ABB SYN 5400 | High-speed generator synchronizer | Analog/Digital | Auto/Manual | 3BHB006714R2210 |
| ABB SYN 5500 | Industrial synchronization 台 | Analog/Digital | Auto/Manual | 3BHB006714R2220 |
| ABB SYN 5600 | Redundant synchronization device | Analog/Digital | Auto/Manual | 3BHB006714R2230 |
