製品紹介
The ABB REF615C_D Feeder Protection and Control Relay is a next-generation intelligent electronic device (IED) designed to deliver advanced protection, monitoring, and control for medium-voltage distribution feeders. As part / ABB’s Relion® 615 family, the REF615C_D integrates modern digital technologies to ensure reliable network operation and seamless integration into smart grid and substation automation systems.
It provides a complete set / feeder protection functions, including overcurrent, earth fault, voltage, frequency, and breaker failure protection. With IEC 61850 compliance and support for multiple communication protocols, the REF615C_D enables high-speed data exchange and interoperability with various SCADA and control systems. Its compact design, user-friendly interface, and robust construction make it a trusted solution for both utility and industrial applications.
製品仕様
| Parameter | Details |
|---|---|
| Product モデル | ABB REF615C_D Feeder Protection and Control Relay |
| Series | Relion® 615 Series |
| Product Type | Feeder Protection and Control Relay |
| Protection Functions | Overcurrent, earth fault, voltage, frequency, breaker failure |
| Control Capabilities | Feeder control, breaker supervision, interlocking |
| Measurement Functions | Current, voltage, power, energy, frequency |
| Communication Protocols | IEC 61850, Modbus, DNP3, IEC 60870-5-103, Pr/ibus |
| Event Recording | 1000+ time-stamped events, integrated disturbance recorder |
| Display | Graphical LCD with multilingual support and intuitive menus |
| Power Supply | 24–250 V DC / 100–240 V AC |
| Mounting Type | Panel-mounted |
| Operating Temperature | –40°C to +70°C |
| Storage Temperature | –50°C to +85°C |
| Compliance Standards | IEC 60255, IEC 61850, ANSI/IEEE |
| Dimensions (H x W x D) | 177 x 177 x 201 mm |
| 重量 | 4.1 kg |
Product Applications
The ABB REF615C_D is designed to provide reliable and efficient feeder protection across various environments:
-
Medium-Voltage Distribution Systems: Protects feeders in radial, ring, and meshed networks.
-
Industrial Power Plants: Provides secure and continuous power for heavy industrial processes.
-
Substation Automation: Integrates into IEC 61850-compliant digital substations with full GOOSE support.
-
Smart Grid Networks: Enhances monitoring, control, and interoperability for intelligent grid applications.
-
Renewable Energy Systems: Protects and monitors feeders in wind, solar, and hybrid energy installations.
-
Breaker Operation and Coordination: Offers secure breaker failure detection and interlocking to prevent cascading faults.
Product Advantages
-
Comprehensive Protection Suite: Incorporates multiple feeder protection elements into one device, reducing complexity.
-
Full IEC 61850 サポート: Enables seamless integration with digital substations and high-speed peer-to-peer communication.
-
Advanced Monitoring & Event Analysis: Built-in disturbance recorder and detailed event logging assist in fast fault diagnosis.
-
Wide Protocol Compatibility: サポートs Modbus, DNP3, IEC 60870-5-103, and Pr/ibus in addition to IEC 61850.
-
Intuitive User Interface: Large graphical display and structured menus simplify configuration and monitoring.
-
Rugged Design: Designed to withstand harsh environmental and electrical conditions with extended temperature ranges.
FAQ
-
What types / protection does the REF615C_D provide?
It /fers overcurrent, earth-fault, voltage, frequency, and breaker failure protection in a single 台. -
Is the REF615C_D fully compliant with IEC 61850 standards?
Yes, it supports IEC 61850, including GOOSE messaging for fast peer-to-peer communication. -
Can the REF615C_D operate in meshed distribution networks?
Yes, it supports radial, ring, and meshed feeder configurations, making it versatile for different grid topologies. -
What auxiliary voltage range does the device accept?
The device supports 24–250 V DC and 100–240 V AC auxiliary power inputs. -
Does the REF615C_D include breaker failure protection and interlocking?
Yes, it integrates breaker failure detection and advanced interlocking schemes for enhanced network reliability. -
What kind / event recording capabilities does it have?
It can store over 1000 time-stamped events and includes a high-resolution disturbance recorder. -
Which communication protocols are supported besides IEC 61850?
It supports Modbus, DNP3, IEC 60870-5-103, and Pr/ibus for broad interoperability. -
Can the REF615C_D measure and log electrical parameters?
Yes, it measures current, voltage, power, energy, and frequency with high accuracy. -
Is the device suitable for renewable energy integration?
Yes, it is widely used for protecting feeders in wind, solar, and hybrid renewable systems. -
Does the REF615C_D support integration with substation automation systems?
Yes, it is designed to work seamlessly with SCADA and digital substation automation platforms.
Related モデルs (Same Series or Similar)
| モデル | 説明 | Key Features |
|---|---|---|
| ABB REF610 | Basic Feeder Protection Relay | Essential feeder protection, cost-effective solution |
| ABB REF611 | Feeder Protection Relay | Compact relay with IEC 61850 compliance |
| ABB REF615 | Feeder Protection and Monitoring Device | Comprehensive feeder protection and control |
| ABB REF615C_C | Feeder Protection and Control Relay | Advanced version with enhanced configuration |
| ABB REF620 | Advanced Feeder Protection Relay | Extended functionality for complex networks |
| ABB REM615 | Motor Protection and Control Relay | Specialized for industrial motor applications |
Popular モデルs from the Same ブランド
| モデル | Product Type | Application |
|---|---|---|
| ABB REX640 | Modular Protection Device | Multi-application protection and control |
| ABB REL670 | Line Protection Relay | Advanced line protection for transmission networks |
| ABB RET670 | Transformer Protection Relay | Differential and backup protection for transformers |
| ABB REM630 | Motor Protection Relay | High-performance motor protection and control |
| ABB REF542plus | Feeder Automation Controller | Integrated control and feeder management |
| ABB 615 Series | Protection and Control Relays | Feeder, motor, and transformer applications |
