製品紹介
The ABB REF615 Feeder Protection and Monitoring Device is a compact, intelligent, and fully IEC 61850-compliant relay designed for the protection, control, measurement, and supervision / utility and industrial power distribution feeders. It belongs to ABB’s renowned Relion® 615 series, which provides advanced digital protection for medium-voltage networks.
REF615 is engineered to support modern smart grid environments and /fers comprehensive protection functions including overcurrent, earth-fault, voltage, frequency, and breaker failure protection. The device also integrates monitoring and control capabilities, enabling operators to improve network reliability and reduce downtime. Its modular hardware and flexible configuration make it suitable for a wide range / feeder applications in both radial and ring networks.
製品仕様
| Parameter | Details |
|---|---|
| Product モデル | ABB REF615 Feeder Protection and Monitoring Device |
| Series | Relion® 615 Series |
| Product Type | Feeder Protection and Control Relay |
| Protection Functions | Overcurrent, earth fault, voltage, frequency, breaker failure |
| Communication Protocols | IEC 61850, Modbus, DNP3, IEC 60870-5-103, Pr/ibus |
| Control Capabilities | Feeder control, breaker supervision, interlocking |
| Measurement Functions | Current, voltage, power, frequency, energy |
| HMI Interface | Large graphical LCD with menu-driven navigation |
| Event Recording | 1000+ events with timestamp, disturbance recorder |
| Power Supply | 24–250 V DC / 100–240 V AC |
| Mounting Type | Panel-mounted |
| Operating Temperature | –40°C to +70°C |
| Storage Temperature | –50°C to +85°C |
| Compliance Standards | IEC 60255, IEC 61850, ANSI/IEEE |
| Dimensions (H x W x D) | 177 x 177 x 201 mm |
| 重量 | 4.1 kg |
Product Applications
The ABB REF615 is widely used for feeder protection and control in various utility and industrial networks:
-
Medium-Voltage Distribution Feeders: Comprehensive protection for radial and ring networks.
-
Industrial Power Systems: Ensures operational reliability in manufacturing plants and processing facilities.
-
Substation Automation: Integrated IEC 61850 support for seamless digital substation environments.
-
Smart Grids: Advanced monitoring and communication for intelligent distribution networks.
-
Renewable Energy Systems: Protection and control / feeders in wind, solar, and hybrid power plants.
-
Breaker Control and Supervision: Provides reliable breaker interlocking, supervision, and failure protection.
Product Advantages
-
Comprehensive Protection Suite: Covers all essential feeder protection functions including overcurrent, earth fault, and voltage.
-
IEC 61850 Compliant: Fully supports digital substation integration with advanced GOOSE messaging.
-
Flexible Communication Options: Offers multiple protocols for interoperability with various SCADA systems.
-
Advanced Monitoring and Recording: Integrated disturbance recorder and event logs for efficient fault analysis.
-
User-Friendly HMI: Large graphical display with intuitive navigation for easy setup and monitoring.
-
Rugged Industrial Design: Withstands harsh environments with wide operating temperature range and robust construction.
FAQ
-
Which protection functions are included in the ABB REF615?
It provides overcurrent, earth-fault, voltage, frequency, and breaker failure protection as standard. -
Does the REF615 support IEC 61850 communication?
Yes, the device is fully IEC 61850-compliant, supporting GOOSE messaging and substation automation integration. -
Can the REF615 be used in both radial and ring feeder networks?
Yes, it is designed to protect feeders in radial, ring, and meshed distribution network topologies. -
What is the range / power supply voltage supported by the device?
The REF615 operates with 24–250 V DC or 100–240 V AC auxiliary power supply. -
Does the REF615 include event and disturbance recording?
Yes, it can store over 1000 time-stamped events and includes a built-in disturbance recorder for fault analysis. -
What communication protocols are supported besides IEC 61850?
The REF615 supports Modbus, DNP3, IEC 60870-5-103, and Pr/ibus for SCADA integration. -
Is the device suitable for smart grid applications?
Yes, its advanced communication, monitoring, and control capabilities make it ideal for smart distribution networks. -
Can the REF615 perform breaker failure protection?
Yes, it includes breaker failure detection and interlocking features to enhance network reliability. -
Does the REF615 support measurement / power and energy?
Yes, it can measure current, voltage, active/reactive power, frequency, and energy values. -
What industries commonly use the ABB REF615?
It is widely used in utilities, industrial plants, renewable energy systems, and automated substations.
Related モデルs (Same Series or Similar)
| モデル | 説明 | Key Features |
|---|---|---|
| ABB REF610 | Basic Feeder Protection Relay | Entry-level feeder protection with essential functions |
| ABB REF611 | Feeder Protection Relay | Compact IEC 61850-compliant protection relay |
| ABB REF620 | Advanced Feeder Protection Relay | Extended functionality and flexible configuration |
| ABB REM615 | Motor Protection and Control Relay | Designed for industrial motor applications |
| ABB RET615 | Transformer Protection and Control Relay | Advanced transformer protection functions |
| ABB REU615 | Voltage Protection and Control Relay | Focused on voltage and frequency protection |
Popular モデルs from the Same ブランド
| モデル | Product Type | Application |
|---|---|---|
| ABB 615 Series | Protection and Control Relays | Feeder, motor, and transformer protection |
| ABB REX640 | Modular Protection and Control Device | Multi-application protection platform |
| ABB REL670 | Line Protection Relay | Advanced line protection for transmission networks |
| ABB RET670 | Transformer Protection Relay | Comprehensive transformer differential protection |
| ABB REM630 | Motor Protection Relay | High-performance motor protection and control |
| ABB REF542plus | Feeder Automation Controller | Integrated control and protection for feeders |
