製品紹介
The ABB PP874 3BSE069271R1 Touch Panel is a robust, high-performance operator interface designed for demanding industrial environments. As part / ABB’s renowned control system HMI series, this touch panel combines intuitive usability with industrial-grade durability. It is commonly used in various process automation tasks, including machine control, system visualization, and data monitoring. With a responsive touchscreen interface and compact design, the PP874 enhances operator efficiency and system integration capabilities. Its wide compatibility with ABB control systems, such as the AC800M and AC500 series, ensures a seamless operation across multiple platforms.
The touch panel is housed in a rugged enclosure suitable for harsh industrial settings. It supports multiple communication protocols and integrates easily with SCADA and PLC systems, making it ideal for use in manufacturing, utilities, and energy sectors. Its screen clarity, reliable performance, and long lifecycle contribute to its popularity among system integrators and plant operators worldwide.
製品仕様
| Parameter | Value |
|---|---|
| モデル | PP874 |
| 型番 | 3BSE069271R1 |
| Display Type | TFT LCD Touchscreen |
| Display Size | 7 inches |
| Display Resolution | 800 x 480 pixels |
| Touchscreen Technology | Resistive |
| Processor | ARM-based CPU |
| RAM | 256 MB |
| Flash Memory | 512 MB |
| Communication Ports | 1 x Ethernet, 2 x USB, 1 x Serial (RS232/485) |
| サポートed Protocols | Modbus TCP/IP, OPC, Pr/ibus, Ethernet/IP |
| Operating System | Embedded Linux-based ABB firmware |
| Power Supply | 24 VDC nominal (18–30 VDC range) |
| Power Consumption | Approx. 12 W |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Protection Class | IP65 (front), IP20 (rear) |
| Mounting | Panel Mount |
| Dimensions (W x H x D) | 204 × 143 × 43 mm |
| 重量 | 0.8 kg |
| Certifications | CE, RoHS, UL |
Product Applications
The ABB PP874 3BSE069271R1 is extensively used in industrial automation scenarios requiring real-time interaction and visualization. Typical applications include:
-
Process Control Panels: Visualizing process variables and control loops.
-
Manufacturing Automation: Interface for machine operators in production lines.
-
Building Management Systems: Control and monitor HVAC, lighting, and energy usage.
-
Water and Wastewater Treatment: Local display and control in treatment facilities.
-
Power and Energy Monitoring: Displaying energy usage trends and alerts.
-
OEM Machine Interfaces: Embedded in OEM equipment as user interface panels.
Product Advantages
-
Rugged and Industrial-Grade: Built to endure harsh operating environments with vibration and temperature resistance.
-
Wide Protocol サポート: Ensures compatibility with multiple ABB and third-party PLCs and SCADA systems.
-
Compact Design: Space-saving dimensions make it ideal for tight enclosures or cabinet installations.
-
User-Friendly Interface: High-resolution touchscreen provides clear visualization and responsive control.
-
High Reliability: Proven stability in 24/7 industrial operations.
-
Integrated ABB Firmware: Seamlessly integrates into ABB automation systems for easy deployment and configuration.
-
Long-Term Availability: ABB /fers long product lifecycles and ongoing support.
-
Low Power Consumption: Efficient design minimizes energy costs and heat generation.
よくある質問 (FAQ)
-
What s/tware is required to configure the ABB PP874 Touch Panel?
– ABB’s Panel Builder or Automation Builder s/tware is typically used for HMI screen configuration. -
Can the PP874 be used with third-party PLCs?
– Yes, it supports common protocols such as Modbus and Ethernet/IP for compatibility with non-ABB systems. -
Is the panel suitable for outdoor applications?
– While the front panel is IP65 rated, it is recommended to use it in protected or indoor enclosures. -
Does the device support remote monitoring?
– Indirectly, yes. With network access, it can be integrated into remote SCADA or control systems. -
How is firmware updated on the PP874?
– Firmware updates are done via USB or Ethernet using ABB’s firmware utility tools. -
What is the power input range for the panel?
– The panel operates on 24 VDC nominal, with a range / 18–30 VDC. -
Can I customize the HMI layout and graphics?
– Yes, ABB’s configuration tools allow full customization / screen layout, buttons, and process 閲覧数. -
Does the panel support trending and data logging?
– Yes, it includes built-in support for real-time trending and historical data logging. -
Is it possible to mount this panel vertically or horizontally?
– It supports flexible mounting orientations as long as adequate ventilation is maintained. -
What is the expected lifespan / the touch screen?
– Under normal industrial usage, the resistive touchscreen typically lasts over 1 million touch operations.
Recommended Related or Same-Series モデルs
| モデル Number | 説明 | Display Size | Interface |
|---|---|---|---|
| PP865 3BSE030740R1 | Touch Panel, basic version | 5.7” | Serial + Ethernet |
| PP880 3BSE069272R1 | High-performance HMI with extended memory | 10.4” | Ethernet + USB |
| PP875 3BSE069273R1 | Advanced graphical panel | 8.4” | RS232 + USB |
| CP651 3BSE012869R1 | Compact Panel for basic HMI tasks | 3.5” | Serial |
| CP665 3BSE030740R2 | Mid-size HMI with touch and visualization | 7” | Ethernet |
| PP870 3BSE069270R1 | Entry-level HMI for process interface | 5” | Ethernet + RS485 |
Popular モデルs from the Same ブランド (ABB)
| モデル Number | 説明 | Main Feature | Application Focus |
|---|---|---|---|
| AC800M PM861A | Control CPU Module for ABB DCS | Modular design | Process Control Systems |
| PM864AK01 3BSE018161R1 | High-Performance CPU Module | Redundant support | Industrial Automation |
| CI854AK01 3BSE030220R1 | Communication Interface Pr/ibus | Pr/ibus-DP interface | PLC Networking |
| AI810 3BSE008516R1 | Analog Input Module (8 ch) | 0-20 mA / 4-20 mA inputs | Process I/O Integration |
| DO810 3BSE008510R1 | Digital Output Module (16 ch) | 24 VDC transistor output | Machine Control |
| CP600-Eco | Entry-level HMI series for cost-effective setups | Web-based engineering | Compact HMI Applications |
