製品紹介
The ABB PM590 1SAP150000R0100 is a central processing 台 (CPU) module within the AC500 Programmable Logic Controller (PLC) series. Designed for distributed automation systems, this module /fers robust performance and flexibility, making it suitable for a wide range / industrial applications. It features a 2MB memory capacity, supports various communication interfaces, and includes an LCD display for user interaction.
Technical Specifications
| Parameter | Details |
|---|---|
| モデル Number | PM590 |
| Product ID | 1SAP150000R0100 |
| Memory Capacity | Total: 5120 kB; User Program: 2048 kB; User Data: 3072 kB |
| Memory Type | Flash EPROM, Non-volatile RAM, SD Card |
| Processing Time | 0.000002 ms |
| Communication Interfaces | 2x RS232/485 (configurable), FBP, Ethernet |
| Display | LCD with 1 line and 8 function keys |
| Real-Time Clock | Yes |
| Power Supply | 24 V DC (20.4 – 28.8 V DC) |
| Mounting | DIN Rail TH35-15 (35 x 15 mm) per IEC 60715 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Protection Rating | IP20 |
| Dimensions (L x W x H) | 124 x 124 x 119 mm |
| 重量 | 1.2 kg |
| Maximum Digital I/Os | 320 DI, 240 DO/DC (local max. 10 extension modules) |
| Maximum Analog I/Os | 160 AI, 160 AO (local max. 10 extension modules) |
| Programming S/tware | PS501-PROG Control Builder Plus |
| Certifications | CE, UL, CSA, DNV, RINA, RMRS |
| Country / Origin | Germany |
Product Applications
The ABB PM590 CPU module is utilized in various industrial sectors, including:
-
Manufacturing Automation: Controls complex production lines and machinery.
-
Process Industries: Manages operations in chemical, pharmaceutical, and food processing plants.
-
Energy Sector: Oversees processes in power generation and distribution systems.
-
Water and Wastewater Treatment: Automates treatment processes and monitors system performance.
-
Transportation: Integrates into control systems for railways and other transportation infrastructures.
Product Advantages
-
High Performance: Fast processing time ensures efficient handling / complex control tasks.
-
Versatile Communication: Multiple interfaces allow seamless integration with various devices and networks.
-
Scalability: サポートs expansion with additional I/O modules to accommodate growing system requirements.
-
User-Friendly Interface: LCD display with function keys facilitates easy monitoring and configuration.
-
Robust Design: Durable construction and wide operating temperature range suit harsh industrial environments.
-
Compliance: Meets international standards and certifications, ensuring reliability and safety.
よくある質問 (FAQ)
-
Q: What programming s/tware is compatible with the PM590 module?
-
A: The PM590 is programmed using PS501-PROG Control Builder Plus.
-
-
Q: Can the PM590 module be mounted vertically?
-
A: Yes, it can be mounted vertically with appropriate derating considerations.
-
-
Q: Does the PM590 support real-time clock functionality?
-
A: Yes, it includes a real-time clock for time-dependent operations.
-
-
Q: What is the maximum number / I/O modules that can be connected?
-
A: Up to 10 extension modules can be connected locally.
-
-
Q: Is the PM590 suitable for use in extreme temperatures?
-
A: It operates effectively within a temperature range / 0°C to +60°C.
-
-
Q: What types / communication interfaces are available?
-
A: The module /fers 2x RS232/485 (configurable), FBP, and Ethernet interfaces.
-
-
Q: Does the PM590 have any display features?
-
A: Yes, it features an LCD display with one line and eight function keys.
-
-
Q: What is the protection rating / the PM590?
-
A: It has an IP20 protection rating.
-
-
Q: Can the PM590 be used in distributed automation systems?
-
A: Yes, it is designed for use in distributed automation applications.
-
-
Q: Where is the PM590 manufactured?
-
A: The PM590 is manufactured in Sweden.
-
Related モデルs in the Same Series
| モデル | 説明 |
|---|---|
| PM590-ETH | Processor module with Ethernet interface |
| PM590-ARCNET | Processor module with ARCNET interface |
| PM591-ETH | Enhanced processor module with Ethernet interface |
| PM582 | Compact CPU module for smaller applications |
| PM581-ETH | CPU module with Ethernet interface for mid-range systems |
| PM571-ETH | Entry-level CPU module with Ethernet interface |
Popular ABB モデルs (Same ブランド)
| モデル | 説明 |
|---|---|
| PM864AK01 | High-performance AC 800M CPU module |
| CI854AK01 | PROFIBUS interface module for decentralized I/O |
| TB840A | RCU linking module for redundant systems |
| AI810 | 8-channel analog input module |
| DI810 | 16-channel digital input module |
| AO810V2 | 8-channel analog output module |
