Product Overview
The ABB PM861AK01 (3BSE018157R1) is a core processor module designed for the AC 800M distributed control system platform. As an integral part / ABB’s 800xA control architecture, the PM861AK01 provides high-performance processing power, robust communication interfaces, and support for redundant configurations, ensuring reliable operation in critical industrial environments.
This controller 台 features a PowerPC-based CPU, multiple Ethernet ports, serial communication channels, and integrated memory. It is widely used in process automation, power generation, oil and gas, and various other demanding industries where real-time control, system availability, and long-term reliability are essential.
Key Features
-
Powerful 48 MHz PowerPC processor architecture.
-
サポートs redundant CPU configurations with automatic switchover (<10 ms).
-
Integrated dual Ethernet ports for network redundancy and communication.
-
CompactFlash interface for firmware and application storage.
-
Galvanic isolation / communication ports for signal integrity.
-
Hot-swappable design for easy maintenance and system upgrades.
-
Compatibility with ABB S800 I/O and AC 800M modules.
-
Robust metal housing with DIN-rail mounting for industrial environments.
-
Compliance with global industry standards (CE, UL).
-
Designed for long-term operation in mission-critical systems.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル | PM861AK01 |
| 型番 | 3BSE018157R1 |
| Processor | 48 MHz PowerPC |
| RAM Memory | 16 MB |
| CompactFlash Slot | Yes (For firmware and application storage) |
| Ethernet Ports | 2 × RJ45 (CN1, CN2) |
| Serial Ports | COM3 RS-232C, COM4 (galvanically isolated) |
| Redundancy Switchover | < 10 ms |
| Backup Battery | 1 × Lithium Battery (品番. 4943013-6) |
| サポートed I/O | S800 I/O Series, AC 800M Modules |
| Communication | ModuleBus, CEX-Bus, Ethernet |
| Operating Voltage | 24 VDC (19.2–30 VDC) |
| Isolation Voltage | 500 VAC |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity | 5% to 95% Non-condensing |
| Dimensions | 135 × 186 × 119 mm |
| 重量 | 1.2 kg |
| Certifications | CE, UL, RoHS Non-compliant (Legacy Product) |
| Mounting | DIN-rail with slide-lock mechanism |
Industry Applications
-
Oil & Gas: Real-time control and monitoring in /fshore platforms, refineries, and pipelines.
-
Power Generation: Automation and safety in thermal, nuclear, and renewable energy plants.
-
Chemical Processing: Reliable control / complex chemical and petrochemical processes.
-
Pulp & Paper: Optimized production management and quality control.
-
Water & Wastewater Treatment: Distributed control and automation for plant operations.
-
Pharmaceutical Manufacturing: Precision control for batch processing and regulatory compliance.
Product Advantages
-
Redundancy Ready: サポートs dual-CPU redundancy for uninterrupted system operation.
-
Fast Switchover: <10 ms automatic failover enhances system availability.
-
Robust Communication: Dual Ethernet ports and isolated serial interfaces.
-
Flexible Storage: CompactFlash slot for application and firmware data.
-
Industrial Durability: Withstands harsh environments with wide temperature range and EMC protection.
-
Easy Integration: Fully compatible with ABB’s 800xA and S800 I/O platforms.
-
Maintenance-Friendly: Hot-swappable design minimizes downtime during servicing.
-
Scalable System Architecture: サポートs system expansion with additional modules and I/O.
-
Global Compliance: Certified for international use with CE, UL standards.
-
Legacy System サポート: Essential for maintaining and upgrading existing ABB control infrastructures.
よくある質問 (FAQ)
-
What is the processor specification for the PM861AK01?
It uses a 48 MHz PowerPC processor with 16 MB / RAM. -
Is the PM861AK01 compatible with redundant configurations?
Yes, it supports CPU redundancy with bumpless switchover under 10 milliseconds. -
What communication ports are available on the 台?
It includes 2 Ethernet RJ45 ports and 2 serial ports (COM3 RS-232C, COM4 isolated). -
Can the PM861AK01 be hot-swapped?
Yes, the module is hot-swappable for simplified maintenance. -
What type / memory storage is supported?
It supports CompactFlash cards for firmware and application storage. -
Is this controller suitable for new installations?
No, it is a legacy product primarily intended for maintaining existing ABB AC 800M systems. -
What are the environmental specifications?
Operating temperature: -20°C to +60°C; storage: -40°C to +85°C; humidity: 5% to 95% non-condensing. -
What power supply voltage does the PM861AK01 require?
It operates on 24 VDC (19.2–30 VDC range). -
Is the PM861AK01 RoHS compliant?
No, it is a legacy product and does not comply with RoHS directives. -
What system platforms is this controller compatible with?
It integrates with ABB AC 800M control systems, 800xA environments, and S800 I/O.
