The ABB PM564-TP-ETH (Order Code: 3ABD00033169) is a high-performance Programmable Logic Controller (PLC) from the ABB AC500 series. Designed for advanced industrial automation applications, this modular PLC combines flexibility, reliability, and powerful communication capabilities in one compact 台. It features integrated Ethernet connectivity and multiple I/O expansion possibilities, making it ideal for complex control systems in manufacturing, energy, infrastructure, and process industries.
The PM564-TP-ETH controller supports IEC 61131-3 programming languages and is engineered for harsh environments with robust EMC protection and wide operating temperature ranges. Its scalability and integration readiness with SCADA and DCS platforms position it as a future-pro/ solution in digital transformation initiatives.
製品仕様
| Parameter | Details |
|---|---|
| Product Name | ABB PM564-TP-ETH |
| Order Code | 3ABD00033169 |
| Processor Type | 32-bit RISC CPU |
| Program Memory | 512 kB (expandable via SD card) |
| Data Memory (RAM) | 256 kB |
| Communication Ports | 1 x Ethernet (RJ45), 1 x USB (Mini-B), 2 x COM (RS-232/RS-485) |
| Ethernet Protocols サポートed | Modbus TCP, OPC, SNMP, HTTP, FTP |
| I/O Capacity | サポートs up to 10 I/O modules locally |
| Digital I/O サポート | Configurable via expansion modules |
| Analog I/O サポート | Configurable via expansion modules |
| Memory Card Slot | SD card slot for firmware and application storage |
| Programming 言語s | IEC 61131-3 (LD, FBD, ST, IL, SFC) |
| Supply Voltage | 24 VDC (nominal) |
| Power Consumption | Approx. 4.5 W |
| Mounting Type | DIN rail |
| Protection Class | IP20 |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions (W x H x D) | 74 x 135 x 82 mm |
| 重量 | 0.29 kg |
| Certifications | CE, UL, cUL, RoHS, ATEX Zone 2 compliant |
Product Applications
The PM564-TP-ETH PLC is widely used across industries due to its scalability and reliability. Key application areas include:
-
Factory Automation: Assembly lines, packaging systems, robotics control.
-
Energy and Utilities: Power plant control, water/wastewater treatment.
-
Infrastructure: Intelligent traffic systems, tunnel automation.
-
Building Management: HVAC systems, access control, lighting automation.
-
Renewable Energy: Wind turbine control, solar PV plant monitoring.
Product Advantages
-
Integrated Ethernet Communication
Seamless connectivity to networks, SCADA, and third-party systems. -
Modular and Scalable Architecture
Allows flexible I/O expansion tailored to specific automation needs. -
IEC 61131-3 Programming
Industry-standard languages increase programming flexibility and compatibility. -
Robust and Industrial-Grade
Operates reliably in challenging industrial environments with wide temperature support. -
Low Power Consumption
Energy-efficient operation for sustainable system design. -
Field Proven Reliability
Trusted by global industries for consistent performance and uptime.
よくある質問 (FAQ)
-
What programming s/tware is used for PM564-TP-ETH?
It is programmed using ABB’s Automation Builder s/tware suite. -
Does the PM564-TP-ETH support Ethernet communication?
Yes, it features an integrated Ethernet port supporting Modbus TCP, HTTP, SNMP, and more. -
Can the PM564 be expanded with I/O modules?
Yes, up to 10 local I/O modules can be added for system expansion. -
Is it suitable for harsh environments?
Yes, it operates from -10°C to +60°C and has EMC protection. -
How is the PLC mounted?
The 台 is mounted on a standard DIN rail. -
Is remote programming or diagnostics possible?
Yes, via Ethernet or USB interfaces using Automation Builder. -
Can it be integrated into SCADA or DCS systems?
Yes, using supported protocols like Modbus TCP and OPC. -
Does it support SD cards for memory expansion?
Yes, it includes an SD card slot for additional application and firmware storage. -
What is the main difference between PM564 and PM554 models?
PM564 has enhanced Ethernet support and more I/O expansion capability. -
Is this PLC compliant with global standards?
Yes, it is certified with CE, UL, cUL, and ATEX Zone 2 compliance.
Recommended Related モデルs (Same Series)
| モデル | Order Code | Key Features |
|---|---|---|
| PM554-RP-ETH | 1SAP120500R0001 | Entry-level CPU with Ethernet, serial COM, SD slot |
| PM564-RP-ETH | 1SAP120600R0001 | Mid-range CPU with larger memory and 2 COM ports |
| PM566-TP-ETH | 1SAP120700R0001 | High-end model with faster CPU, extended diagnostics |
| CI581-CN | 1SAP111100R0270 | PROFINET communication module for AC500 |
| AC500-eCo PM554-RP | 1SAP120200R0001 | Compact economical version for small-scale automation |
| CP600-HMI | 1SAP500900R0001 | Compatible HMI panel for visualization and control |
Recommended Popular ABB モデルs
| モデル | Order Code | 説明 |
|---|---|---|
| AC500 PM592-ETH | 1SAP131100R0270 | High-end AC500 CPU with advanced Ethernet capabilities |
| AC500-XC PM573-ETH | 1SAP120800R0001 | Extreme condition PLC with extended temperature support |
| CP600-Pro HMI | 1SAP500500R0001 | Advanced touch panel for control and monitoring |
| REF615 | 1MRK001ABB | Feeder Protection Relay used in power distribution |
| PVS980 | 3AUA0000138066 | Central inverter for solar PV applications |
| ABB Freelance AC700F | 1SAP707000R0001 | Hybrid DCS/PLC controller with DCS integration |
