Product Overview
The ABB P13AC8 1MRK002266-AAR03 is a high-performance binary input/output (I/O) module designed for robust industrial automation and substation control systems. This module facilitates the interfacing / discrete signals in a wide range / applications, such as monitoring and controlling switches, alarms, relays, and other field devices.
With its compact form factor and reliable operation, the ABB P13AC8 module /fers exceptional value for mission-critical control systems where fast response times, operational safety, and high reliability are paramount. It supports multiple communication protocols, including IEC 61850, Modbus, and IEC 60870-5-103, ensuring seamless integration into diverse automation systems.
The P13AC8 is engineered to perform optimally even in harsh environments, with a wide operating temperature range and advanced diagnostic features that simplify maintenance and troubleshooting. Its efficient design and flexible mounting options make it suitable for applications in power generation, transportation, oil & gas, and industrial automation.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル Number | P13AC8 1MRK002266-AAR03 |
| ブランド | ABB |
| Product Type | Binary Input/Output Module |
| Input Channels | 8 Binary Inputs |
| Output Channels | 8 Binary Outputs |
| Input Voltage Range | 24 VDC / 48 VDC |
| Input Type | Dry お問い合わせ / Voltage Input |
| Output Type | Mechanical Relay Outputs (Form A お問い合わせs) |
| Output Current Rating | 2 A @ 250 VAC / 2 A @ 30 VDC |
| Isolation Voltage | 2 kV RMS |
| Switching Time | < 5 ms |
| サポートed Protocols | IEC 61850, Modbus, IEC 60870-5-103 |
| LED Indicators | Per Channel Status LEDs |
| Diagnostics | Integrated Self-Test and Fault Diagnostics |
| Mounting Options | DIN Rail / Panel Mount |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Ingress Protection | IP20 |
| Certifications | CE, RoHS, UL, IEC |
| Housing Material | Flame-retardant Plastic |
| Dimensions (L × W × H) | 230 x 130 x 30 mm |
| 重量 | 0.208 kg |
Applications
-
Substation Automation
The P13AC8 is ideal for monitoring and controlling circuit breakers, disconnectors, transformers, and alarms in electrical substations, ensuring efficient and reliable operation. -
Industrial Automation
It integrates seamlessly with PLCs, SCADA systems, and DCS systems to manage discrete inputs and outputs in manufacturing and process control environments. -
Power Generation
This module plays a critical role in power plant auxiliary system monitoring, turbine control, and generator protection. -
Transportation
The P13AC8 module is used in rail signaling, airport lighting control, and tunnel safety systems, ensuring smooth operation in transportation infrastructure. -
Oil & Gas
In the oil and gas sector, it supports safety functions, emergency shutdown systems, and automation in hazardous environments. -
Renewable Energy
It is widely used in solar, wind, and hydroelectric plants for efficient monitoring / system components, such as inverters and circuit breakers.
Advantages
-
High Reliability
Designed with robust features to withstand harsh environmental conditions, including extreme temperatures and vibrations. -
Fast Switching Time
The module features a fast switching time / less than 5 milliseconds, ensuring quick response for critical control functions. -
Wide Compatibility
It supports multiple communication protocols such as IEC 61850, Modbus, and IEC 60870-5-103, enabling integration with a variety / control and monitoring systems. -
Diagnostic Capabilities
With built-in diagnostic feedback and status indicators, the P13AC8 simplifies maintenance and troubleshooting by providing real-time insights into module performance. -
Compact Design
The compact size and versatile mounting options (DIN rail or panel mount) allow for easy installation in control panels where space is limited. -
Operational Safety
The module meets international safety standards, ensuring it is safe for use in industrial and critical infrastructure applications.
FAQs
Q1: What is the primary function / the ABB P13AC8 module?
A1: The P13AC8 module is designed to handle binary inputs and outputs for monitoring and controlling field devices such as switches, alarms, and relays.
Q2: How many inputs and outputs does this module support?
A2: It supports 8 binary inputs and 8 binary outputs.
Q3: Is the module suitable for use in outdoor environments?
A3: The module has an IP20 ingress protection rating, so it must be installed inside a protective enclosure for outdoor use.
Q4: What communication protocols does the P13AC8 support?
A4: The module supports IEC 61850, Modbus, and IEC 60870-5-103 protocols for seamless integration with other automation systems.
Q5: What is the response time / the module?
A5: The module has a fast switching response time / less than 5 milliseconds.
Q6: Can the P13AC8 module be mounted on a DIN rail?
A6: Yes, the P13AC8 module can be mounted on a DIN rail or directly onto a control panel.
Q7: What is the maximum operating temperature / the P13AC8 module?
A7: The module can operate in temperatures ranging from -25°C to +70°C.
Q8: Does the P13AC8 module provide any diagnostic features?
A8: Yes, the module includes integrated self-test functions and status LEDs to help diagnose faults and verify operational status.
Q9: What is the power supply requirement for the P13AC8 module?
A9: The module operates with a 24 VDC or 48 VDC power supply.
Q10: What is the size and weight / the module?
A10: The module measures 230 x 130 x 30 mm and weighs approximately 0.208 kg.
