Product Overview
The ABB EI 803F (3BDH000017R1) Ethernet Module is a high-performance communication interface designed for ABB’s industrial control and automation systems. As part / ABB’s renowned automation product line, this Ethernet module enables seamless, reliable, and high-speed communication between controllers, field devices, and supervisory systems within a distributed control system (DCS) or programmable logic controller (PLC) network.
The EI 803F module provides robust Ethernet connectivity, ensuring reliable real-time data transmission across various network architectures. It supports essential industrial communication protocols and is suitable for critical applications in industries like power generation, oil & gas, water treatment, and manufacturing where stable, high-speed networking is vital.
Key Features
-
High-speed Ethernet communication for real-time industrial networking.
-
サポートs standard industrial protocols for seamless integration.
-
Rugged design suitable for demanding industrial environments.
-
Provides galvanic isolation for safe and interference-free data transmission.
-
DIN-rail mounting for easy installation and system integration.
-
Compact form factor for space-efficient cabinet layouts.
-
Fully compatible with ABB control systems and automation solutions.
-
Enhanced diagnostics and status indication for reliable operation.
-
Stable operation across wide temperature and humidity ranges.
-
Conforms to international industrial standards (CE, UL, RoHS).
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル | EI 803F |
| 型番 | 3BDH000017R1 |
| Communication Interface | Ethernet (10/100 Mbps) |
| サポートed Protocols | Industrial Ethernet, TCP/IP, and related protocols |
| Port Type | RJ45 |
| Galvanic Isolation | Yes, for reliable and safe operation |
| Status Indicators | LED indicators for communication and module status |
| Operating Voltage | 24 VDC (19.2–30 VDC) |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions | 125 ×155 ×28 mm |
| 重量 | 0.15 kg |
| Certifications | CE, UL, RoHS compliant |
| Mounting | DIN-rail mounting |
Industry Applications
-
Power Generation: Reliable Ethernet communication for plant control systems.
-
Oil & Gas: High-speed data exchange in /fshore platforms, pipelines, and refineries.
-
Water & Wastewater Treatment: Stable networking for plant monitoring and automation.
-
Manufacturing: Facilitates real-time communication in production lines and machine networks.
-
Chemical Processing: サポートs safe and efficient network integration in hazardous environments.
-
Building Automation: Enables centralized control and monitoring over Ethernet networks.
Product Advantages
-
Reliable Industrial Networking: Ensures consistent, interference-resistant Ethernet communication.
-
Protocol Flexibility: サポートs key industrial protocols for broad system compatibility.
-
Compact Design: Space-saving form factor ideal for control cabinets with limited space.
-
Safe Operation: Galvanic isolation protects both the module and connected equipment.
-
Ease / Installation: DIN-rail mounting simplifies integration into new or existing systems.
-
Wide Environmental Tolerance: Operates reliably across harsh industrial conditions.
-
Enhanced Diagnostics: LED indicators provide clear status monitoring for maintenance and troubleshooting.
-
Seamless ABB Integration: Designed to work optimally within ABB control architectures.
-
Energy Efficient: Low power consumption suitable for energy-conscious operations.
-
Certified Compliance: Meets global standards for safety, reliability, and environmental impact.
よくある質問 (FAQ)
-
What is the main function / the EI 803F module?
It provides Ethernet communication capability for ABB control and automation systems. -
What communication speeds does the EI 803F support?
It supports standard 10/100 Mbps Ethernet networking. -
Does the module include galvanic isolation?
Yes, galvanic isolation ensures safe and interference-free operation. -
What types / networks is this module suitable for?
It is designed for industrial Ethernet networks, supporting TCP/IP and related protocols. -
Can the EI 803F be mounted on a DIN rail?
Yes, it features DIN-rail mounting for easy installation. -
What is the operating temperature range / the module?
The module operates from -20°C to +60°C. -
Is the module compatible with non-ABB systems?
While optimized for ABB systems, it can integrate into other systems supporting standard Ethernet protocols. -
What certifications does the EI 803F hold?
The module is CE, UL, and RoHS compliant. -
What are the physical dimensions and weight?
Dimensions: 125mm ×155mm ×28 mm; 重量: approximately 0.15 kg. -
Is the module suitable for harsh industrial environments?
Yes, its rugged design and wide environmental tolerance ensure reliable performance in demanding conditions.
Related モデルs
| モデル | 説明 |
|---|---|
| EI 801F (3BDH000011R1) | Ethernet module with basic features for standard applications. |
| EI 802F (3BDH000012R1) | Mid-range Ethernet interface with enhanced diagnostics. |
| CI854A (3BSE018182R1) | PROFIBUS DP communication interface for AC 800M systems. |
| CI871 (3BSE018181R1) | PROFINET communication interface for distributed networks. |
| PM864AK01 (3BSE018161R1) | High-performance CPU controller for AC 800M systems. |
| PM865AK01 (3BSE018162R1) | SIL-rated High Integrity CPU for critical safety applications. |
Popular ABB モデルs
| モデル | 説明 |
|---|---|
| SD832 (3BSE018102R1) | Power supply module for AC 800M systems. |
| SB822 (3BSE018149R1) | Backup battery module for controller memory retention. |
| DI830 (3BSE008512R1) | Digital input module for process signal acquisition. |
| AI810 (3BSE008516R1) | Analog input module for precise process measurements. |
| PM863K01 (3BSE088381R1) | Advanced CPU controller with enhanced processing power. |
| PM862K01 (3BSE076940R1) | CPU controller with dual Ethernet and redundancy support. |
