Product Overview
The ABB DSQC363 3HAC1462-1 is an essential robot circuit board designed for integration within ABB industrial robotic control systems, especially the IRC5 controller family. This board is responsible for managing key control and communication tasks between internal subsystems, acting as a bridge between various modules such as axis computers, servo drives, and I/O systems.
Engineered for robust operation in high-demand industrial environments, the DSQC363 provides reliable logic processing and data routing capabilities. It is typically deployed within robotic control cabinets / ABB IRB-series robots, where consistency, low latency, and EMC resistance are critical.
Key Features
-
Central processing and communication interface board for IRC5
-
サポートs real-time robotic data flow and subsystem coordination
-
Interfaces with servo drives, I/O modules, measurement boards, and HMIs
-
Durable multi-layer PCB design for electrical and thermal stability
-
Equipped with diagnostic LEDs and test points
-
Easily installable into IRC5 controller rack slots
-
CE and RoHS compliant with ABB manufacturing standards
-
Fully compatible with RobotWare s/tware environment
Technical Specifications
| Item | Specification |
|---|---|
| メーカー | ABB |
| モデル Number | DSQC363 (3HAC1462-1) |
| Product Type | Robot Circuit Board |
| Application | ABB IRB Robots, IRC5 Controller |
| Communication Interfaces | ABB proprietary bus, signal, and power backplane |
| Processor | Embedded control processor (version varies) |
| Voltage Rating | Powered via controller backplane |
| Function | Signal routing, motion control logic, internal communications |
| Diagnostic サポート | Onboard LED indicators, controller log interface |
| Cooling Method | Passive (ambient controller airflow) |
| Mounting Type | Controller rack slot-in board |
| Operating Temperature | 0°C to +55°C (32°F to 131°F) |
| Storage Temperature | –25°C to +70°C (–13°F to 158°F) |
| Environmental Rating | IP20 (internal electronic board) |
| Dimensions | 320 x 220 x 70mm |
| 重量 | 1.5 kg |
| Certifications | CE, RoHS, EMC-compliant |
| Compatibility | IRC5 controller, ABB IRB series robots (IRB 2400, IRB 4600, etc.) |
Industry Applications
-
Automated Manufacturing – Central control in multi-axis robotic automation
-
Automotive Assembly – Real-time data coordination for welding and painting robots
-
Electronics Manufacturing – Logic control for precision robotics in surface-mount and assembly lines
-
Packaging & Logistics – Communication gateway in pick-and-place and sorting robotics
-
Aerospace Production – Data flow handling in composite laying and drilling robotics
-
Heavy Machinery Automation – Motion logic control in robotic handling / large components
Product Advantages
-
Integrated Design – Specifically built for seamless operation with ABB IRC5 systems
-
High-Speed Communication – Ensures minimal latency in motion and I/O control
-
Reliable Performance – Robust design for long-term deployment in industrial environments
-
Firmware サポート – Easily upgraded and managed via ABB RobotWare s/tware
-
Easy Diagnostics – Onboard indicators help reduce troubleshooting time
-
EMC-Resistant – Operates reliably in electrically noisy environments
-
Minimal Maintenance – No moving parts and protected circuitry
-
Global Availability – サポートed worldwide through ABB’s spare parts network
よくある質問 (FAQ)
-
Q: What controller is the DSQC363 board used with?
A: It is used in ABB IRC5 controllers, commonly found in IRB-series industrial robots. -
Q: What is the function / the DSQC363 board?
A: It manages internal communication between servo drives, I/O modules, and other controller components. -
Q: Can this board be field replaced?
A: Yes, it is a serviceable component within ABB’s modular control system architecture. -
Q: Is it compatible with older ABB controllers?
A: It is designed specifically for IRC5 and may not be compatible with S4/S4C/S4C+ controllers. -
Q: How do I diagnose issues with this board?
A: Use RobotWare logs and check onboard status LEDs for errors or fault codes. -
Q: What s/tware supports this circuit board?
A: It is supported by ABB’s RobotWare s/tware platform. -
Q: What is the expected operating lifespan?
A: The board is rated for long-term industrial use with proper environmental conditions. -
Q: Are refurbished versions / this board available?
A: Yes, ABB and authorized distributors /ten /fer certified refurbished 台s. -
Q: Does this board support external fieldbus communication?
A: It handles internal communication; external fieldbus modules are handled separately (e.g., DSQC652). -
Q: Is installation user-serviceable?
A: Installation should be done by trained personnel following ABB service procedures.
Related ABB Robot Control Boards
| モデル Number | 説明 |
|---|---|
| DSQC361 (3HAC12815-1) | Axis Computer Board for motion processing |
| DSQC652 | Pr/ibus Communication Interface Module |
| DSQC354 (3HAC1292-1) | Power Distribution Board for ABB Controllers |
| DSQC328 (3HAC17971-1) | Axis Communication Board used in multi-axis robots |
| DSQC363B | Updated version / DSQC363 for newer IRC5 systems |
| DSQC377B | I/O Expansion Interface for ABB robot systems |
Popular ABB Automation and Robotics モデルs
| モデル Number | 説明 |
|---|---|
| IRB 6700 | High-payload industrial robot for welding and handling |
| IRB 1200 | Compact 6-axis robot for assembly and small-part handling |
| IRB 2600 | General-purpose medium payload robot |
| IRC5 Controller | Flagship robot control platform for ABB IRB robots |
| RobotWare 6.x | ABB’s control s/tware for configuration and monitoring |
| DSQC679 | Drive Module Communication Board for high-speed data processing |
