Product Overview
The ABB DO571 (型番: 1TNE968902R2202) is a Digital Output (DO) module designed to deliver high-speed, high-reliability switching capabilities for industrial automation systems. This module belongs to ABB’s proven Advant Controller 31 or S800 I/O system portfolio and is widely adopted in distributed control systems (DCS), factory automation, and process industries where accuracy, fault tolerance, and scalability are critical.
Featuring 16 digital output channels, each channel on the DO571 is capable / sourcing 24 V DC signals. The module is designed to switch electrical loads such as indicator lamps, solenoids, contactors, and small relays. It comes with short-circuit protection, overload detection, and channel status diagnostics, making it a robust choice for controlling field devices under demanding conditions.
Technical Specifications
| Parameter | Value |
|---|---|
| モデル Name | DO571 |
| 型番 | 1TNE968902R2202 |
| Product Type | Digital Output Module |
| System Compatibility | Advant Controller 31, S800 I/O |
| Number / Output Channels | 16 |
| Output Type | Sourcing (PNP) |
| Nominal Output Voltage | 24 V DC |
| Voltage Range | 18–30 V DC |
| Maximum Output Current | 0.5 A per channel |
| Short Circuit Protection | Yes |
| Output Delay Time | < 1 ms |
| Load Type | Resistive, inductive |
| Channel Isolation | Channel-to-bus isolated |
| Diagnostics | Channel fault and status LEDs |
| Internal Power Consumption | Approx. 3 W |
| Connection Type | Screw terminals / DIN rail mountable |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 75 x 135 x 34 mm |
| 重量 | 0.138 kg |
| Certifications | CE, UL, cUL, RoHS |
