Product Overview
The ABB DI650 3BHT3000025R1 is a high-performance digital input module used in ABB Freelance Distributed Control Systems (DCS). Designed for industrial automation environments, the DI650 provides 32 channels / 48 V DC digital input, /fering real-time detection / binary states from field devices such as switches, sensors, and limit contacts. Its high input voltage range makes it particularly suitable for demanding applications requiring robust signal integrity in noisy environments.
Key Features
-
32 digital input channels with 48 V DC operating voltage
-
Isolated channels for enhanced system protection
-
Fast and reliable signal acquisition for binary field data
-
Built-in diagnostic LEDs for each input point
-
Compatible with ABB Freelance and Symphony Plus control systems
-
Compact footprint for space-saving installations
-
Designed to meet industrial EMC and temperature requirements
-
Pluggable terminals for simplified field wiring and maintenance
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル | DI650 |
| 型番 | 3BHT3000025R1 |
| Module Type | Digital Input Module |
| Channels | 32 |
| Input Voltage Range | 48 V DC (nominal), operating range: 36 V to 60 V DC |
| Input Type | Sink/source configurable (positive or negative logic) |
| Input Current | Approximately 2.5 mA per channel at 48 V DC |
| Isolation | Galvanic isolation between channels and system bus |
| Channel Status LEDs | One LED per channel (active state indication) |
| Wiring Method | Pluggable screw terminals |
| Diagnostics | Channel fault and overload indication |
| Response Time | < 5 ms |
| Operating Temp. | 0°C to +60°C |
| Storage Temp. | -25°C to +70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Cooling | Natural convection |
| Dimensions | 140 x 130 x 40mm |
| 重量 | 0.6 kg |
| Installation | DIN rail or backplane-mounted in system cabinet |
| Certifications | CE, RoHS, IEC 61131-2, EMC compliant |
Industry Applications
The DI650 module is widely deployed in industries where higher-voltage digital signal acquisition is necessary for reliable monitoring and control:
-
Oil & Gas – Monitoring / remote signals in substations and field junction boxes
-
Power & Energy – High-voltage breaker status and interlock signal acquisition
-
Chemical Processing – Binary condition monitoring in hazardous environments
-
Steel & Mining – Robust input capture in heavy-duty plant operations
-
Water & Wastewater – 州 monitoring / pumps, blowers, and relay circuits
-
Rail & Infrastructure – Digital interfacing in transportation and signaling systems
Product Advantages
-
High Voltage Tolerance – Designed for stable operation at 48 V DC input
-
Scalable System Integration – 32-channel density for compact signal acquisition
-
Field-Friendly Design – Clear signal status via LEDs, reducing commissioning time
-
Fault Diagnostics – Immediate feedback on channel health and operational issues
-
EMC Compliance – Reliable operation in environments with electromagnetic interference
-
ABB Lifecycle サポート – Ensures availability / updates, spares, and global service
よくある質問 (FAQ)
-
What is the purpose / the DI650 module?
It captures the digital ON/OFF status / field devices and relays this information to the DCS. -
What type / voltage input does it support?
The module supports 48 V DC nominal input, with a working range / 36 to 60 V DC. -
Can the module detect both sink and source signals?
Yes, it is configurable for both sinking and sourcing input logic. -
Is it compatible with the ABB Freelance system?
Yes, the DI650 is fully compatible with ABB Freelance and Symphony Plus control systems. -
Are the channels isolated from each other?
Yes, each input channel is galvanically isolated to prevent cross-talk and signal faults. -
Does it include diagnostics features?
Yes, it provides per-channel diagnostics and overload protection. -
How many input channels does it support?
The DI650 /fers 32 individual input channels. -
What is the typical response time?
Less than 5 milliseconds. -
Can the module be installed with other ABB modules?
Yes, it fits standard ABB Freelance module racks and terminal 台s. -
What is the benefit / using this module over 24 V DC models?
It /fers better signal imm台y and longer signal transmission range in noisy environments.
Related モデルs in the Same Series
| モデル Number | 説明 |
|---|---|
| DO650 3BHT300052R1 | 32-channel Digital Output Module (48 V DC) |
| DI620 3BHT300002R1 | 32-channel Digital Input Module (24 V DC) |
| DO620 3BHT300051R1 | 32-channel Digital Output Module (24 V DC) |
| AO620 3BHT300055R1 | 8-channel Analog Output Module |
| AI620 3BHT300036R1 | 8-channel Analog Input Module |
| PM861AK01 | Processor Module for ABB Freelance DCS |
Popular ABB Automation Modules
| モデル Number | 説明 |
|---|---|
| CI854AK01 | PROFIBUS DP Interface Module for AC800M |
| CI860K01 | MasterBus 300 Communication Interface |
| AI810 | Analog Input Module (S800 I/O) |
| DO810 | Digital Output Module (S800 I/O) |
| CI871K01 | Ethernet/IP Adapter for System 800xA |
| PM865K01 | High-performance CPU Module for System 800xA |
