Product Overview
The ABB CS513 3BSE000435R1 is a communication module used within the ABB Advant Controller 400 Series, specifically designed to facilitate high-performance communication between process controllers and peripheral devices. It enables the integration / various fieldbus systems and I/O networks into ABB’s DCS environments such as Advant Master or System 800xA. Engineered with robust architecture and support for industrial protocols, the CS513 plays a critical role in distributed control system (DCS) networking by enhancing communication reliability and system scalability.
Key Features
-
Seamless integration with ABB Advant Controller 410 and 450 systems
-
サポートs multiple communication protocols such as MODBUS, Advant Fieldbus 100 (AF100)
-
High data throughput for real-time process communication
-
Compact module form factor for space-saving control cabinets
-
Plug-and-play capability with automated system configuration
-
Diagnostic LEDs for communication and operational status
-
Industrial-grade design for high EMI/EMC resistance and environmental endurance
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル Number | CS513 |
| 型番 | 3BSE000435R1 |
| Product Type | Communication Module |
| System Compatibility | Advant Controller 410/450, System 800xA |
| Communication Protocols | Advant Fieldbus 100, MODBUS, MasterBus 300 |
| Data Transmission | High-speed serial communication (fieldbus and network) |
| Power Supply | Supplied via controller backplane |
| Status Indicators | LED indicators for communication, power, and fault |
| Wiring Interface | Fieldbus terminal connectors and backplane |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Humidity Tolerance | 5%–95% RH (non-condensing) |
| Cooling Method | Passive convection |
| Dimensions | 120 x 80 x 40mm |
| 重量 | 0.5 kg |
| Installation | Plug-in module for Advant Controller rack |
| Certifications | CE, RoHS, IEC 61131-2 compliant |
Industry Applications
The ABB CS513 is widely used in process automation systems across industries where high-performance distributed control is critical:
-
Oil & Gas – Pipeline automation, compressor station control
-
Power Generation – Turbine and auxiliary systems communication
-
Pulp & Paper – Real-time data networking between PLCs and I/O racks
-
Chemical Processing – Integration / control networks and fieldbus sensors
-
Water & Wastewater – Communication infrastructure for distributed monitoring
-
Pharmaceuticals – Data acquisition and remote equipment networking
Product Advantages
-
Protocol Versatility – サポートs multiple industrial communication standards
-
Integration-Ready – Designed for use in ABB’s proven control system architectures
-
Space-Saving Design – Compact footprint for easy rack integration
-
Long Lifecycle – Stable supply and service from ABB with long-term availability
-
Diagnostic Capabilities – LED feedback simplifies troubleshooting and maintenance
-
Proven Reliability – Industrial-grade design ensures continuous, uninterrupted operation
よくある質問 (FAQ)
-
What is the main function / the CS513 module?
It provides communication capabilities between controllers and field devices over industrial protocols. -
Which control systems support the CS513 module?
It is compatible with ABB Advant Controller 410/450 systems and integrates into System 800xA. -
Does it support MODBUS communication?
Yes, it supports MODBUS and Advant Fieldbus 100 (AF100). -
How is the CS513 powered?
It is powered via the controller backplane, no separate external power supply is needed. -
Can the CS513 be hot-swapped?
No, the system must be powered down before removing or inserting the module. -
What type / diagnostic indicators are available?
LED indicators display power, communication, and fault status. -
Is this module suitable for outdoor installations?
No, it should be installed in a protected, indoor control cabinet. -
Is CS513 backward compatible with older systems?
Yes, it supports legacy Advant systems while integrating with modern ABB platforms. -
Can this module be used in redundant configurations?
Redundancy is supported when integrated with redundant controller architectures. -
What is the typical lifecycle / the CS513 module?
ABB provides long-term support, typically over 10+ years for industrial-grade modules.
