Product Overview
The ABB CP410M 1SBP260181R1001 Control Panel is a compact, user-friendly operator interface designed for use with ABB low-voltage variable speed drives, particularly the ACS355 and ACS310 series. This panel provides a convenient method for configuring, monitoring, and controlling drive parameters without the need for additional programming tools or a laptop.
Featuring an intuitive interface with a bright backlit display and s/t-touch membrane keys, the CP410M makes it easy for operators and maintenance personnel to quickly access key drive functions. It allows real-time parameter changes, drive diagnostics, monitoring / process variables, and storage / parameter sets for faster commissioning or replacement / drives.
Engineered to meet the rugged requirements / industrial environments, the CP410M is compact, lightweight, and easy to mount on the drive or remotely via panel mounting accessories. It supports multiple languages and features plug-and-play compatibility with ABB drive families, helping to minimize downtime and speed up system configuration.
製品仕様
| Parameter | Value |
|---|---|
| モデル | CP410M |
| Product Code | 1SBP260181R1001 |
| Product Type | Control Panel / Operator Panel |
| Display Type | Monochrome LCD with backlight |
| Display Resolution | 2-line × 16-character |
| Keys | 6 membrane keys (Start/Stop, Up/Down, Left/Right, Enter) |
| Drive Compatibility | ABB ACS310, ACS355, ACS150, ACS550 |
| サポートed 言語s | Multi-language support |
| Parameter Storage | Up to 3 parameter sets |
| Operating Voltage | Powered by drive (5 VDC) |
| Communication Interface | Panel bus / Drive connector |
| Protection Class (Front) | IP54 (panel-mounted), IP20 (hand-held) |
| Operating Temperature Range | -10 °C to +50 °C |
| Storage Temperature Range | -20 °C to +70 °C |
| Humidity | 5% to 95% RH non-condensing |
| Mounting | Drive-mounted, handheld, or panel-mounted (with optional kit) |
| Certifications | CE, UL, cULus |
| Dimensions (W × H × D) | 173 x 105.5 x 7.8 mm |
| 重量 | 0.37 kg |
| Compliance Standards | EN 61800-5-1, EN 61000-6-4, EN 61000-6-2 |
| Parameter Backup / Restore | サポートed |
Applications
The ABB CP410M Control Panel is widely used in a variety / industrial and commercial settings where low-voltage drives are deployed:
-
Pumping Systems
Easy control and monitoring / pumps in HVAC, water treatment, and irrigation. -
HVAC Applications
Fan and compressor control in ventilation and air conditioning systems. -
Material Handling
Control / conveyor belts, hoists, and automated logistics systems. -
Food & Beverage
Adjustment / motor speeds in production lines and packaging equipment. -
General Industrial Automation
On-site parameter management for machine control systems. -
OEM Equipment
Factory-installed on OEM equipment for drive adjustment and diagnostics.
Product Advantages
-
User-Friendly Interface
Simple operation with s/t-touch keys and clear LCD display. -
Quick Parameter Backup & Restore
Store up to 3 parameter sets for fast commissioning or drive replacement. -
Drive Compatibility
Fully compatible with multiple ABB low-voltage drive families. -
Multi-言語 サポート
Accessible to operators globally. -
Flexible Mounting
Use drive-mounted, handheld, or panel-mounted with an optional kit. -
No External Power Required
Powered directly from the drive (5 VDC), simplifying installation. -
Robust Industrial Design
IP54 rating for front face (when panel mounted), ideal for harsh environments. -
Improved Maintenance
Quick diagnostics and real-time status information reduce downtime. -
Compact & Lightweight
保存s space in crowded control panels. -
Reliable ABB Ecosystem
Designed, built, and supported by ABB for long-term performance.
よくある質問 (FAQ)
-
What drives is the CP410M compatible with?
It works with ABB ACS310, ACS355, ACS150, and ACS550 series drives. -
Does it support parameter backup and restore?
Yes, it can store and restore up to 3 parameter sets. -
Can it be panel-mounted?
Yes, with the optional panel-mounting kit, it achieves IP54 protection. -
Is it powered externally?
No, it draws power directly from the drive via the panel bus. -
What display format does it use?
2-line × 16-character monochrome LCD with backlight. -
Can it be used for troubleshooting?
Yes, it provides diagnostics and alarm display for the drive. -
Does it work in outdoor environments?
It is designed for indoor use. If outdoor use is required, additional protection is recommended. -
What languages are supported?
Multiple languages, configurable via the menu. -
Is it CE certified?
Yes, it meets CE, UL, and cULus standards. -
How is it connected to the drive?
Through the panel bus interface built into the drive.
Related モデルs from the Same Series or カテゴリー
| モデル | Product Type | Compatibility | Dimensions (W×H×D) | 重量 |
|---|---|---|---|---|
| CP410M 1SBP260181R1001 | Control Panel | ACS310, ACS355, ACS150 | 70×120×25 mm | 0.20 kg |
| CP410L 1SBP260181R2001 | Basic Control Panel | ACS310, ACS355 | 70×120×25 mm | 0.20 kg |
| CP600-ECO | Advanced HMI Panel | ACS800, ACS880 | 320×240×50 mm | 1.8 kg |
| CP600-Pro (CP620) | Premium HMI Touch Panel | ACS800, ACS880, PLCs | 220×150×50 mm | 1.2 kg |
| RPBA-01 Fieldbus Adapter | PROFIBUS Adapter | ACS310, ACS550, ACS800 | 100×140×25 mm | 0.25 kg |
| RETA-01 Ethernet Adapter | Ethernet TCP/IP Adapter | ACS355, ACS550, ACS880 | 100×140×25 mm | 0.25 kg |
Popular モデルs from ABB Product Line
| モデル | Product Type | Application Area | Dimensions (W×H×D) | 重量 |
|---|---|---|---|---|
| ACS880-01-045A-3 | Industrial Drive | General purpose motor control | 300×500×300 mm | 25 kg |
| ACS800-U1-0450-5+N7501 | Industrial Drive | Heavy-duty industry | 550×750×300 mm | 75 kg |
| ACS580-01-075A-4 | Industrial Drive | HVAC, pumps, general industry | 350×450×280 mm | 35 kg |
| CP600-Pro (CP620) | HMI Panel | Operator interface | 220×150×50 mm | 1.2 kg |
| RPBA-01 | PROFIBUS Adapter | ABB drives | 100×140×25 mm | 0.25 kg |
| RETA-01 | Ethernet Adapter | ABB drives | 100×140×25 mm | 0.25 kg |
