Product Overview
The ABB 3HNM00272-1 Clear Sensor is a high-precision optical detection device commonly used in ABB robotic systems and automation solutions. Designed to detect transparent or semi-transparent objects (like glass or plastic films), it ensures reliable signal acquisition even in complex light conditions.
This clear sensor is particularly useful in applications where conventional photoelectric sensors struggle, such as packaging, bottling, and semiconductor assembly. Its compact form, quick response time, and robust design make it ideal for high-speed industrial processes requiring transparent object detection.
Key Features
-
Optimized for transparent object detection (e.g., glass, film, PET bottles)
-
Fast response time for high-speed automation tasks
-
Compact and lightweight for easy integration
-
Stable detection even with varying background and lighting conditions
-
Simple alignment and calibration
-
LED status indicators for active sensing feedback
-
Long service life with industrial-grade durability
-
Designed for ABB robotics and automated production lines
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Clear (Transparent Object) Sensor |
| モデル Number | 3HNM00272-1 |
| Detection Method | Optical – Through-beam or reflex (depending on configuration) |
| Sensing Range | Typically 10–100 mm (adjustable) |
| Response Time | <1 ms |
| Output Type | PNP/NPN configurable or relay output |
| Operating Voltage | 10–30 VDC |
| Current Consumption | <25 mA |
| Output Current | Max. 100 mA |
| Indicators | LED for power and detection status |
| Connection Type | M8 or M12 connector / cable lead |
| Enclosure Material | Industrial-grade plastic or metal (depending on version) |
| Operating Temperature | -10°C to +55°C |
| Protection Rating | IP67 |
| Dimensions | 200 x 150 x 80 mm |
| 重量 | 1.2 kg |
| Mounting Style | Side-mount with bracket or flush-mount (optional) |
Industry Applications
-
Glass manufacturing – Detecting transparent sheets and panels
-
Bottling lines – Monitoring presence / plastic/glass bottles
-
Semiconductor production – Handling wafer trays or clear carriers
-
Packaging – Detecting clear wrapping films or containers
-
Pharmaceutical – Vial and ampoule detection
-
Robotics – Object sensing for ABB robotic arms in pick-and-place tasks
Advantages
-
優良 performance on transparent targets
-
Compact and versatile design suitable for tight spaces
-
Reliable operation in dusty or reflective environments
-
Reduces false triggers compared to standard photoelectric sensors
-
Improves process uptime through precise detection
-
Plug-and-play compatibility with ABB robotic control 台s
-
Low maintenance requirements and high durability
よくある質問 (FAQ)
-
What is the ABB 3HNM00272-1 used for?
It is used to detect transparent or translucent objects such as plastic bottles or glass sheets. -
Is this sensor compatible with ABB robots?
Yes, it is designed for integration with ABB robotic systems. -
Can it detect colored glass or tinted plastic?
Yes, as long as the object allows sufficient light transmission. -
Does the sensor support both PNP and NPN outputs?
Yes, depending on the model variant, it may support PNP or NPN configuration. -
What is the response time / the sensor?
It typically responds in under 1 millisecond. -
What is the recommended mounting method?
It can be mounted via side brackets or embedded using flush-mount accessories. -
Is the sensor resistant to water and dust?
Yes, it is IP67 rated for use in harsh industrial environments. -
Does it require special calibration?
Only initial alignment is required; some models /fer auto-tuning features. -
Can it detect multiple layers / transparent material?
It can, but performance may vary depending on thickness and reflectivity. -
How is it powered?
It operates on 10–30 VDC, compatible with most industrial control systems.
