製品紹介
The ABB 1MRK000284-ABr03 is a versatile binary input/output module designed for integration within ABB’s industrial automation systems, particularly the Relion® relay family. This module is engineered to monitor and control binary signals from external devices such as pushbuttons, switches, and sensors, playing a crucial role in protection and control systems across various industrial applications. Its robust design and advanced features ensure reliable performance in demanding environments.
Technical Specifications
| Specification | Details |
|---|---|
| メーカー | ABB |
| モデル Number | 1MRK000284-ABr03 |
| Product Type | Binary Input/Output Module |
| Number / Inputs | 24 |
| Input Voltage Range | 24 VDC to 250 VAC |
| Input Current | 2 mA maximum |
| Input Isolation | Optically isolated inputs to protect against electrical noise and transients |
| Input Delay | Configurable from 0 ms to 30 seconds |
| Status Indicators | LED status indication for each input |
| Operating Temperature Range | -20°C to +55°C |
| Storage Temperature Range | -40°C to +70°C |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Dimensions (H x W x D) | 85 x 35 x 25 mm |
| 重量 | 0.1 kg |
| Mounting | DIN rail mounting |
| Compliance | CE, UL, CSA certifications |
Applications
The ABB 1MRK000284-ABr03 module is suitable for a wide range / industrial applications, including:
- Industrial Control Systems: Monitors and controls binary signals from various field devices, ensuring efficient operation / industrial processes.
- Building Automation Systems: Integrates with building management systems to monitor and control lighting, HVAC, and security systems.
- Power Distribution Systems: Ensures the reliability and safety / electrical distribution by monitoring critical binary signals.
- Machine Safety Systems: Monitors safety interlocks and emergency stop signals to maintain safe operating conditions.
Advantages
- High Input Density: Offers 24 binary inputs in a compact module, optimizing space utilization in control panels.
- Optical Isolation: Each input is optically isolated, providing robust protection against electrical noise and transients, enhancing system reliability.
- Configurable Input Delay: Allows customization / input response times to suit specific application requirements, improving system flexibility.
- LED Status Indicators: Each input channel features an LED indicator, facilitating easy monitoring and troubleshooting.
- Wide Operating Voltage Range: Compatible with a broad range / input voltages (24 VDC to 250 VAC), increasing versatility across different applications.
- Robust Environmental Tolerance: Designed to operate in harsh conditions, with a wide operating temperature range and high humidity tolerance.
- Compact Design: Its small footprint allows for efficient use / space in control cabinets, making it ideal for installations with limited space.
- Compliance with International Standards: Adheres to CE, UL, and CSA certifications, ensuring global applicability and adherence to safety standards.
よくある質問 (FAQs)
-
What is the primary function / the ABB 1MRK000284-ABr03 module?
- It serves as a binary input/output module designed to monitor and control binary signals from external devices within industrial automation systems.
-
Which ABB systems are compatible with this module?
- It is compatible with ABB’s Relion® relay family and other industrial automation systems that support binary input modules.
-
What types / signals can this module monitor?
- It can monitor binary signals from devices such as pushbuttons, switches, and sensors within the specified voltage range.
-
How does optical isolation benefit the module’s performance?
- Optical isolation protects the module from electrical noise and transients, enhancing signal integrity and system reliability.
-
Is the input delay configurable?
- Yes, the input delay is configurable from 0 ms to 30 seconds, allowing customization based on application needs.
-
What environmental conditions can the module withstand?
- It operates effectively within a temperature range / -20°C to +55°C and can be stored between -40°C to +70°C, with a humidity tolerance / 5% to 95% non-condensing.
-
Does the module provide status indicators for each input?
- Yes, each input channel has an LED indicator for real-time status monitoring.
-
What are the dimensions and weight / the module?
- The module measures 85 x 35 x 25 mm, with a weight / 0.1 kg.
-
How is the module mounted within a control system?
- It is designed for DIN rail mounting, facilitating easy integration into standard control panels.
-
Does the module comply with international safety standards?
- Yes, it holds CE, UL, and CSA certifications, ensuring compliance with international safety and performance standards.
Related モデルs
| モデル Number | 説明 | Key Features |
|---|---|---|
| ABB 1MRK000284-ABr02 | Binary Input/Output Module | Similar to ABr03 with minor variations in input specs |
| ABB 1MRK000284-ABr01 | Binary Input/Output Module | Earlier version with fewer input options |
| ABB 1MRK000285-ABr03 | Advanced Binary Input/Output Module | Higher input density and improved isolation |
| ABB 1MRK000286-ABr03 | High-Speed Binary I/O Module | Designed for applications requiring faster response |
| ABB REF615 | Feeder Protection Relay with Binary I/O | Integrated protection relay with binary I/O support |
| ABB 1MRK000287-ABr03 | Multi-Channel Binary Input Module | Expanded input channels for complex automation |
| ABB 1MRK000288-ABr03 | High-Reliability Binary Output Module | Designed for critical safety applications |
| ABB 1MRK000289-ABr03 | Digital Input Module for Industrial Automation | Optimized for industrial control systems |
Popular モデルs
| モデル Number | 説明 | Key Features |
|---|---|---|
| ABB 07KT98 GJR5253100R0270 | Central Processing ユニット for ABB Control Systems | High-performance CPU for ABB automation |
| ABB REF620 | Protection Relay with Binary I/O | Advanced protection relay with multiple I/O |
| ABB 1MRK000570-ABr02 | Analog Input/Output Module | Used in industrial process control |
| ABB RTU560 | Remote Terminal ユニット for Substations | Integrated remote monitoring and control |
| ABB 07AC91 | Analog Output Module | Provides precision control / analog signals |
| ABB REX640 | Multifunction Protection Relay | サポートs various protection and control functions |
| ABB 07KT97 GJR5253000R0270 | Control Module for ABB PLC Systems | Used in distributed automation |
| ABB IED670 | Intelligent Electronic Device for Grid Protection | Designed for high-voltage substation applications |
