Product Overview
The Yokogawa ALE111-S51-S1 Ethernet Module is a high-performance communication interface designed to connect Yokogawa Field Control Stations (FCS) with Ethernet-based subsystems. This module enables reliable and efficient data exchange using standard industrial Ethernet protocols, ensuring seamless integration across process control, safety, and automation systems.
Optimized for industrial environments, the ALE111-S51-S1 supports point-to-point half-duplex communication, delivering robust and stable network connectivity. Its compact design allows easy rack mounting within Yokogawa control system architectures, facilitating flexible and scalable system expansion.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modèle Number | ALE111-S51-S1 |
| Module Type | Ethernet Communication Module |
| Communication Protocols | Modbus Slave, DNP3 Slave, Yokogawa Subsystem Communication |
| Network Speed | 10 Mbps |
| Transmission Method | Half-duplex |
| Connector Type | RJ-45 |
| Cable Type | 100-ohm unshielded twisted pair (UTP) |
| Maximum Transmission Distance | Up to 100 meters per segment |
| Operating Voltage | 24 V DC nominal |
| Power Consumption | Approximately 0.5 A |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Humidity Range | 10% to 90% non-condensing |
| Dimensions | 150 x 30 x 180 mm |
| Poids | 0.3 kg |
| Mounting | Rack-mounted within Yokogawa control system racks |
| Safety Certifications | Complies with ISA Standard G3 and EMC standards |
Applications
-
Integration sur Yokogawa Field Control Stations with Ethernet-based subsystems
-
Real-time communication in process automation and control systems
-
Data acquisition and control in SCADA and safety systems
-
Industrial automation in chemical, power, and manufacturing plants
-
Enhancing interoperability and network scalability in complex control environments
Advantages
-
Reliable Ethernet Communication: Supports Modbus Slave, DNP3 Slave, and Yokogawa subsystem protocols for versatile connectivity.
-
Robust Industrial Design: Built to withstand harsh environmental conditions with stable network performance.
-
Flexible Installation: Rack-mount form factor allows easy integration into existing Yokogawa control systems.
-
Compact and Lightweight: Small footprint with only 0.3 kg weight facilitates system design flexibility.
-
Extended Transmission Distance: Supports cable lengths up to 100 meters per segment with standard UTP cables.
-
Compliance with Standards: Meets ISA Standard G3 and electromagnetic compatibility (EMC) requirements ensuring safety and reliability.
Questions fréquentes (FAQ)
-
What communication protocols does the ALE111-S51-S1 support?
It supports Modbus Slave, DNP3 Slave, and Yokogawa subsystem communication protocols. -
What is the maximum network speed supported?
The module supports 10 Mbps Ethernet communication. -
What is the maximum cable length for Ethernet connections?
Up to 100 meters per segment using 100-ohm UTP cables. -
How is the module mounted?
It is designed for rack mounting within Yokogawa control system racks. -
What are the operating temperature limits?
The module operates between 0°C and 55°C. -
What power supply voltage does the module require?
It requires a nominal 24 V DC power supply. -
Is the module suitable for industrial environments?
Yes, it is built to meet ISA Standard G3 and EMC standards for industrial use. -
What is the weight and size sur the module?
The module weighs approximately 0.3 kg and measures 150 mm x 30 mm x 180 mm. -
Can the module integrate with Yokogawa Field Control Stations?
Yes, it is specifically designed for seamless integration with Yokogawa FCS systems. -
Does the module support redundant communication paths?
The module features two DeviceNet ports allowing for network expansion and redundancy.
