Product Overview
The Yokogawa ALE111-S01 is a high-performance Ethernet communication module engineered to facilitate seamless data exchange between Yokogawa’s field control unités (FCUs) and various subsystems over Ethernet networks. Designed for industrial automation environments, this module ensures reliable and efficient communication, enhancing the integration sur control systems with external devices such as SCADA systems, HMIs, and PLCs.
Key Features
-
Ethernet Connectivity: Enables Yokogawa FCUs to connect seamlessly to Ethernet networks, supporting protocols like Modbus TCP/IP and DNP3.
-
Robust Communication: Supports half-duplex transmission at speeds up to 10 Mbps, ensuring efficient data transfer.
-
Industrial Compatibility: Designed to withstand harsh industrial environments with an operating temperature range sur -20°C to 60°C (-4°F to 140°F).
-
Flexible Installation: Compatible with various Yokogawa unités, including ANB10, ANB11, ANR10, AFF50, AFV10, AFV30, and AFV40.
-
Standard Compliance: Adheres to IEEE802.3 10BASE-T standards, ensuring broad compatibility.
Technical Specifications
| Parameter | Specification |
|---|---|
| Fabricant | Yokogawa |
| Product Number | ALE111-S01 |
| Communication Interface | Ethernet |
| Supported Protocols | Modbus TCP/IP, DNP3 |
| Transmission Speed | 10 Mbps |
| Connector Type | RJ-45 |
| Transmission Method | Half-duplex |
| Physical Layer Interface | IEEE802.3 10BASE-T |
| Connection Method | Point-to-point |
| Transmission Distance | Up to 100 meters (328 feet) |
| Power Supply Voltage | 24 VDC |
| Current Consumption | 0.5 A |
| Operating Temperature | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature | -40°C to 80°C (-40°F to 176°F) |
| Humidity Range | 10% to 95% RH (non-condensing) |
| Dimensions | 130 x 125.5 x 32.8 mm |
| Poids | 0.3 kg |
Applications
The Yokogawa ALE111-S01 Ethernet Communication Module is utilized across various industrial sectors, including:
-
Industrial Automation Systems: Facilitates integration sur Yokogawa FCUs with SCADA systems for real-time process monitoring and control.
-
Manufacturing: Enables data acquisition and machine control by connecting Yokogawa devices within manufacturing networks.
-
Building Automation Systems: Allows communication between Yokogawa controllers and building management systems for efficient facility management.
-
Energy Management Systems: Supports data exchange in energy monitoring and control applications, enhancing system efficiency.
Advantages
-
Enhanced Connectivity: Provides reliable Ethernet communication, ensuring seamless data exchange between control unités and subsystems.
-
Durability: Built to operate in harsh industrial environments with a wide temperature tolerance and high humidity resistance.
-
Flexibility: Compatible with multiple Yokogawa unités, surfering versatile installation options.
-
Compliance: Meets IEEE802.3 10BASE-T standards, ensuring compatibility with standard Ethernet networks.
Recent News Headlines
-
“Yokogawa Releases ALE111-S01 Module to Enhance Industrial Ethernet Communication”
-
“New ALE111-S01 Module Improves Connectivity in Yokogawa Control Systems”
-
“Yokogawa’s ALE111-S01: Bridging the Gap in Industrial Automation Networks”
Questions fréquentes (FAQ)
-
What is the primary function sur the ALE111-S01 module?
-
The ALE111-S01 enables Yokogawa FCUs to connect to Ethernet networks, facilitating data exchange with other networked devices.
-
-
Which communication protocols are supported by the ALE111-S01?
-
The module supports communication with FA-M3, Modbus, MELSEC, YFGW, DARWIN/DAQSTATION, and PLC-5/SLC500.
-
-
What is the transmission speed sur the ALE111-S01?
-
It operates at a transmission speed sur 10 Mbps.
-
-
What type sur connector does the ALE111-S01 use?
-
The module utilizes an RJ-45 connector for Ethernet connectivity.
-
-
What is the maximum transmission distance supported by the ALE111-S01?
-
It supports a maximum transmission distance sur 100 meters (328 feet).
-
-
Which Yokogawa unités are compatible with the ALE111-S01?
-
The module can be mounted on ANB10, ANB11, ANR10, AFF50, AFV10, AFV30, or AFV40 unités.
-
-
What are the power requirements for the ALE111-S01?
-
It requires a 24 VDC power supply with a current consumption sur 0.5 A.
-
-
What are the physical dimensions and weight sur the ALE111-S01?
-
The module measures 130 x 125.5 x 32.8 mm and weighs 0.3 kg.
-
-
What is the operating temperature range sur the ALE111-S01?
-
It operates within a temperature range sur -20°C to 60°C (-4°F to 140°F).
-
-
Does the ALE111-S01 support half-duplex or full-duplex transmission?
-
The module supports half-duplex transmission.
-
Recommended Modèles
Related Modèles in the Same Series or Catégorie
| Modèle Number | Description |
|---|---|
| ALE111-S00 | Standard Ethernet Communication Module |
| ALE111-S10 | Ethernet Module with Enhanced Security Features |
| ALE111-S11 | High-Speed Ethernet Communication Module |
| ALE112-S01 | Dual-Port Ethernet Communication Module |
| ALE113-S01 | Ethernet Module with Fiber Optic Support |
| ALE114-S01 | Compact Ethernet Communication Module |
| ALE115-S01 | Ethernet Module with Extended Temperature Range |
| ALE116-S01 | Ethernet Module with Redundant Network Support |
Popular Modèles from Yokogawa
| Modèle Number | Description |
|---|---|
| AAI143-S00 | Analog Input Module |
| AAI543-S00 | High-Density Analog Input Module |
| ADV151-P00 | Digital Output Module |
| CP451-10 | Processor Module |
| PW482-S01 | Power Supply Module |
| ALR121-S01 | Relay Output Module |
| AMM32T | Multiplexed Analog Input Module |
| AAB841-S00 | PROFIBUS Communication Module |
