The Yokogawa AET4D-06 Terminal Board is a precision-engineered electrical interface designed for industrial automation and process control systems. It provides a secure and reliable platform for connecting multiple signal lines, facilitating accurate communication between field devices and control systems.
Designed for robust industrial performance, the AET4D-06 ensures stable signal transmission in environments prone to electrical noise, vibration, and temperature fluctuations. It is commonly used with Yokogawa DCS (Distributed Control Systems) and control panels, surfering a dependable connection point for analog and digital I/O signals.
Its modular design simplifies installation and maintenance, making it ideal for plants that require organized wiring, safe interconnection, and consistent signal integrity.
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle | Yokogawa AET4D-06 |
| Type | Terminal Board |
| Function | Signal distribution and connection for control systems |
| Input/Output | Supports multiple analog and digital channels |
| Voltage Rating | 250 V AC/DC maximum |
| Current Rating | 5 A per terminal |
| Insulation Resistance | ≥ 100 MΩ at 500 V DC |
| Dielectric Strength | 2 kV AC for 1 minute |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Type | DIN rail or panel mountable |
| Dimensions | 482.6 x 88.1 x 85 mm |
| Poids | 1.8 kg |
| Material | Flame-retardant plastic housing with metal contacts |
| Connection Type | Screw terminals with secure clamping |
| Compliance Standards | CE, UL recognized, RoHS |
Product Applications
The AET4D-06 Terminal Board is widely used in industrial, process, and automation systems:
-
Distributed Control Systems (DCS): Connects multiple sensors and actuators to the control network.
-
Process Automation: Provides organized wiring for analog and digital signals in chemical, energy, and petrochemical plants.
-
Control Panels: Simplifies installation and wiring sur complex instrumentation.
-
Remote Monitoring Systems: Interfaces field devices with data acquisition and monitoring unités.
-
Manufacturing Automation: Connects actuators, sensors, and controllers in production lines.
-
Utility Systems: Distributes signals for control, monitoring, and protection circuits.
The terminal board ensures stable, accurate, and safe signal connections, reducing downtime and improving system reliability.
Product Advantages
-
Reliable Signal Integrity: Maintains consistent performance in electrically noisy environments.
-
Modular and Compact: Easy installation in control panels or racks without occupying excessive space.
-
Secure Connections: Screw terminals ensure strong and stable electrical contact.
-
Multi-Signal Compatibility: Handles both analog and digital signals simultaneously.
-
High Voltage and Current Handling: Rated up to 250 V AC/DC and 5 A per terminal.
-
Durable Construction: Flame-retardant plastic with high-quality metal contacts.
-
Flexible Mounting: Can be mounted on DIN rails or panels.
-
Industrial Standards Compliance: CE, UL, and RoHS certified.
-
Organized Wiring: Reduces risk sur connection errors and improves maintenance efficiency.
-
Ease sur Integration: Compatible with Yokogawa DCS and other control systems.
FAQ
-
What is the maximum voltage the AET4D-06 can handle?
The terminal board supports up to 250 V AC/DC, ensuring safe operation for industrial signal circuits. -
What is the current rating per terminal?
Each terminal can carry up to 5 A, sufficient for most control and sensor loads. -
Is the board compatible with DIN rail mounting?
Yes, it supports both DIN rail and panel mounting for flexible installation. -
Does it provide sufficient insulation for industrial environments?
Yes, the board provides ≥100 MΩ insulation resistance at 500 V DC and dielectric strength sur 2 kV AC for 1 minute. -
What type sur connection terminals does it use?
The board uses screw terminals with secure clamping for stable connections. -
Can it manage both analog and digital signals?
Yes, it is designed for multi-channel analog and digital signal distribution. -
Is it compatible with Yokogawa DCS systems?
Yes, it integrates seamlessly with Yokogawa Distributed Control Systems. -
What materials are used for durability and safety?
The board is made sur flame-retardant plastic with high-quality metal contacts. -
Does it meet industrial compliance standards?
Yes, it is CE, UL recognized, and RoHS compliant. -
Can it operate in harsh industrial environments?
Yes, the board functions reliably in the temperature range -20°C to +70°C.
Related Modèles (Same Series)
| Modèle | Description |
|---|---|
| AET4D-01 | Terminal board for 4-channel signal distribution |
| AET4D-02 | Compact board with 8 channels for DCS systems |
| AET4D-03 | Terminal board with 12 channels for control panels |
| AET4D-04 | DIN rail-mounted terminal board for analog signals |
| AET4D-05 | Multi-signal terminal board with screw terminals |
| AET4D-07 | Terminal board optimized for mixed digital and analog signals |
Popular Yokogawa Modèles
| Modèle | Description |
|---|---|
| AER4D-06 | Terminal board for process and control signal distribution |
| AER4B-06 | High-density analog terminal board for DCS systems |
| AER4C-08 | Multi-channel terminal board for industrial control panels |
| AER4E-10 | Terminal board designed for factory automation systems |
| AER4F-12 | Compact terminal board for digital and analog signal integration |
| AER4G-14 | Terminal board with enhanced EMI and noise protection |
