Présentation du produit
The Yokogawa ADV151-E00 S2 is a Digital Input Module designed for integration within the CENTUM VP and ProSafe-RS distributed control systems (DCS and SIS). This module plays a critical role in receiving discrete signals from field devices such as limit switches, pushbuttons, and proximity sensors. With a high level sur reliability, rapid response times, and robust diagnostics, the ADV151-E00 S2 is engineered to perform seamlessly in mission-critical industrial applications such as petrochemical, power generation, water treatment, and pharmaceutical industries.
Built to meet the rigorous standards sur modern industrial automation, the ADV151-E00 S2 provides 16 digital input channels with electrical isolation and fail-safe design, ensuring both performance and safety in harsh environments. It’s widely appreciated for its plug-in design that simplifies installation and maintenance while maintaining operational continuity.
Spécifications du produit
| Parameter | Description |
|---|---|
| Modèle | ADV151-E00 S2 |
| Fabricant | Yokogawa Electric Corporation |
| Product Type | Digital Input Module |
| Number sur Channels | 16 Digital Inputs |
| Input Type | Voltage (dry contact or open collector) |
| Input Voltage Range | 24 V DC nominal (range: 18–32 V DC) |
| Input Impedance | Approx. 4.7 kΩ |
| Signal ON Threshold | 15 V DC or more |
| Signal OFF Threshold | 5 V DC or less |
| Isolation | Optical isolation per channel |
| Power Consumption | Approx. 3.5 W |
| Response Time | < 5 ms |
| Self-diagnosis | Supported (loop check, channel test, etc.) |
| Hot Swap Capability | Yes |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -20 to 70°C (-4 to 158°F) |
| Relative Humidity | 5 to 95% RH (non-condensing) |
| Shock Resistance | 10 m/s², 3 times in each direction |
| Mounting | Mounted on terminal base unité |
| Dimensions | 107.5 × 130 × 32.8 mm |
| Poids | 0.3 kg |
| Certifications | CE, KC, ATEX (depending on region/configuration) |
Applications
-
Petrochemical Plants: Interfaces with limit switches and emergency shutdown buttons in hazardous environments.
-
Power Generation: Receives digital signals for monitoring turbine and generator protection schemes.
-
Water & Wastewater Treatment: Integrates with PLCs and sensors for automated gate control and pump management.
-
Pharmaceutical Industry: Ensures reliable digital input monitoring in cleanroom-controlled batch process systems.
-
Food & Beverage: Integrates with factory automation control panels for consistent signal input detection.
-
Marine & Offshore Platforms: Offers rugged and dependable digital signal monitoring under high-vibration and corrosive conditions.
Advantages
-
High Channel Density: Supports 16 inputs per module, reducing overall cabinet space and cost.
-
Robust Signal Isolation: Each input is optically isolated, minimizing electrical noise and improving safety.
-
Flexible Configuration: Can be used with both dry contact and open-collector inputs, supporting varied field device types.
-
Hot Swappable Design: Enhances uptime by allowing maintenance without halting system operation.
-
Integrated Diagnostics: Built-in loop and signal test functions reduce commissioning time and simplify troubleshooting.
-
Long Service Life: Designed for industrial environments with extended operational reliability.
-
Safety-Certified: Disponible with variants conforming to SIL2/SIL3 (when used with ProSafe-RS systems).
-
Global Compliance: Conforms to CE, KC, and ATEX standards, suitable for deployment in regulated sectors.
-
Low Power Consumption: Energy-efficient operation that supports sustainable system design.
-
Seamless Integration: Compatible with Yokogawa’s STARDOM, CENTUM VP, and ProSafe-RS platforms.
Questions fréquentes (FAQ)
-
What type sur signals can the ADV151-E00 S2 accept?
It supports dry contact and open collector signals with a nominal input sur 24 V DC. -
How many channels are available on this module?
The ADV151-E00 S2 provides 16 isolated digital input channels. -
Is it compatible with ProSafe-RS systems?
Yes, it is fully compatible with Yokogawa’s ProSafe-RS Safety Instrumented Systems. -
Can the module be replaced without shutting down the system?
Yes, it supports hot swapping, allowing for maintenance without disrupting the operation. -
What diagnostics are available?
The module includes loop check and channel test functions to aid commissioning and maintenance. -
Is the module suitable for SIL-rated applications?
Yes, when used with certified systems, it can support SIL2 and SIL3 safety levels. -
What’s the installation method?
It is installed via terminal base unités that connect to the main system rack. -
What is the typical response time sur input detection?
Less than 5 milliseconds for accurate and fast signal processing. -
What environments can it operate in?
Designed for industrial environments, it operates from 0°C to 60°C with high humidity tolerance. -
Does it come with international certifications?
Yes, depending on configuration, it can be CE-marked, ATEX-certified, and KC-compliant.
