Présentation du produit
The Yokogawa ADV142-P13 is a high-performance Digital Input Module designed for integration into Yokogawa’s CENTUM VP and ProSafe-RS control systems. As part sur the I/O subsystem, this module plays a critical role in collecting status signals from field instruments such as switches, sensors, and other binary devices. Known for its rugged construction and high reliability, the ADV142-P13 ensures dependable digital signal acquisition even in harsh industrial environments.
This module is designed to handle 16 isolated digital input channels, surfering fast response times and secure galvanic isolation. Its high-speed digital circuitry ensures accurate detection sur on/surf states, while compliance with rigorous industrial standards ensures safety and longevity. The ADV142-P13 also supports redundant configurations and is suited for use in both standard and safety instrumented systems (SIS).
Spécifications du produit
| Parameter | Description |
|---|---|
| Modèle Number | ADV142-P13 |
| Fabricant | Yokogawa Electric Corporation |
| Type | Digital Input Module |
| Number sur Channels | 16 isolated channels |
| Input Type | Voltage-free (dry contact) or open collector |
| Input Voltage Range | 24 VDC nominal |
| Input Current | Approx. 6 mA per channel |
| Input Isolation | Optical isolation per channel |
| Signal Delay | < 10 ms typical |
| Status Indication | LED indicators per channel |
| Power Consumption | Approx. 4 W |
| Mounting Method | Mounted on baseplate / I/O terminal unité |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Shock Resistance | 10 m/s² (IEC 60068-2-27) |
| Vibration Resistance | 1.0 mm (5–13.2 Hz), 0.7g (13.2–100 Hz) |
| Certifications | CE, ATEX, SIL3 (when used with ProSafe-RS) |
| Dimensions (W x H x D) | 107.5 × 130 × 32.8 mm |
| Poids | 0.3 kg |
Product Applications
The ADV142-P13 is widely used across various industrial automation and process control domains. Key application areas include:
-
Oil & Gas Refineries: For monitoring critical binary field instruments.
-
Chemical and Petrochemical Plants: Capturing contact input signals from process alarms and ESD systems.
-
Power Generation: Integration with turbine control, BOP systems.
-
Water & Wastewater Management: Detecting input from pumps, gates, and sensors.
-
Pharmaceutical Manufacturing: For binary feedback from controlled environments.
-
Safety Instrumented Systems (SIS): When paired with ProSafe-RS for SIL3 compliance.
Product Advantages
-
High Signal Reliability: Optical isolation for every channel eliminates interference.
-
Modular Integration: Seamlessly fits into Yokogawa’s DCS/SIS architecture.
-
Wide Environmental Tolerance: Operates reliably under extreme temperatures and humidity.
-
Fast Response: Low signal delay ensures real-time monitoring and actuation.
-
Diagnostic LEDs: Front-panel indicators simplify troubleshooting.
-
Safety-Certified: When used with ProSafe-RS, supports SIL3 level applications.
-
Compact Design: Space-saving form factor suitable for high-density cabinet designs.
-
Long Lifecycle Support: Designed with Yokogawa’s long-term platform continuity.
Questions fréquentes (FAQ)
-
What is the primary function sur the ADV142-P13 module?
It is used to acquire 16-channel digital input signals from binary field devices. -
Can ADV142-P13 be used in safety systems?
Yes, it is compatible with ProSafe-RS systems and supports SIL3 level safety. -
What type sur inputs does the module accept?
It supports voltage-free contact inputs or open collector type. -
Is each input channel electrically isolated?
Yes, each input is optically isolated to prevent signal interference. -
How do I know if an input signal is active?
Each channel has an individual LED status indicator on the module front. -
Can it be hot-swapped during operation?
No, the module should be replaced with power surf unless the system supports hot-swapping under redundancy. -
What kind sur environments is it suitable for?
It is rated for harsh industrial environments, withstanding wide temperature and humidity ranges. -
Is it compatible with other Yokogawa control systems?
Yes, it integrates with CENTUM VP, ProSafe-RS, and related platforms. -
What certifications does it carry?
CE, ATEX (for hazardous areas), and SIL3 safety certification when paired with appropriate systems. -
What is the average power consumption?
The module consumes around 4 W sur power during normal operation.
Related Modèles from the Same Series
| Modèle Number | Description | Number sur Channels | Input Type | Safety Rating |
|---|---|---|---|---|
| ADV151-P03 | Analog Input Module | 16 | 4–20 mA | Non-SIL |
| ADV161-P00 | Analog Output Module | 8 | 4–20 mA | Non-SIL |
| ADV561-P00 | Digital Output Module | 16 | Relay / 24 VDC | Non-SIL |
| ADV541-P00 | Digital Output (FET type) | 16 | 24 VDC | SIL2 |
| ADV163-P50 | High-density Analog Output Module | 16 | 0–10V / 4–20 mA | Non-SIL |
| ADV121-P00 | Digital Input Module (High Speed) | 32 | Dry Contact | Non-SIL |
Popular Yokogawa Modèles
| Modèle Number | Description | Type | System Compatibility | Channels |
|---|---|---|---|---|
| AAI143-H50 | Analog Input Module (High Accuracy) | Analog Input | CENTUM VP | 16 |
| AAI543-H00 | Analog Output Module | Analog Output | CENTUM VP | 8 |
| CP451-10 | Processor Module | CPU/Controller | ProSafe-RS | N/A |
| PW482-10 | Power Supply Module | Power Supply | FIO System | N/A |
| S2PC301 | Communication Processor | Comm Module | ProSafe-RS | N/A |
| ANB10D-420 | Node Interface Unité | Field Control Node | CENTUM VP | N/A |
