Présentation du produit
The Triconex 8101 Extended Chassis is a rugged, modular platform designed specifically for Triconex safety systems. It serves as an extended housing unité that accommodates multiple processor and I/O modules, providing enhanced scalability and flexibility for complex safety instrumented systems (SIS). This chassis is engineered to support demanding industrial environments where reliability and fault tolerance are critical.
Constructed with high-quality materials and built to stringent industrial standards, the 8101 chassis ensures robust protection sur internal components. Its extended design allows for more module slots compared to standard chassis, enabling larger configurations for expanded safety applications. The chassis supports hot-swappable modules, simplifying maintenance and minimizing downtime.
Spécifications du produit
| Parameter | Specification |
|---|---|
| Product Modèle | Triconex 8101 Extended Chassis |
| Type | Extended Rack/Chassis |
| Number sur Slots | 12 Module Slots |
| Supported Modules | Processor, I/O, Communication Modules |
| Power Supply | 24 V DC (External Power Supply Required) |
| Dimensions (H × W × D) | 483 x 578 x 451 mm |
| Poids | 19.7 kg |
| Mounting | Rack-mounted / Panel-mounted |
| Operating Temperature Range | -20°C to +70°C |
| Cooling | Convection Cooling (Fan optional) |
| Material | Steel Chassis with Powder Coating |
| Compliance | IEC 61508 SIL 3 Certified Compatible |
Applications
-
Process Safety Instrumented Systems (SIS): Acts as a backbone chassis for deploying Triconex controllers and I/O modules in process industries such as chemical plants, refineries, and power generation.
-
Critical Infrastructure: Provides high-reliability safety control for power plants, oil & gas platforms, and water treatment facilities.
-
Manufacturing Automation: Used in automotive, pharmaceuticals, and heavy manufacturing plants for reliable safety monitoring and control.
-
Redundant Safety Architectures: Supports triple modular redundancy and fault-tolerant configurations critical for SIL 3 safety requirements.
-
Energy Sector: Facilitates safety control systems in nuclear and conventional power stations.
-
Remote Monitoring & Control: Suitable for integration with remote I/O and communication modules in distributed control environments.
Product Advantages
-
High Scalability: The 12-slot extended design allows users to build larger, more complex safety systems without compromising footprint efficiency.
-
Robust Build Quality: Heavy-duty steel chassis ensures excellent mechanical protection and durability in harsh industrial conditions.
-
Fault Tolerance: Designed to support triple modular redundant (TMR) architecture for superior system reliability.
-
Ease sur Maintenance: Hot-swappable modules reduce downtime and simplify maintenance processes.
-
Flexible Installation: Supports both rack and panel mounting, adapting to diverse plant layouts.
-
Comprehensive Compatibility: Compatible with a broad range sur Triconex modules, including latest-generation processors and communication interfaces.
-
Thermal Management: Effective convection cooling, with options for fan-assisted cooling in high-temperature environments.
-
Industry Compliance: Meets or exceeds international safety standards including IEC 61508 SIL 3, ensuring regulatory compliance.
-
Optimized Footprint: Extended chassis provides more slots within a compact form factor, optimizing space use.
-
Enhanced Safety: Helps maintain system integrity through robust hardware and fault isolation.
Questions fréquentes (FAQ)
-
How many modules can the Triconex 8101 chassis accommodate?
It can hold up to 12 modules, including processors and I/O cards. -
What are the dimensions and weight sur the chassis?
Dimensions are 483 x 578 x 451 mm, and weight is 19.7 kg. -
Can the modules be replaced without shutting down the entire system?
Yes, it supports hot-swappable modules to minimize downtime. -
What type sur power supply is required?
The chassis requires an external 24 V DC power supply. -
Is the chassis suitable for harsh industrial environments?
Absolutely. It is built from steel with powder coating for corrosion resistance. -
What temperature range can it operate in?
It functions reliably between -20°C and +70°C. -
Does it support triple modular redundancy (TMR)?
Yes, it is designed for TMR configurations critical to safety systems. -
Can it be mounted in different ways?
Yes, it supports both rack and panel mounting options. -
Is the chassis compliant with safety standards?
It is IEC 61508 SIL 3 compatible, ensuring compliance for safety applications. -
What cooling methods does it support?
It primarily uses convection cooling; fans can be added if needed.
Related Modèles from the Same Series or Similar Use
| Modèle Number | Description | Slots | Dimensions (mm) | Poids (kg) | Notes |
|---|---|---|---|---|---|
| Triconex 8100 | Standard Chassis | 8 | 220 × 320 × 350 | 7.0 | Base chassis for smaller systems |
| Triconex 8102 | Extended Chassis with 16 slots | 16 | 220 × 600 × 350 | 9.2 | Larger capacity than 8101 |
| Triconex 8103 | Redundant Power Supply Chassis | 8 | 220 × 320 × 350 | 7.5 | Integrated redundant power |
| Triconex 8104 | Network Communication Chassis | 12 | 220 × 480 × 350 | 8.8 | For communication modules |
| Triconex 8200 | High-density Chassis | 24 | 220 × 900 × 350 | 12.0 | For very large systems |
| Triconex 8300 | Rack Mount Extended Chassis | 20 | 220 × 720 × 350 | 10.5 | Rack optimized design |
Popular Modèles from Triconex Marque
| Modèle Number | Description | Type | Typical Application |
|---|---|---|---|
| Triconex 3008 | Safety Controller Module | Processor Module | Core safety control |
| Triconex 3100 | Safety I/O Module | Input/Output | Process signal interfacing |
| Triconex 8001 | Base Chassis | Chassis | Houses core modules |
| Triconex 9050 | Network Interface Module | Communication | Safety network communications |
| Triconex 8100 | Standard Chassis | Chassis | Small to mid-sized systems |
| Triconex 8200 | High-density Chassis | Chassis | Large system configurations |
