Présentation du produit
The Schneider Electric BMXERT1604T is a high-performance Ethernet Remote I/O module designed for use with the Modicon M340 automation platform. As part sur the Modicon X80 I/O system, this module surfers seamless integration for distributed control applications requiring fast, flexible, and reliable digital input capabilities across industrial networks.
Featuring 16 discrete input/output channels, the BMXERT1604T supports deterministic Ethernet communication through Ethernet TCP/IP protocols. This allows real-time data acquisition and communication between field devices and the control system over extended distances. It is optimized for high-speed and time-sensitive operations, making it suitable for advanced automation environments such as manufacturing plants, utility systems, and infrastructure monitoring.
Engineered for DIN rail mounting and compliant with industrial standards, this I/O module provides robust diagnostics, LED indicators per channel, and hot-swap capabilities for maintenance without system downtime.
Spécifications du produit
| Parameter | Details |
|---|---|
| Product Name | BMXERT1604T |
| Product Type | Remote I/O Ethernet Input Module |
| Marque | Schneider Electric |
| Series | Modicon X80 |
| Platform Compatibility | Modicon M340, Modicon X80 |
| Communication Protocol | Ethernet TCP/IP, Modbus TCP |
| Number sur Channels | 16 channels (mixed I/O) |
| Input Type | Discrete (Digital) Inputs |
| Input Voltage | 24 VDC |
| Output Type | Transistor Outputs |
| Output Current (max) | 0.5 A/channel |
| Isolation | Channel-to-bus isolation (galvanic) |
| Diagnostic Features | Per-channel status LEDs, network diagnostics |
| Hot Swap Support | Yes |
| Power Supply Requirement | 24 VDC (±20%) |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
| Operating Temperature Range | -10°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Tolerance | 5% to 95% RH, non-condensing |
| Certifications | CE, UL, CSA, RoHS, EAC |
| Dimensions (W x H x D) | 32 x 100 x 86 mm |
| Poids | 0.454 kg |
Product Applications
The BMXERT1604T is ideal for automation applications that demand modular, decentralized control and Ethernet-based communication. Typical application areas include:
-
Manufacturing Automation: Real-time monitoring and control sur conveyors, sensors, actuators, and safety systems.
-
Water Treatment Plants: Remote data acquisition and diagnostics in distributed water processing unités.
-
Food & Beverage Industry: High-speed packaging line monitoring with input/output signal control.
-
Smart Infrastructure: Reliable I/O data exchange in traffic management and building control systems.
-
Energy Management Systems: Integration sur I/O signals in substations and renewable energy installations.
-
Material Handling Systems: Coordination sur input and output devices for cranes, lifts, and automated warehouses.
Product Advantages
-
Seamless Ethernet Integration: Supports open Ethernet communication, enabling flexible architecture and easy system expansion.
-
High Channel Density: 16 channels in a compact footprint make it ideal for space-constrained panels.
-
Robust Diagnostics: LED indicators provide quick visual feedback on channel and network status.
-
Hot Swappable: Modules can be replaced without shutting down the system—minimizing downtime during maintenance.
-
Durable Design: Industrial-grade housing and electronics ensure performance in harsh environments.
-
Easy Installation: Standard DIN rail mounting simplifies panel design and field setup.
-
Cross-Platform Compatibility: Integrates with Modicon M340 and other Ethernet-compatible controllers.
-
Scalable for Large Systems: Well-suited for scalable systems requiring centralized or distributed I/O.
Questions fréquentes (FAQ)
-
What does the BMXERT1604T actually do in a control system?
It acts as a remote I/O module that reads input signals and sends output signals over Ethernet, making your control system more flexible and distributed. -
Can I connect this module directly to a Modicon M340 CPU?
Yes, it’s fully compatible with Modicon M340 via Ethernet and is designed to operate seamlessly within the same architecture. -
Is this module suitable for fast-response applications?
Absolutely. It’s built for deterministic Ethernet communication, making it well-suited for fast control cycles. -
How do I know if the module is receiving power and signals?
LED indicators on the front panel show power status and I/O activity for each channel, making it easy to diagnose issues. -
Does it support hot-swapping during system operation?
Yes. You can replace the module while the system is running, provided that safety protocols are followed. -
What kind sur output does it support?
It provides transistor-type outputs, good for switching digital devices like lamps, contactors, or valves. -
Can I use this module in environments with high humidity?
Yes, it can tolerate up to 95% relative humidity, as long as there’s no condensation. -
What happens if communication with the CPU is lost?
The module can be configured to go into a safe state or retain its last known output—depending on how you set it up. -
Is there a specific configuration tool for setup?
Yes, you can configure it using EcoStruxure Control Expert (formerly Unitéy Pro), which allows full customization. -
How do I mount this module in my panel?
It snaps onto a standard DIN rail and connects via Ethernet. It’s compact and quick to install.
Related or Same-Series Modèles
| Modèle | Description | Channels | I/O Type | Dimensions (mm) | Poids (g) |
|---|---|---|---|---|---|
| BMXERT0204T | Ethernet I/O Module with 2 In / 4 Out | 6 | Mixed Digital | 32 x 100 x 115 | 260 |
| BMXDDO1602 | Digital Output Module | 16 | Transistor Output | 32 x 100 x 115 | 280 |
| BMXDDI3202K | Digital Input Module | 32 | 24V DC Sink/Source | 64 x 100 x 115 | 350 |
| BMXEAE0300 | Analog Input Module (3 ch.) | 3 | Analog (Voltage) | 32 x 100 x 115 | 270 |
| BMXART0814 | Analog Output Module | 8 | Analog (Voltage) | 32 x 100 x 115 | 275 |
| BMXNOE0100 | Ethernet Communication Module | N/A | Communication Only | 32 x 100 x 115 | 290 |
Popular Modèles from Schneider Electric (Same Marque)
| Modèle | Product Type | Features | Dimensions (mm) | Poids (g) |
|---|---|---|---|---|
| TM241CE40T | Modicon M241 PLC | 40 I/O, Ethernet, CANopen | 125 x 100 x 85 | 600 |
| ATV320U15M3C | Altivar Machine Drive | Variable speed drive, 1.5 kW, 3-phase | 72 x 143 x 153 | 1200 |
| HMIGTO5310 | HMI Terminal | 10.4″ touchscreen, Ethernet, USB | 260 x 200 x 60 | 1500 |
| BMXCPS2000 | Modicon Power Supply Module | 24 VDC input, 20 W output | 32 x 100 x 115 | 300 |
| XB5AS844 | Emergency Stop Pushbutton | Twist release, 22 mm | 44 x 44 x 45 | 100 |
| NSX250F | Compact Circuit Breaker | 250 A, 3-pole, thermal-magnetic | 161 x 140 x 86 | 1800 |
