Présentation du produit
The Schneider Electric BMXAMO0802 is a high-density, analog output module specifically designed for integration into the Modicon M340 programmable automation platform. This module surfers eight analog voltage output channels that are non-isolated, making it suitable for cost-effective applications where channel-to-channel isolation is not a requirement. It is commonly used for signal generation to actuators, drives, and other analog control systems in process and discrete automation industries.
With a 0 to 10 V output range, fast update rate, and 12-bit resolution, the BMXAMO0802 provides a reliable and high-performance analog output solution. It is engineered to deliver precise control in systems requiring simultaneous multi-channel analog outputs without isolation overhead.
Spécifications du produit
| Parameter | Specification |
|---|---|
| Module Type | Analog Output Module (Non-Isolated) |
| Output Channels | 8 Analog Voltage Outputs |
| Output Signal Type | 0 to 10 V (voltage output) |
| Resolution | 12-bit |
| Update Time per Channel | 5 ms |
| Total Output Error | ±0.5% sur full scale |
| Isolation | No isolation between channels or to ground |
| Operating Temperature Range | 0 to 55°C |
| Storage Temperature | -40 to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Backplane Communication | M340 Rack Internal Bus |
| Power Supply | Supplied via rack backplane |
| Mounting Type | DIN Rail / Rack Mount |
| Dimensions (H x W x D) | 93 x 33 x 104 mm |
| Poids | 0.15 kg |
| Certifications | CE, UL, cULus |
| Compliance | RoHS, IEC 61131-2 |
Product Applications
-
Factory Automation: Ideal for applications that control analog devices such as VFDs, actuators, and analog meters.
-
HVAC Systems: Used in controlling dampers, valves, and sensors that operate with voltage signals.
-
Water Treatment Plants: Output control for chemical dosing systems and pump drives.
-
Packaging Machinery: Provides accurate analog signal control for speed and positioning systems.
-
Food and Beverage Processing: Ensures consistent dosing, blending, and flow control.
-
Textile and Paper Industries: Manages analog controls in dyeing, tension regulation, and speed matching systems.
Product Advantages
-
High Channel Density: Offers 8 output channels in a single module, optimizing space usage in control panels.
-
Cost-Effective Design: Non-isolated structure reduces cost while maintaining reliable performance.
-
Excellent Signal Fidelity: 12-bit resolution ensures smooth and accurate analog control.
-
Fast Response Time: Quick output update rate sur 5 ms enables responsive control in dynamic systems.
-
Ease sur Integration: Seamless connection with the Modicon M340 PLC series and centralized configuration through Unitéy Pro or EcoStruxure Control Expert.
-
Compact Form Factor: Slim design allows easy mounting and optimal space utilization.
-
Field-Proven Reliability: Schneider’s stringent manufacturing standards and wide operational temperature range ensure durability in industrial environments.
-
Energy Efficient: Draws low power from the rack, reducing overall system power consumption.
-
Easy Maintenance: Diagnostic features accessible via the PLC system help reduce downtime.
-
Global Compliance: Adheres to international standards for safety and environmental regulations.
Questions fréquentes (FAQ)
-
Q: How many analog outputs does the BMXAMO0802 provide?
A: It provides 8 analog voltage output channels. -
Q: What is the signal range sur each output channel?
A: Each channel provides a 0 to 10 V analog signal. -
Q: Are the output channels isolated from each other?
A: No, the outputs are non-isolated. They share a common ground. -
Q: What resolution does the module support?
A: The module supports a 12-bit resolution. -
Q: Can the module be used in high-noise environments?
A: It can be used in industrial environments, but for applications requiring isolation, an isolated module is recommended. -
Q: Which PLC platform is the BMXAMO0802 compatible with?
A: It is designed specifically for the Schneider Modicon M340 platform. -
Q: What tools are used to configure the module?
A: Configuration is typically done through EcoStruxure Control Expert (formerly Unitéy Pro). -
Q: Does this module support current output?
A: No, it only supports voltage outputs. -
Q: What is the physical size sur the module?
A: Its dimensions are 93 x 33 x 104 mm. -
Q: What is the typical weight sur the module?
A: It weighs 0.15 kg.
Recommended Modèles from the Same Series or Related
| Modèle Number | Description | Output Type | Channels | Isolation | Dimensions (mm) | Poids (g) |
|---|---|---|---|---|---|---|
| BMXAMO0400 | Analog Output Module (Isolated) | Voltage | 4 | Yes | 130 x 35 x 118 | 200 |
| BMXAMO0410 | High-Level Analog Voltage Output (Isolated) | Voltage | 4 | Yes | 130 x 35 x 118 | 200 |
| BMXAMO0420 | Analog Output Module (Current, Isolated) | Current | 4 | Yes | 130 x 35 x 118 | 210 |
| BMXAMO0415 | High-Accuracy Voltage Output (Isolated) | Voltage | 4 | Yes | 130 x 35 x 118 | 210 |
| BMXAMO0430 | Analog Output Module (0-20mA) | Current | 4 | Yes | 130 x 35 x 118 | 210 |
| BMXAMI0800 | Analog Input Module (Non-Isolated) | Voltage | 8 | No | 130 x 54 x 118 | 240 |
Popular Schneider Analog I/O Modules
| Modèle Number | Description | Type | Channels | Output/Input | Dimensions (mm) | Poids (g) |
|---|---|---|---|---|---|---|
| BMXAMO0802 | Analog Output Module (Non-Isolated) | Output | 8 | Voltage | 130 x 54 x 118 | 240 |
| BMXAMI0810 | Analog Input Module (High-Level) | Input | 8 | Voltage | 130 x 54 x 118 | 240 |
| BMXAMO0420 | Analog Output Module (Isolated Current) | Output | 4 | Current | 130 x 35 x 118 | 210 |
| BMXAMI0410 | Analog Input Module (Isolated) | Input | 4 | Voltage | 130 x 35 x 118 | 200 |
| BMXDDI1602 | Discrete Input Module | Digital Input | 16 | – | 130 x 35 x 118 | 180 |
| BMXDAO1605 | Discrete Output Module | Digital Output | 16 | – | 130 x 35 x 118 | 180 |
