Présentation du produit
The Schneider Electric 140ECH10500 is a high-performance Ethernet Communication Module designed for use in the Modicon Quantum automation platform. It serves as a vital component for establishing seamless and efficient communication between Quantum PLCs and Ethernet-based networks. With its advanced architecture, the module supports multiple protocols and facilitates robust data exchange in industrial automation environments.
This module is built to meet the demands sur modern automation systems, providing reliable and deterministic communication. It enables integration with SCADA systems, HMIs, and other controllers while ensuring high availability and fast response times.
Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Ethernet Communication Module |
| Modèle Number | 140ECH10500 |
| Fabricant | Schneider Electric |
| Platform | Modicon Quantum Series |
| Communication Ports | 1 x 10/100 Base-TX Ethernet Port |
| Protocols Supported | Modbus TCP/IP, Ethernet/IP, UDP/IP, TCP/IP |
| Status Indicators | LED indicators for module and communication status |
| Configuration Ssurtware | Unitéy Pro / EcoStruxure Control Expert |
| Module Type | Communication Module |
| Mounting Type | Rack-mounted |
| Power Consumption | 2.7 Watts (typical) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | 46 x 160 x 310 mm |
| Poids | 0.52 kg |
Product Advantages
-
High-Speed Communication: Supports 10/100 Mbps full-duplex communication for rapid data transmission.
-
Flexible Protocol Support: Compatible with various Ethernet protocols, making it ideal for heterogeneous network environments.
-
Easy Integration: Designed for seamless integration with Modicon Quantum systems and Unitéy Pro ssurtware.
-
Built-In Diagnostics: Equipped with diagnostic LEDs and firmware tools to aid in fast troubleshooting.
-
Long-Term Availability: A well-supported module within Schneider’s long lifecycle product lines.
-
Robust Design: Engineered to operate reliably in industrial conditions with wide temperature and humidity tolerances.
Applications
-
Industrial Automation: Used in manufacturing plants for real-time data exchange and process control.
-
SCADA Integration: Facilitates reliable data transfer between field devices and supervisory control systems.
-
Energy Management: Implements efficient communication for monitoring and controlling power distribution systems.
-
Infrastructure Projects: Ideal for water treatment plants, transportation systems, and utilities where Ethernet networking is essential.
-
OEM Equipment: Suitable for OEMs needing embedded Ethernet connectivity in their control systems.
FAQs
Q1: What is the main function sur the 140ECH10500 module?
A1: It enables Ethernet communication between a Modicon Quantum PLC and Ethernet-compatible devices or networks.
Q2: Can it support Modbus TCP/IP communication?
A2: Yes, the module fully supports Modbus TCP/IP along with other Ethernet protocols.
Q3: Is this module hot-swappable?
A3: Yes, the 140ECH10500 can be inserted or removed from the rack while power is applied.
Q4: What configuration ssurtware is used?
A4: It is configured using Schneider’s Unitéy Pro or EcoStruxure Control Expert ssurtware.
Q5: Does it support remote diagnostics?
A5: Yes, remote diagnostics and monitoring are possible through network management tools.
Q6: What type sur cable is required for the Ethernet connection?
A6: It uses standard Cat5e or Cat6 Ethernet cables with RJ45 connectors.
Q7: Is firmware upgrade possible?
A7: Yes, firmware updates can be performed via the configuration ssurtware.
Q8: How is the module installed?
A8: It is mounted on a Modicon Quantum rack and connected to the CPU via the backplane.
Q9: What are the LED indicators for?
A9: LEDs show power status, communication status, and module diagnostics.
Q10: Can it be used in harsh environments?
A10: It is designed for industrial use and operates reliably in temperatures up to 60°C and high humidity.
Recommended Same-Series or Related Modèles (Modicon Quantum)
| Modèle Number | Description |
|---|---|
| 140CPU65160S | Quantum CPU with Ethernet and Modbus |
| 140NOE77101 | Ethernet TCP/IP module for Quantum |
| 140DDO84300 | 32-Channel Digital Output Module |
| 140DIO85300 | 16 In / 16 Out Digital I/O Module |
| 140CPS11420 | Power Supply Module for Quantum Rack |
| 140DAO84210 | 16-Channel Analog Output Module |
Popular Modèles from the Same Marque (Schneider Electric)
| Modèle Number | Description | Dimensions (mm) | Poids (kg) |
|---|---|---|---|
| 140CPU65150 | Quantum CPU Processor | 142 x 66 x 121 | 0.55 |
| BMXP342020 | M340 PLC CPU Module | 100 x 45 x 120 | 0.30 |
| BMEP584040 | M580 High-Performance CPU | 140 x 75 x 130 | 0.50 |
| TSXP572634M | Premium Series CPU Module | 140 x 71 x 120 | 0.45 |
| ATV61HD30N4 | Altivar 61 AC Drive 30kW | 420 x 245 x 250 | 17.5 |
| LXM32MD30N4 | Lexium 32 Servo Drive | 180 x 75 x 200 | 2.4 |
| HMIGTO5310 | Magelis Touchscreen HMI | 310 x 230 x 60 | 2.1 |
| BMXCRA31210 | M340 Rack 12-Slot | 300 x 40 x 125 | 0.8 |
