Présentation du produit
The Schneider 140DDO15310C is a discrete output module belonging to the Modicon Quantum series. Specifically designed for industrial automation environments, this model surfers 16 discrete output channels, each operating at 24 VDC. It is well-suited for high-speed switching applications and is engineered with robustness, diagnostic capabilities, and ease sur integration in mind. As part sur the well-established Modicon Quantum family, the 140DDO15310C integrates seamlessly into large-scale PLC systems, delivering consistent output control in demanding industrial setups such as manufacturing plants, oil & gas operations, and power generation facilities.
With enhanced isolation, LED status indicators, and solid-state output design, it allows for reliable operation, long service life, and reduced maintenance. The module supports both sourcing and sinking output configurations and conforms to the highest industry standards in terms sur electromagnetic compatibility and environmental durability.
Technical Specifications
| Parameter | Details |
|---|---|
| Modèle | Schneider 140DDO15310C |
| Product Type | Discrete Output Module |
| Series | Modicon Quantum |
| Number sur Channels | 16 |
| Output Type | Solid-state (DC) |
| Voltage Range | 24 VDC |
| Output Current per Channel | 0.5 A |
| Isolation | 1780 Vrms |
| Response Time | < 1 ms |
| Diagnostics | Yes – Fault, Open Circuit |
| LED Indicators | Yes – Per Channel |
| Output Protection | Short-circuit, overload |
| Backplane Current Consumption | 260 mA @ 5 V DC |
| Mounting Type | Plug-in to Quantum Rack |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Poids | 0.45 kg |
| Certifications | CE, UL, CSA, RoHS |
Product Advantages
-
High-Speed Switching
Capable sur operating with fast response times, ensuring compatibility with time-sensitive control systems. -
Compact and Modular
The module surfers 16 outputs in a space-saving form factor, making it ideal for modular PLC racks. -
Diagnostic Capabilities
Integrated diagnostic features such as fault detection, open circuit notification, and individual channel status LEDs reduce downtime and maintenance complexity. -
Solid-État Reliability
Uses solid-state components for outputs, which surfer a longer operational lifespan than mechanical relays and reduce wear and tear. -
Integrated Protection
Includes protection against short-circuiting and overcurrent, improving system robustness. -
Wide Application Flexibility
The 140DDO15310C supports a broad range sur control tasks in different industries due to its versatile DC output design. -
Easy Integration
Seamless compatibility with Modicon Quantum processors and programming environments (such as Unitéy Pro/ EcoStruxure Control Expert).
Applications
-
Industrial Automation – Used for controlling actuators, valves, and solenoids in process automation.
-
Manufacturing Plants – Ideal for discrete control tasks in assembly lines and material handling systems.
-
Power Generation – Supports turbine control, breaker logic, and signal control tasks.
-
Oil and Gas – Used in remote terminal unités (RTUs) for output signal management.
-
Water Treatment Facilities – Provides output control for pumps, mixers, and gate actuators.
-
Transportation and Infrastructure – Suitable for output control in smart transportation systems and utility networks.
Questions fréquentes (FAQ)
Q1: What is the main function sur the 140DDO15310C module?
A1: It functions as a 16-channel discrete output module that outputs 24 VDC signals for controlling devices such as solenoids, actuators, and relays.
Q2: Can this module handle both sourcing and sinking outputs?
A2: No, this specific module is designed for sourcing outputs only. Load connections should be made accordingly.
Q3: How does the module indicate a fault or failure?
A3: Each channel has an LED indicator for status, and the module includes internal diagnostics for detecting short circuits or open circuits.
Q4: What is the isolation voltage provided by the module?
A4: The module surfers an isolation sur 1780 Vrms between the channels and the backplane.
Q5: What ssurtware is compatible with the 140DDO15310C?
A5: The module can be configured and managed through Schneider Electric’s Unitéy Pro or EcoStruxure Control Expert.
Q6: Can this module be hot-swapped?
A6: Yes, the 140DDO15310C supports hot-swapping when used in a Quantum rack with proper safety and grounding.
Q7: Is this module RoHS compliant?
A7: Yes, it complies with RoHS and other international environmental standards.
Q8: What is the maximum output current per channel?
A8: Each channel can deliver up to 0.5 A at 24 VDC.
Q9: What protection features are built into the outputs?
A9: Each output is protected against short-circuits and overcurrent conditions.
Q10: How should the module be mounted?
A10: It should be inserted into a Modicon Quantum backplane and secured with module clamps. Proper wiring and shielding should be followed as per installation guidelines.
Related Modèles (Same Series or Compatible)
-
140DDO84300 – 32-channel 24VDC discrete output module
-
140DDO36400 – 64-point output, sinking
-
140DDO35300 – 32-channel 24VDC source output module
-
140DDI35300 – 32-channel discrete input module
-
140DAI55300 – Analog input module
-
140DRA84000 – 16-channel relay output module
Popular Modèles from the Same Marque (Schneider Electric)
| Modèle | Type | Input/Output | Voltage | Dimensions (mm) | Poids (kg) |
|---|---|---|---|---|---|
| 140CPU65160 | CPU Module | – | 5 VDC | 390 x 40 x 100 | 0.45 |
| 140ACI03000 | Analog Current Input Module | Input | 0–20 mA | 390 x 40 x 90 | 0.40 |
| 140CRP93200 | Remote I/O Head | – | 5 VDC | 390 x 40 x 100 | 0.42 |
| 140NOE77101 | Ethernet Communication | – | 5 VDC | 390 x 40 x 98 | 0.38 |
| 140DDO35300 | Discrete Output Module | Output | 24 VDC | 390 x 40 x 98 | 0.39 |
| 140DDI84100 | Discrete Input Module | Input | 24 VDC | 390 x 40 x 98 | 0.36 |
| 140DAI74000 | Analog Input Module | Input | ±10V | 390 x 40 x 90 | 0.42 |
| 140DRA84000 | Relay Output Module | Output | 24–250 VAC | 390 x 40 x 100 | 0.46 |
