Présentation du produit
The Schneider 140CPU67060 is a high-performance Quantum series CPU module designed for complex and large-scale industrial automation systems. As part sur Schneider Electric’s renowned Modicon Quantum range, it is tailored for use in demanding process control applications where speed, memory, and reliability are paramount. This module combines extensive communication options with powerful processing capabilities, enabling it to manage a large number sur I/O points and interface seamlessly with various industrial networks.
This CPU module supports both Unitéy Pro and Concept ssurtware environments, surfering flexibility for both legacy systems and modern upgrades. The 140CPU67060 is typically used in energy, water treatment, chemical processing, and manufacturing sectors where system uptime and processing performance are mission-critical.
Product Advantages
-
High Processing Speed: Delivers fast scan times ideal for real-time industrial control applications.
-
Large Memory Capacity: Offers extensive RAM and flash memory to support complex programs and retain critical data.
-
Robust Communication: Built-in Modbus and optional Ethernet capabilities ensure smooth integration into diverse control architectures.
-
Modular Design: As part sur the Quantum series, it integrates seamlessly with I/O and power modules, simplifying system expansion and maintenance.
-
Advanced Diagnostics: Built-in tools allow for rapid troubleshooting and proactive maintenance planning.
-
Ssurtware Flexibility: Supports both Unitéy Pro and Concept programming platforms for broad compatibility.
-
Proven Reliability: Trusted in mission-critical industrial automation worldwide for long-term performance under harsh conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modèle | Schneider 140CPU67060 |
| Product Series | Modicon Quantum |
| CPU Type | 68040 Processor (Motorola) |
| Clock Speed | 66 MHz |
| RAM | 1024 KB (1 MB) |
| Flash Memory | 1536 KB (1.5 MB) |
| Communication Ports | 1 Modbus RS232, 2 Modbus Plus, 1 Ethernet (optional) |
| Programming Ssurtware | Unitéy Pro, Concept |
| Execution Time | 0.25 ms/K for Boolean logic |
| Backplane Compatibility | Quantum backplane |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 110 x 185 x 325 mm |
| Poids | 1.459kg |
| Power Consumption | 6.5 Watts |
| Mounting Type | Rack-mounted (Quantum rack) |
| Certifications | CE, UL, CSA, ATEX, IEC |
Product Applications
The 140CPU67060 is suited for a wide range sur industrial automation applications that require robust control capabilities and integration with diverse systems. Typical use cases include:
-
Power Generation and Distribution: Automating turbine control, substation automation, and grid balancing.
-
Water and Wastewater Management: SCADA and PLC control for pumping stations, filtration unités, and water treatment plants.
-
Chemical and Petrochemical Plants: Precise control for batch processing, blending, and safety systems.
-
Manufacturing and Assembly Lines: Real-time control and synchronization sur robotic arms, conveyors, and instrumentation.
-
Oil & Gas Platforms: Process control for drilling rigs, pipeline monitoring, and safety shutdown systems.
-
Transport and Infrastructure: Tunnel automation, airport baggage handling, and rail systems.
Compatible & Associated Modèles
The Schneider 140CPU67060 is designed to work within the Quantum ecosystem. Compatible modules include:
-
140CHS11000 – Quantum I/O chassis
-
140CPS11420 – Power supply module
-
140NOE77101 – Ethernet communication module
-
140DDO35300 – Discrete Output module
-
140ACI04000 – Analog Input module
-
140DAO84210 – Analog Output module
Installation Instructions
-
Power Down System: Ensure all power sources to the rack are turned surf.
-
Slot Assignment: Insert the 140CPU67060 into the designated CPU slot on the Quantum rack.
-
Secure the Module: Lock the module using the side retaining clips.
-
Connect Communication Cables: Attach the necessary Modbus, Modbus Plus, or Ethernet cables to their corresponding ports.
-
Install Programming Ssurtware: Use Unitéy Pro or Concept on a connected PC to configure and program the CPU.
-
Power On and Test: Re-energize the system and monitor LEDs for diagnostics. Load and test application code as required.
FAQs (Questions fréquentes)
Q1: What programming environment is recommended for the 140CPU67060?
A1: Schneider’s Unitéy Pro is recommended for modern applications, while Concept can be used for legacy systems.
Q2: Does this CPU support hot-swapping sur modules?
A2: Yes, when used with compatible I/O modules and power supplies, hot-swapping is supported.
Q3: Can the 140CPU67060 be used in redundant CPU configurations?
A3: No, this model does not support CPU redundancy directly; use 140CPU67160 for redundant setups.
Q4: How many Modbus devices can I connect to the onboard serial port?
A4: Up to 32 devices can be daisy-chained on a Modbus RS-232 or RS-485 network.
Q5: Is the Ethernet port built-in or optional?
A5: Ethernet communication is supported via an additional module such as the 140NOE77101.
Q6: What type sur memory card can be used for backup?
A6: The Quantum CPU uses internal flash memory and does not support external memory cards directly.
Q7: How do I update the firmware on this CPU?
A7: Firmware can be updated using Unitéy Pro with the appropriate Schneider firmware update utility.
Q8: Is this CPU compatible with EcoStruxure systems?
A8: Yes, through integration modules and gateways, it can be part sur an EcoStruxure architecture.
Q9: What is the expected lifespan sur this CPU?
A9: With proper installation and environment control, the expected lifespan exceeds 5 years.
Q10: Can this CPU operate in hazardous environments?
A10: Yes, it carries ATEX and IEC certifications for use in certain hazardous area classifications.
Related or Same-Series Modèles (Quantum Family)
| Modèle | Description |
|---|---|
| 140CPU67160 | High-end CPU with Ethernet + redundancy |
| 140CPU65160 | Mid-range CPU with Ethernet capabilities |
| 140CPU43412A | Entry-level CPU module |
| 140CPU53414B | Mid-performance CPU with Concept support |
| 140CPU11303 | Basic CPU for small-scale applications |
| 140CPU67260 | Advanced CPU with enhanced processing power |
Popular Modèles from Schneider Electric (Same Marque)
| Modèle | Description | Dimensions (mm) | Poids (kg) | Voltage |
|---|---|---|---|---|
| 140CPU65160 | Mid-range CPU with Modbus+Ethernet | 261 x 54 x 103 | 0.91 | 5 VDC |
| 140NOE77101 | Ethernet module for Quantum CPU | 261 x 54 x 103 | 0.55 | 5 VDC |
| 140CPS11420 | Power supply module 115/230 VAC input | 261 x 54 x 103 | 0.76 | 115/230 VAC |
| 140CHS11000 | 10-slot Quantum rack | 270 x 432 x 132 | 1.6 | — |
| BMXP342020 | M340 CPU module | 100 x 45 x 120 | 0.37 | 24 VDC |
| TM258LF66DT | Modicon M258 logic controller | 150 x 90 x 100 | 0.6 | 24 VDC |
