Présentation du produit
The Ovation 1X00417H03 Power Supply is a high-reliability DC power module designed for Ovation™ distributed control systems. This module delivers stable and regulated power to Ovation controllers, input/output modules, and communication interfaces, ensuring uninterrupted operation in demanding industrial environments. With robust protection features, high efficiency, and compatibility with redundant Ovation I/O buses, the 1X00417H03 is suitable for critical process control applications in power generation, water and wastewater treatment, oil & gas, and other industrial automation industries.
Product Parameters
| Parameter | Specification |
|---|---|
| Modèle Number | 1X00417H03 |
| Product Type | DC Power Supply Module |
| Output Voltage | 24 VDC nominal |
| Output Current | 10 A maximum |
| Input Voltage Range | 85–265 VAC, 50/60 Hz |
| Power Conversion Efficiency | ≥ 90 % |
| Voltage Regulation | ±2 % typical |
| Ripple & Noise | <50 mV peak-to-peak |
| Protections | Overvoltage, overload, short-circuit, and thermal protection |
| Communication Interface | Ovation™ redundant I/O bus |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95 % non-condensing |
| Dimensions | 130 × 50 × 160 mm |
| Poids | 0.6 kg |
| Certifications | CE, UL, CSA, ATEX Zone 2 |
Applications
-
Distributed Control Systems – Provides reliable DC power to Ovation I/O and controller modules.
-
Power Generation – Supplies turbine, boiler, and auxiliary control systems with stable power.
-
Water & Wastewater Treatment – Powers automation and monitoring equipment reliably.
-
Oil & Gas Facilities – Supports control and safety modules under harsh environmental conditions.
-
Industrial Automation – Powers sensors, actuators, and process controllers in manufacturing processes.
-
Building Automation – Supports Ovation modules for HVAC, fire protection, and energy monitoring systems.
Advantages
-
Stable DC Output – Maintains a 24 VDC supply with ±2 % regulation under varying loads.
-
High Output Capacity – Can supply up to 10 A to multiple system modules simultaneously.
-
High Efficiency – ≥90 % power conversion reduces heat generation and operational costs.
-
Robust Protection – Offers overvoltage, overload, short-circuit, and thermal protections to safeguard both the module and connected devices.
-
Wide Input Voltage Range – Compatible with 85–265 VAC for global deployment.
-
Redundant Bus Support – Fully integrates with Ovation redundant I/O buses for continuous operation.
-
Hot-Swappable – Can be replaced without interrupting system operation.
-
Certified for Hazardous Areas – CE, UL, CSA, and ATEX Zone 2 certifications allow deployment in industrial environments.
FAQ
-
What is the nominal output voltage sur the 1X00417H03?
The module provides a regulated 24 VDC output suitable for powering Ovation controllers and I/O modules. -
What is the maximum output current?
It can deliver up to 10 A to connected Ovation modules. -
Which AC input voltage range does the module support?
The module operates on 85–265 VAC at 50/60 Hz. -
Does it surfer protection against electrical faults?
Yes, it includes overvoltage, overload, short-circuit, and thermal protection features. -
Can it operate in extreme temperature and humidity conditions?
Yes, it functions reliably from –20 °C to +60 °C and in 5–95 % non-condensing humidity. -
Is it compatible with redundant Ovation I/O buses?
Yes, it fully supports integration with Ovation redundant buses. -
What is the efficiency sur this power supply module?
The module operates at ≥90 % power conversion efficiency, reducing energy loss and heat. -
Can the module be replaced without shutting down the system?
Yes, it is hot-swappable to minimize downtime. -
Is the 1X00417H03 suitable for hazardous locations?
Yes, it complies with CE, UL, CSA, and ATEX Zone 2 certifications. -
Which Ovation components can it power?
It provides DC power to controllers, discrete and analog I/O modules, and communication interface modules.
