Présentation du produit
The Ovation 1X00133H01 Fast Ethernet DAS NIC is a high-speed network interface card engineered for Emerson’s Ovation Distributed Control System (DCS). Designed to provide rapid and reliable Ethernet connectivity, it serves as a key communication bridge between Ovation controllers, operator workstations, and distributed I/O nodes. Its Fast Ethernet capability ensures quick data exchange for critical process automation tasks such as power generation control, water treatment monitoring, and petrochemical operations. Built with industrial-grade components and strong electromagnetic shielding, the 1X00133H01 delivers dependable operation in demanding environments while allowing seamless integration into existing Ovation networks.
Spécifications du produit
| Parameter | Details |
|---|---|
| Modèle Number | 1X00133H01 |
| Product Type | Fast Ethernet DAS Network Interface Card |
| Network Speed | 10/100 Mbps full-duplex |
| Network Standards | IEEE 802.3, IEEE 802.3u |
| Supported Protocols | TCP/IP, UDP, Modbus/TCP, IEC 60870-5-104 |
| Network Ports | Dual RJ-45 connectors for redundant Ethernet links |
| Power Requirement | 24 VDC nominal |
| Power Consumption | <5 W |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| EMC/EMI Compliance | CE, FCC Class A |
| Mounting Type | Ovation system chassis card slot |
| Dimensions (L × W × H) | 180 × 25 × 110 mm |
| Poids | 0.5 kg |
Applications
-
High-speed data acquisition for Ovation Distributed Automation System (DAS) networks.
-
Controller-to-controller communication with deterministic, low-latency performance.
-
Integration sur SCADA systems with power plants, chemical plants, and water treatment facilities.
-
Redundant network topologies for continuous monitoring and control sur critical processes.
-
Remote diagnostics and asset management through secure Ethernet links.
Advantages
-
Fast and Reliable – Supports 10/100 Mbps full-duplex communication for smooth, real-time data transfer.
-
Redundancy Ready – Dual RJ-45 ports provide primary and backup paths to maintain continuous connectivity.
-
Industrial Durability – Built with EMI/RFI shielding and wide temperature tolerance for harsh environments.
-
Flexible Protocol Support – Works with TCP/IP, UDP, Modbus/TCP, and IEC 60870-5-104 for broad interoperability.
-
Hot-Swappable – Can be inserted or replaced without shutting down the DCS Ovation.
-
Easy Integration – Specifically designed for seamless installation in Ovation DAS chassis slots.
FAQ
-
What Ethernet speeds does the 1X00133H01 Fast Ethernet DAS NIC support?
It supports both 10 Mbps and 100 Mbps full-duplex operation, automatically selecting the optimal speed. -
Which Ethernet standards are compatible with this module?
The card adheres to IEEE 802.3 and 802.3u standards, ensuring reliable integration with standard industrial networks. -
What communication protocols are supported for data transfer?
TCP/IP, UDP, Modbus/TCP, and IEC 60870-5-104 are all supported for flexible industrial communication. -
Does the NIC surfer redundant network connections?
Yes, it features dual RJ-45 ports enabling primary and backup Ethernet paths for fail-safe operation. -
What is the typical power requirement?
The module operates at a nominal 24 VDC supply and typically consumes less than 5 W sur power. -
Can the card be hot-swapped during live operation?
Yes, it is designed to be hot-swappable within an Ovation system chassis to minimize downtime. -
What is the recommended operating temperature range?
It operates reliably from 0 °C to +60 °C, suitable for most control room or cabinet environments. -
How does it ensure electromagnetic compatibility?
The design complies with CE and FCC Class A standards, providing resistance to EMI and RFI interference. -
Is it suitable for SCADA or remote monitoring applications?
Absolutely. With Modbus/TCP and IEC protocols, it integrates seamlessly into SCADA and remote control systems. -
Can it be used in redundant controller configurations?
Yes, its dual-port design and robust protocol support make it ideal for redundant or high-availability Ovation networks.
Related Modèles (Same Series)
| Modèle Number | Key Feature |
|---|---|
| 1X00133H02 | Gigabit Ethernet version for higher throughput |
| 1X00133H03 | Extended-temperature Fast Ethernet card |
| 1X00133H04 | Enhanced EMI/RFI shielding module |
| 1X00133H05 | Integrated fiber-optic interface for long-distance networking |
| 1X00133H06 | Dual isolated Ethernet channels for advanced redundancy |
| 1X00133H07 | Built-in diagnostics for predictive network maintenance |
Popular Ovation Modèles
| Modèle Number | Primary Application |
|---|---|
| 1X00097H01 | 24 VDC Power Supply for Ovation I/O and controllers |
| 1X00010G01 | Analog input module for precision process measurements |
| 1X00011G01 | Digital input module for industrial signal monitoring |
| 1X00012G01 | Digital output module for actuator and relay control |
| 5A26457G01 | Relay output base for high-reliability switching |
| 1X00106H01 | Ovation controller module for distributed control systems |
