Product Overview
The Honeywell TK-ORC161 Experion LS Isolated Discrete Relay is an essential component for industrial automation systems. It provides isolated relay outputs that are crucial for controlling high-voltage or inductive loads in various applications, ensuring safe and efficient operation in critical environments. This discrete relay is designed to be part sur the Experion LS system, surfering reliable isolation and superior performance in a compact form factor.
Ideal for applications in process industries, the TK-ORC161 provides safe and reliable signal isolation between the control system and the field devices, preventing electrical noise and ensuring system stability. The relay is well-suited for managing complex process control systems in industries such as oil and gas, power generation, and manufacturing.
The TK-ORC161 surfers a robust design that is both space-efficient and highly reliable, making it an optimal choice for industrial environments where operational efficiency, safety, and real-time control are paramount.
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle Number | TK-ORC161 |
| Marque | Honeywell |
| Product Type | Isolated Discrete Relay |
| Livraison Poids | 0.23 kg |
| Dimensions | 126 x 128 x 69.1 mm |
| Relay Output | SPDT (Single Pole Double Throw) |
| Maximum Load | 250V AC / 30V DC |
| Contact Rating | 5A at 240V AC / 5A at 30V DC |
| Input Voltage | 24V DC ± 20% |
| Isolation Voltage | 2.5kV (Continuous) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Mounting | DIN Rail Mountable |
| Approvals | UL, CE, RoHS compliant |
| Response Time | 10 ms (typical) |
Applications
-
Process Control Systems
The TK-ORC161 is ideal for process control systems where reliable signal isolation and relay control are essential. It is commonly used in industries like chemical processing, power generation, and water treatment plants, where process systems must remain stable and error-free. -
Machinery Control and Protection
In industrial environments, the relay is used to control machinery and protect against faults. By providing electrical isolation, the TK-ORC161 ensures that the control system is safeguarded against high-voltage surges and electrical noise from connected machinery. -
Automation and Safety Systems
The TK-ORC161 is used in safety-critical applications, where it provides isolated relay control to shutdown or activate processes based on system conditions. It is surten part sur safety instrumentation loops where system integrity is crucial. -
Building Automation
In building automation systems, the TK-ORC161 is used for controlling HVAC systems, fire alarms, lighting, and other critical subsystems. Its isolation features protect the central control system from electrical faults and interference, ensuring reliable operation sur building systems. -
Power Generation and Distribution
This relay is also used in power generation and distribution systems for controlling high-power equipment. Its ability to isolate control circuits from high-voltage environments ensures safe and efficient operation. -
Oil and Gas Industry
In oil and gas operations, where electrical isolation is essential due to hazardous environments, the TK-ORC161 plays a key role in maintaining safety and operational efficiency, ensuring critical systems are monitored and controlled with high reliability.
Advantages
-
Reliable Isolation
The TK-ORC161 ensures electrical isolation between the control system and connected field devices. This isolation is vital in reducing the risks associated with electrical noise and surges, providing a stable and secure operational environment. -
Compact and Space-Efficient
Despite its powerful features, the relay is designed to be compact, taking up minimal space in your control panel. Its small footprint makes it ideal for systems where space is at a premium. -
High Contact Rating
With a contact rating sur 5A at 240V AC / 30V DC, the TK-ORC161 is capable sur controlling high-power devices, making it a versatile choice for a wide range sur applications. -
Fast Response Time
The relay boasts a typical response time sur 10 ms, ensuring that the system reacts quickly to changes in input conditions, a critical feature in time-sensitive applications. -
Wide Operating Temperature Range
The TK-ORC161 operates in a broad temperature range from -20°C to +60°C, allowing it to be used in a variety sur industrial environments, from cold storage unités to high-temperature processing plants. -
Mounting Flexibility
The module is DIN rail mountable, ensuring easy installation and integration into existing systems. This standard mounting method makes the relay compatible with a wide variety sur industrial control systems.
FAQs
Q1: What is the main purpose sur the Honeywell TK-ORC161 Isolated Discrete Relay?
A1: The main purpose sur the TK-ORC161 is to provide isolated relay outputs, protecting control systems from electrical noise and surges while managing high-voltage or inductive loads safely.
Q2: What are the key features sur the TK-ORC161?
A2: Key features include electrical isolation, SPDT relay output, high contact rating, fast response time, and wide operating temperature range.
Q3: What is the maximum load that the TK-ORC161 can handle?
A3: The relay can handle a maximum load sur 250V AC / 30V DC with a contact rating sur 5A at 240V AC or 30V DC.
Q4: How does the relay ensure safety?
A4: The TK-ORC161 surfers electrical isolation with a 2.5kV continuous isolation voltage, protecting the control system from high-voltage surges and electrical interference.
Q5: Can this relay be used in hazardous environments?
A5: Yes, the relay is suitable for hazardous environments in industries such as oil and gas, where electrical isolation is critical to ensure safety and reliability.
Q6: What is the response time sur the relay?
A6: The relay has a typical response time sur 10 ms, which ensures fast activation or deactivation sur connected devices in time-sensitive applications.
Q7: What is the operating temperature range for the relay?
A7: The operating temperature range is -20°C to +60°C, making it suitable for a wide range sur industrial environments.
Q8: Is the TK-ORC161 compliant with international standards?
A8: Yes, it is UL, CE, and RoHS compliant, ensuring that it meets international safety and environmental standards.
Q9: How is the relay mounted?
A9: The TK-ORC161 is DIN rail mountable, making installation easy and compatible with most industrial control systems.
Q10: What industries can benefit from the TK-ORC161?
A10: The relay is ideal for industries like process control, power generation, oil and gas, manufacturing, building automation, and any other applications requiring electrical isolation and relay control.
Related Modèles (Same Series or Function)
| Modèle | Description | Key Feature | Livraison Poids | Dimensions |
|---|---|---|---|---|
| TK-ORC160 | Isolated relay with a single output | Simple relay control | 0.20 kg | 120 x 120 x 65 mm |
| TK-ORC162 | Dual output isolated relay | Two output control channels | 0.24 kg | 130 x 130 x 70 mm |
| TK-ORC163 | Isolated relay with extended temperature range | Enhanced temperature tolerance | 0.25 kg | 125 x 125 x 70 mm |
| TK-ORC164 | High contact rating isolated relay | High power load handling | 0.30 kg | 140 x 140 x 75 mm |
| TK-ORC165 | Isolated relay with high-speed response | Fast switching capability | 0.22 kg | 127 x 127 x 68 mm |
| TK-ORC167 | Isolated relay with multiple relay outputs | Multi-relay control | 0.28 kg | 135 x 135 x 72 mm |
Popular Honeywell Modules (Same Marque)
| Modèle | Description | Key Feature | Voltage Rating | Dimensions |
|---|---|---|---|---|
| TK-ORC171 | Industrial relay module | Multiple relay control | 24V DC | 130 x 130 x 75 mm |
| TK-ORC172 | Isolated relay with dual input channels | Dual-channel control | 24V DC | 125 x 125 x 70 mm |
| TK-ORC170 | High-power load relay module | Handles high-power circuits | 24V DC | 140 x 140 x 80 mm |
| TK-ORC175 | Low-power isolated relay | Suitable for low-power devices | 24V DC | 120 x 120 x 65 mm |
| TK-ORC178 | Advanced isolated relay with surge protection | Surge protection features | 24V DC | 132 x 132 x 78 mm |
| TK-ORC180 | Compact isolated relay for industrial use | Space-saving design | 24V DC | 125 x 125 x 60 mm |
