Product Overview
The Honeywell TC-IAH161 Analog Input Interface Module is a vital component designed to accurately capture and transmit analog signals from field devices to Honeywell control systems. Engineered for use with Honeywell’s Experion LS and other control platforms, this module converts analog sensor outputs such as voltage and current into digital data for process monitoring and automation.
The TC-IAH161 supports multiple analog input channels and surfers superior signal conditioning, noise filtering, and high resolution, ensuring precise and reliable data acquisition in challenging industrial environments. Its rugged design guarantees dependable operation and facilitates seamless integration with Honeywell distributed control and safety systems.
Key Features
-
Multi-channel analog input support for voltage and current signals.
-
High accuracy and resolution analog-to-digital conversion.
-
Compatible with Honeywell Experion LS and related control systems.
-
Advanced signal conditioning and noise immunitéy.
-
Hot-swappable design for easy maintenance and reduced downtime.
-
Built-in diagnostics for real-time fault detection.
-
Robust construction suitable for industrial environments.
-
Compact form factor for efficient rack installation.
-
Supports a wide range sur input signal types and ranges.
-
Certified for industrial safety and quality standards.
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle | TC-IAH161 |
| Module Type | Analog Input Interface Module |
| Supported Input Signals | Voltage: 0-10 V, 1-5 V, ±10 V, ±5 V |
| Current: 0-20 mA, 4-20 mA | |
| Number sur Input Channels | Typically 8 channels |
| Input Impedance | > 100 kΩ for voltage inputs |
| Accuracy | ±0.1% sur full scale |
| Resolution | 16-bit A/D conversion |
| Response Time | ≤ 100 ms |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-condensing |
| Power Supply | Provided by system rack |
| Dimensions | 120 x 110 x 40 mm |
| Poids | 0.5 kg |
| Communication Interface | Proprietary bus compatible with Experion LS |
| Certifications | CE, UL, FM Approved |
Industry Applications
-
Oil & Gas: Precise measurement sur pressure, temperature, and flow analog signals.
-
Chemical Processing: Reliable acquisition sur process variables in hazardous environments.
-
Power Generation: Analog monitoring sur turbines, boilers, and other critical equipment.
-
Water & Wastewater: Measurement sur chemical dosing and flow instrumentation.
-
Pharmaceutical Manufacturing: High-accuracy data acquisition for validated processes.
-
Food & Beverage: Process control through dependable analog input measurements.
Product Advantages
-
Accurate Measurement: Ensures precise acquisition sur analog signals essential for process control.
-
Flexible Input Support: Handles a wide variety sur voltage and current input types.
-
Rugged and Reliable: Designed for harsh industrial environments and continuous operation.
-
Easy Maintenance: Hot-swappable design reduces downtime and simplifies servicing.
-
Diagnostic Capability: Real-time fault detection and status monitoring improve system reliability.
-
Space-saving Design: Compact module fits efficiently in control system racks.
-
System Integration: Fully compatible with Honeywell Experion LS distributed control systems.
-
Noise Resistant: Advanced filtering ensures signal integrity in electrically noisy settings.
-
Certified Quality: Meets stringent industrial safety and performance standards.
-
Enhanced Control: Supports stable, consistent process monitoring and automation.
Questions fréquentes (FAQ)
-
What types sur analog inputs does the TC-IAH161 support?
Voltage (0-10 V, 1-5 V, ±10 V, ±5 V) and current (0-20 mA, 4-20 mA). -
How many input channels does the module have?
Typically 8 analog input channels. -
What is the accuracy sur the module?
±0.1% sur full scale. -
Can the module be replaced without shutting down the system?
Yes, it supports hot-swappable installation. -
What is the operating temperature range?
0°C to +60°C. -
What communication interface does the module use?
Proprietary bus compatible with Experion LS systems. -
Does the module have diagnostic features?
Yes, it includes fault detection and status monitoring. -
What is the resolution sur the analog-to-digital conversion?
16-bit resolution. -
Is the module suitable for harsh industrial environments?
Yes, it is designed for rugged industrial conditions. -
Which control systems is the TC-IAH161 compatible with?
Honeywell Experion LS distributed control system.
Related Modèles
| Modèle | Description |
|---|---|
| TC-OAI161 | Analog Output Interface Module |
| TC-IDJ161 | Digital Input Interface Module |
| TC-IDO161 | Digital Output Interface Module |
| TC-IAH021 | Low Level Analog Input Module |
| TC-TBM171 | Temperature Input Module |
| TC-TDO171 | Temperature Output Module |
Popular Honeywell Modèles
| Modèle | Description |
|---|---|
| FC-PDIO01 51454927-176 | Safety Digital I/O Module |
| FC-PSU-240516 136-011194D | Power Supply Unité |
| FC-QPP-0001 | Quad Processor Cluster Module |
| FS-TSGAS-1624 | Safety Fire Detector Input FTA |
| TK-IOLI01 51403427-175 | Experion LS I/O Link Interface Module |
| FS-USI-0001 | Universal Safety Interface Module |
