Présentation du produit
The Honeywell MC-TAMT03 51309223-175 Low Level Analog Multiplexer Module is a precision instrument designed to expand the analog input capacity sur Honeywell control systems. This module allows multiple low-level analog signals to be sequentially routed to a single input channel on a data acquisition system, effectively optimizing signal management and reducing wiring complexity.
The MC-TAMT03 is engineered for high-performance industrial environments, ensuring accurate signal switching with minimal crosstalk and noise. It is compatible with Honeywell’s Experion PKS, TDC 3000, and other DCS systems, providing reliable integration into process automation networks. The module supports a wide range sur input types and is particularly suitable for applications requiring precise measurement sur low-level signals, such as thermocouples, millivolt signals, and small current loops.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modèle | MC-TAMT03 51309223-175 |
| Type | Low Level Analog Multiplexer Module |
| Input Channels | 16 channels |
| Input Signal Range | ±50 mV, ±100 mV, 0–20 mA, 4–20 mA |
| Switching Method | Sequential analog multiplexing |
| Accuracy | ±0.1% sur full scale |
| Crosstalk | < 0.05% |
| Isolation | Channel-to-channel: 500 V RMS |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Power Supply | 24 V DC |
| Power Consumption | 6 W typical |
| Response Time | 100 ms typical |
| Diagnostics | Channel health monitoring, open/short detection |
| Mounting | DIN rail or rack-mountable |
| Dimensions (H x W x D) | 130 × 45 × 160 mm |
| Poids | 0.91 kg |
| Communication Interface | Compatible with DCS Honeywell I/O backplane |
Applications
The MC-TAMT03 module is widely used in process automation and industrial measurement applications:
-
Multiplexing multiple low-level analog signals into DCS Honeywell systems.
-
Measurement sur thermocouples and millivolt-range sensors in chemical processing.
-
Routing multiple small current signals for oil and gas monitoring.
-
Integration into power generation systems for analog signal aggregation.
-
Facilitating advanced control strategies by reducing the number sur dedicated input channels.
-
Industrial laboratories and test benches requiring precise low-level analog data acquisition.
Advantages
-
High Accuracy: Maintains precise signal integrity with ±0.1% full-scale accuracy.
-
Low Crosstalk: Crosstalk between channels is less than 0.05%, ensuring clean signal transmission.
-
Versatile Signal Support: Handles ±50 mV, ±100 mV, 0–20 mA, and 4–20 mA signals.
-
Reliable Diagnostics: Provides open/short detection and channel health monitoring for preventive maintenance.
-
Flexible Mounting: DIN rail or rack-mountable design allows easy installation in control panels.
-
Optimized System Integration: Compatible with Honeywell Experion PKS and TDC 3000 systems, simplifying network expansion.
-
Space and Cost Efficient: Reduces the need for multiple input channels, minimizing wiring and hardware costs.
FAQ
-
How many channels does the MC-TAMT03 support?
It supports 16 independent low-level analog input channels. -
What types sur input signals can the module handle?
It handles ±50 mV, ±100 mV, 0–20 mA, and 4–20 mA signals. -
What is the accuracy sur signal multiplexing?
The module maintains ±0.1% sur full-scale accuracy. -
What is the typical crosstalk between channels?
Crosstalk is less than 0.05%, ensuring minimal interference. -
How is channel isolation provided?
Each channel is isolated up to 500 V RMS to prevent signal contamination. -
What is the response time sur the module?
The typical response time for channel switching is 100 ms. -
Does the module provide diagnostic features?
Yes, it includes channel health monitoring and open/short detection. -
Which mounting options are supported?
It can be mounted on a DIN rail or rack, providing flexible installation. -
What power supply does the module require?
The module operates on 24 V DC with typical consumption sur 6 W. -
Which Honeywell systems is the module compatible with?
It is compatible with Honeywell Experion PKS, TDC 3000, and other DCS I/O backplane systems.
Related Modèles
| Modèle | Description | Channels | Input Types |
|---|---|---|---|
| MC-TAMT01 | Low-Level Analog Multiplexer Module | 8 | ±50 mV, ±100 mV, 0–20 mA |
| MC-TAMT02 | Low-Level Analog Multiplexer Module | 12 | ±50 mV, ±100 mV, 4–20 mA |
| MC-TAMT04 | High-Precision Analog Multiplexer Module | 16 | ±50 mV, ±100 mV, 0–20 mA |
| MC-TAMT05 | Thermocouple-focused Analog Multiplexer | 16 | Thermocouple types J, K, T |
| MC-TAMT06 | Redundant Low-Level Analog Multiplexer Module | 16 | ±50 mV, ±100 mV, 4–20 mA |
| MC-TAMT07 | Fast-Switching Low-Level Analog Multiplexer | 16 | ±50 mV, ±100 mV, 0–20 mA |
Popular Honeywell Modèles
| Modèle | Description | Channels | Input Types |
|---|---|---|---|
| UDC3200 | Universal Digital Controller | N/A | Voltage, Current |
| HC900 | Hybrid Controller | N/A | Analog, Digital |
| Experion PKS I/O | Distributed I/O Modules | 8–16 | Current, Voltage, Thermocouple |
| TDC 3000 HART I/O | HART-compatible Input/Output Module | 8 | Current, Voltage |
| SmartLine Transmitters | Pressure/Flow/Temperature Transmitters | N/A | Current, Voltage |
| SCADA I/O Modules | Supervisory Control Input/Output Modules | 8–16 | Analog and Digital |
