Honeywell FS-CPB-0001 – Présentation du produit
The Honeywell FS-CPB-0001 is a precision circuit protection breaker designed for industrial and commercial electrical systems. It provides overcurrent and short-circuit protection in demanding environments, ensuring equipment safety and operational reliability. Built with high-grade materials and engineered for long-term durability, this device is ideal for panel boards, machinery, and power distribution unités.
This breaker is part sur Honeywell’s Circuit Protection Series, known for high interrupting capacity, compact design, and compliance with international safety standards.
Technical Specifications (FS-CPB-0001)
| Parameter | Specification |
|---|---|
| Modèle Number | FS-CPB-0001 |
| Type | Thermal-Magnetic Circuit Breaker |
| Rated Current | 15A (adjustable range: 10A–20A) |
| Voltage Rating | 240V AC / 48V DC |
| Breaking Capacity | 10kA at 240V AC |
| Operating Temperature | -25°C to +70°C |
| Mounting Style | DIN Rail (35mm) |
| Dimensions | 51 x 254 x 114 mm |
| Poids | 0.63 kg |
| Terminal Type | Screw Clamp (6–4 AWG) |
| Protection Class | IP20 (Indoor Use) |
| Certifications | UL 489, CE, RoHS Compliant |
Primary Applications
The FS-CPB-0001 is widely used in:
✔ Industrial Control Panels – Protects motors, PLCs, and servo drives from electrical faults.
✔ HVAC Systems – Safeguards compressors and fan unités from overcurrent damage.
✔ Power Distribution Unités (PDUs) – Ensures stable power flow in data centers.
✔ Renewable Energy Systems – Used in solar/wind power inverters for circuit protection.
✔ Machinery & Automation – Prevents downtime in CNC machines and robotic arms.
✔ Commercial Electrical Installations – Installed in lighting and HVAC control panels.
Key Advantages
✅ High Breaking Capacity – Handles up to 10kA short-circuit currents without failure.
✅ Adjustable Trip Settings – Allows fine-tuning for different load requirements.
✅ Compact & Space-Saving – Fits easily in crowded electrical enclosures.
✅ Durable Construction – Flame-retardant housing resists heat and mechanical stress.
✅ Easy Installation – DIN rail mounting ensures quick setup.
✅ Global Compliance – Meets UL, CE, and RoHS standards for safety.
Questions fréquentes (FAQ)
1. What is the maximum load current for the FS-CPB-0001?
→ 15A continuous, with adjustable trip settings from 10A to 20A.
2. Can this breaker be used in DC circuits?
→ Yes, it supports 48V DC applications (e.g., solar power systems).
3. Is it suitable for outdoor installations?
→ No, it has an IP20 rating and should be used in dry, indoor environments.
4. How does the thermal-magnetic trip mechanism work?
→ Thermal (slow trip for overloads) + Magnetic (instant trip for short circuits).
5. What is the expected lifespan?
→ 50,000+ operations under normal conditions.
6. Does it support remote reset functionality?
→ No, it requires manual reset after tripping.
7. Can multiple breakers be ganged together?
→ Yes, side-by-side DIN rail mounting is possible.
8. What wire size is compatible?
→ 6–4 AWG (screw terminal accepts up to 25mm² conductors).
9. Is there a fault indicator?
→ No, but the trip position is visibly marked.
10. How long is the warranty period?
→ The standard warranty is 1 years, subject to proper usage and conditions.
Recommended Alternative Modèles
Same Series (Circuit Protection Breakers)
| Modèle | Current Rating | Voltage | Key Feature |
|---|---|---|---|
| FS-CPB-0002 | 20A | 240V AC | Higher current capacity |
| FS-CPB-0005 | 10A | 120V AC | Compact, low-prsurile design |
| FS-CPB-0010 | 30A | 480V AC | Heavy-duty industrial use |
| FS-CPB-0015 | 5A | 48V DC | Precision low-current protection |
| FS-CPB-0020 | 50A | 240V AC | High-breaking capacity (15kA) |
| FS-CPB-0030 | 100A | 600V AC | For large power distribution |
Popular Honeywell Modèles (Autres Categories)
| Modèle | Type | Application |
|---|---|---|
| HNT-2000 | Pressure Sensor | HVAC, industrial automation |
| TY-3600 | Thermostat | Building climate control |
| XNX-5000 | Gas Detector | Industrial safety monitoring |
| VX-7000 | Vibration Sensor | Predictive maintenance |
| PX3-9000 | Power Supply | Critical backup systems |
| LX-400 | Limit Switch | Machinery position control |
