Présentation du produit
The Honeywell FS-BLIND-CHAS4HE is a precision-engineered coverplate designed specifically for the 4HE Control Chassis used in Honeywell safety and process automation systems. It serves as a blanking plate for unused module slots, ensuring airflow integrity, system protection, and a clean, prsuressional cabinet finish. This accessory is critical for maintaining chassis balance in both populated and partially populated systems.
Constructed from industrial-grade aluminum and coated for corrosion resistance, the FS-BLIND-CHAS4HE meets stringent Honeywell manufacturing standards, ensuring seamless compatibility with systems like Safety Manager, Experion PKS, and other Fault Tolerant platforms.
Spécifications du produit
| Parameter | Value |
| Product Name | FS-BLIND-CHAS4HE Coverplate |
| Fabricant | Honeywell |
| Material | Aluminum Alloy (Industrial Grade) |
| Surface Finish | Powder-coated, anti-corrosive |
| Compatibility | Honeywell 4HE Control Chassis |
| Mounting Method | Screw-on, tool-less or manual optional |
| Color | Industrial Grey / Black anodized |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W × H × D) | 482.6 x 177.8 x 7.6 mm |
| Poids | 0.45 kg |
| Certifications | RoHS, CE, UL-compliant |
| Environmental Protection | Indoor industrial, IP20 rated |
Product Applications
-
Slot Blanking in Unused Module Bays: Helps maintain air circulation within the Honeywell chassis.
-
EMI/RFI Protection: Reduces electromagnetic interference when modules are absent.
-
System Integrity: Protects internal components from dust or accidental contact.
-
Training/Demo Systems: Used in mock setups to simulate full deployment without full module installation.
-
Temporary or Scalable Installations: Maintains cabinet balance while systems expand over time.
Product Advantages
-
Perfect Fit with Honeywell 4HE Chassis
Manufactured to exact dimensions ensuring seamless installation and removal. -
Enhanced Equipment Protection
Shields sensitive internal components from environmental elements and operator contact. -
Optimized Thermal Management
Preserves the intended airflow design by filling open slots, thus enhancing cooling performance. -
Rugged Industrial Design
Resistant to corrosion, mechanical stress, and chemical exposure in industrial environments. -
Quick Installation
Easy-to-install design that doesn’t require special tools, reducing maintenance time.
Latest News Titles
-
“Honeywell Introduces Modular Accessories for Safety Manager Plus”
-
“Protective Cover Solutions Now Disponible for Legacy and New Chassis Modèles”
-
“Field Deployments sur FS-BLIND-CHAS4HE Surge in Oil & Gas Sectors”
-
“Honeywell Extends Lifecycle sur 4HE Systems with Improved Accessory Kits”
-
“Smart Panel Management with New Coverplate Systems”
Questions fréquentes (FAQ)
-
What is the FS-BLIND-CHAS4HE used for?
It’s used to cover unused slots in a Honeywell 4HE chassis, ensuring protection and proper airflow. -
Is this coverplate compatible with all Honeywell chassis?
It is designed specifically for 4HE control chassis. It may not fit other form factors without modification. -
Does it come with mounting hardware?
Yes, the product includes standard screws or snaps compatible with the chassis. -
Can this be used in outdoor enclosures?
No, it is intended for indoor, panel-mounted environments with IP20 protection. -
Is the FS-BLIND-CHAS4HE heat-resistant?
Yes, it can operate in environments up to 70°C and tolerate storage up to 85°C. -
How many coverplates are needed per chassis?
That depends on how many module slots are unoccupied. Each slot requires one coverplate. -
Does using this plate affect the cooling sur other modules?
It improves system cooling by directing airflow properly, avoiding hot spots. -
Is it reusable during system upgrades?
Absolutely. It can be removed and re-installed without damage. -
Is it painted or anodized?
It typically features a powder-coated or anodized finish for durability. -
Does it require certification for safety audits?
It complies with CE and RoHS requirements but may not require standalone certification.
