Présentation du produit – Honeywell FC-PSU-NI2424 / SPS6061-LF Power Supply
The Honeywell FC-PSU-NI2424, also known by its alternate designation SPS6061-LF, is a high-performance power supply module engineered specifically for industrial control systems. Designed for reliability in critical process environments, this power supply provides stable and regulated 24V DC output power for Honeywell’s control systems, particularly in the Experion PKS and C300 environments.
This power module is suitable for use in redundant configurations to ensure system uptime and enhance overall reliability in process automation. It features advanced protection mechanisms including overvoltage, overload, and thermal shutdown protections. Built with industrial-grade components and rigorous testing, the FC-PSU-NI2424 delivers continuous, fail-safe operation in demanding environments such as oil & gas plants, petrochemical sites, power generation facilities, and manufacturing unités.
Technical Specifications
| Parameter | Value |
|---|---|
| Modèle Number | FC-PSU-NI2424 / SPS6061-LF |
| Fabricant | Honeywell |
| Input Voltage | 100–240V AC (nominal), 50/60Hz |
| Output Voltage | 24V DC |
| Output Current | 5A (nominal), up to 6A (peak) |
| Output Power | 120W (typical) |
| Efficiency | ≥ 85% |
| Overload Protection | Yes (auto-recovery) |
| Short Circuit Protection | Yes (hiccup mode) |
| Overvoltage Protection | Yes |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting Type | DIN Rail Mount |
| Cooling Method | Natural Convection |
| Dimensions (W x H x D) | 95 × 125 × 135 mm |
| Poids | 9.07 kg |
| Certifications | CE, UL, CSA, RoHS compliant |
| Redundancy Capability | Yes (parallel operation supported) |
| Communication | None (Passive PSU) |
Applications
-
Distributed Control Systems (DCS): Specifically designed for Honeywell’s Experion PKS and C300 platforms, where reliable power delivery is crucial.
-
Industrial Automation: Powers field I/O modules, controllers, and signal conditioners in a wide range sur automated facilities.
-
Oil & Gas Industry: Suitable for upstream, midstream, and downstream environments requiring rugged power supply solutions.
-
Power Plants: Provides consistent power to PLCs, SCADA systems, and protective relays in thermal, hydro, and renewable energy sectors.
-
Chemical & Pharmaceutical Industries: Ensures safe operation sur batch processes, mixing, and production lines.
-
Factory Automation: Used in robotics, motion control, and conveyor systems for uninterrupted operations.
Product Advantages
-
High Reliability: Built with industrial-grade components that ensure consistent operation in harsh conditions.
-
Redundant Configuration Support: Enables N+1 power redundancy setups for mission-critical installations.
-
Compact Design: Space-saving DIN rail mounting with natural convection cooling simplifies integration.
-
Advanced Protection Features: Overvoltage, short circuit, and thermal protection mechanisms enhance safety and lifespan.
-
Ease sur Integration: Seamlessly integrates with Honeywell Experion and other automation architectures.
-
Certifications: Complies with international standards ensuring compatibility with global industrial installations.
-
Minimal Maintenance: Robust design reduces the frequency sur replacements and maintenance interventions.
-
Noiseless Operation: Fanless cooling means zero acoustic noise, ideal for noise-sensitive environments.
Questions fréquentes (FAQ)
-
What is the primary use sur the FC-PSU-NI2424?
It powers Honeywell’s control hardware such as I/O modules and controllers in automation environments. -
Is this power supply hot-swappable?
No, it is not hot-swappable. Power should be turned surf before replacement. -
Can this power supply be used with third-party devices?
While optimized for Honeywell systems, it can support any 24V DC industrial device within its power range. -
What safety certifications does this model carry?
It is certified under CE, UL, CSA, and RoHS standards. -
How is this unité mounted?
The FC-PSU-NI2424 is designed for standard DIN rail mounting. -
Does this unité support redundancy configurations?
Yes, it supports parallel redundancy setups for enhanced system reliability. -
What are the maintenance requirements?
Very minimal. Visual inspection and voltage output check during scheduled plant maintenance is usually sufficient. -
Is active cooling required?
No, it is passively cooled using natural convection; no fan is required. -
Can this module work in high-temperature environments?
Yes, it operates reliably in ambient temperatures up to +70°C. -
Is there remote monitoring or diagnostics capability?
No. This unité is a passive power supply without digital communication. Status indicators are limited to local LEDs.
Related Modèles from the Same Series or Functionality
| Modèle | Output Voltage | Output Current | Power Rating | Application Notes |
|---|---|---|---|---|
| FC-PSU-UNI2448 | 24V DC | 10A | 240W | Higher current variant |
| FC-PSU-PAU2412 | 24V DC | 5A | 120W | Compatible with redundant systems |
| SPS6062-LF | 24V DC | 3A | 72W | Compact version for smaller systems |
| FC-PSU-EXT2410 | 24V DC | 4.5A | 108W | External applications with C300 |
| FC-PSU-IS2440 | 24V DC | 8A | 192W | Intrinsically safe zone-rated supply |
| SPS6063-LF | 24V DC | 6A | 144W | Extended temperature range supported |
Popular Honeywell Modèles Across Product Lines
| Modèle | Type | Key Feature | Application |
|---|---|---|---|
| C300 Controller | Process Controller | Supports Redundant I/O, Universal I/O | Honeywell Experion PKS Systems |
| FTA-TBN-SD | Terminal Board | Smart Digital Input Termination | I/O Termination in DCS |
| MU-TDOD12 | Digital Output Module | 12 Channels, Current Sinking Output | Digital Process Control |
| CC-PDOB01 | Digital Output Module | High-speed pulse output | Discrete Control Applications |
| MC-PAIH03 | Analog Input Module | 8-channel, HART Compatible | Pressure/Temperature Measurement |
| FC-TPSU-2430 | Power Supply Unité | 24V DC, High Output | Universal use in Honeywell systems |
