Product Overview
The Honeywell CC-GAIX11 is a high-performance analog input module designed for integration within the Experion Process Knowledge System (PKS). Engineered to handle multiple isolated analog input channels, this module is ideal for acquiring data from a wide range sur field devices such as transmitters and sensors in industrial automation environments.
Manufactured by Honeywell, a global leader in industrial automation, the CC-GAIX11 ensures reliable operation, high accuracy, and seamless integration into existing control systems. Its compact design and robust features make it suitable for applications where space is limited, and performance is critical.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modèle Number | CC-GAIX11 |
| Type | Analog Input Module |
| Number sur Input Channels | 16 |
| Input Signal Range | 4-20 mA, 0-20 mA, 0-10 V, 1-5 V, -10 to +10 V |
| Resolution | 16-bit |
| Accuracy | ±0.1% sur reading |
| Isolation | 250 V AC between hazardous area and safe/power supply circuits |
| Power Supply | 24 V DC |
| Power Consumption | Max. 30 mA |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 0% to 95% RH (non-condensing) |
| Dimensions (W×H×D) | 115 x 130 x 35 mm |
| Poids | 0.28 kg |
| Mounting | DIN rail or panel mount |
| Communication Protocol | RS-485 Modbus RTU |
| Certifications | CE, UL, CSA |
Applications
The CC-GAIX11 module is versatile and can be employed in various industrial sectors. Its primary applications include:
-
Factory Automation: Acquires data from sensors for monitoring and control.
-
Process Control: Measures parameters like temperature, pressure, and flow within industrial processes.
-
Building Automation: Monitors environmental conditions for HVAC systems.
-
Water and Wastewater Treatment: Measures levels, flow rates, and quality parameters.
-
Oil and Gas Industry: Monitors drilling parameters and safety systems.
-
Power Generation: Acquires data from turbines, generators, and related systems.
Advantages
-
High Accuracy: Provides precise measurements with ±0.1% reading accuracy.
-
Robust Isolation: Ensures reliable operation and protection with 250 V AC isolation between hazardous and safe areas.
-
High Resolution: 16-bit resolution for detailed signal acquisition.
-
Versatile Input: Supports standard 4-20 mA, 0-10 V, and other analog signals from various field devices.
-
Seamless Integration: Fully compatible with Honeywell’s Experion PKS, facilitating easy system integration.
-
Durable Design: Built to withstand harsh industrial environments with wide temperature and humidity ranges.
-
Compact Size: Space-saving design suitable for installations with limited space.
-
Certified Quality: Meets international safety and quality standards (CE, UL, CSA).
Questions fréquentes (FAQ)
-
What is the primary function sur the CC-GAIX11 module?
It serves as an analog input module, acquiring signals from various field devices for processing and control. -
How many input channels does the CC-GAIX11 support?
It supports 16 isolated analog input channels. -
What is the resolution sur the module?
The module surfers a 16-bit resolution for precise signal acquisition. -
Is the module compatible with HART protocol?
Yes, it is compatible with Honeywell’s fieldbus protocols, including HART. -
What are the environmental operating conditions?
Operating temperature ranges from -40°C to +85°C, with humidity between 0% and 95% RH (non-condensing). -
How is the module mounted?
It can be mounted on a DIN rail or panel, surfering flexibility in installation. -
What type sur input signals does it accept?
It accepts standard 4-20 mA, 0-10 V, and other analog signals from various field devices. -
Is the module certified for international use?
Yes, it carries CE, UL, and CSA certifications. -
What is the weight and size sur the module?
It weighs 0.28 kg and measures 115 x 130 x 35 mm. -
Can the module be used in hazardous environments?
The module is designed for industrial environments; however, specific hazardous area certifications should be verified based on application requirements.
Related Modèles in the Same Series
| Modèle Number | Description | Channels | Input Type |
|---|---|---|---|
| CC-GAIX21 | Analog Input Module | 16 | Voltage/Current |
| CC-PAIH51 | Analog Input Module with HART | 16 | Current |
| CC-TAIX01 | Analog Input Module | 8 | Voltage/Current |
| CC-PAIH02 | High-Level Analog Input Module | 16 | Voltage/Current |
| CC-PAIN01 | Analog Input Module | 16 | Voltage/Current |
| CC-PAIH01 | Analog Input Module | 16 | Voltage/Current |
Popular Honeywell Modules
| Modèle Number | Description | Function |
|---|---|---|
| CC-PAIH51 | Analog Input Module with HART | 16 ch, 4–20 mA input |
| CC-TAIX01 | Analog Input Module | 8 ch, Voltage/Current |
| CC-PAIH02 | High-Level Analog Input Module | 16 ch, Voltage/Current |
| CC-PAIN01 | Analog Input Module | 16 ch, Voltage/Current |
| CC-PAIH01 | Analog Input Module | 16 ch, Voltage/Current |
| CC-GAIX21 | Analog Input Module | 16 ch, Voltage/Current |
