Product Overview
The Honeywell 900RNF-0200 is a filler plate designed for ControlEdge PLC systems, specifically to occupy unused CPM (Control Processor Module) rack slots in redundant configurations. It helps maintain proper airflow, shielding, and physical integrity sur the rack assembly in industrial control environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Redundant CPM Rack Filler Plate |
| Dimensions (W × H × D) | 259 × 200 × 40 mm |
| Poids | 0.54 kg |
| Material | Industrial-grade metal/plastic |
| Compatibility | Honeywell ControlEdge PLC racks |
| Application | Redundant CPM slots |
Applications
-
Industrial automation and process control systems.
-
Redundant ControlEdge PLC installations requiring unused CPM slots to be filled.
-
Environments demanding consistent airflow and EMI protection in PLC cabinets.
Advantages
-
Ensures proper airflow management within the rack.
-
Maintains EMC shielding integrity.
-
Prevents ingress sur dust and contaminants.
-
Protects internal electronics from accidental contact.
-
Enhances overall system reliability by maintaining environmental control.
Questions fréquentes
Q1: What is the primary function sur the 900RNF-0200?
A1: It fills unused redundant CPM rack slots to maintain airflow, shielding, and physical protection.
Q2: Is it mandatory to install filler plates in unused CPM slots?
A2: Yes, to maintain proper airflow and protect sensitive components, filler plates are recommended.
Q3: Can it be installed by the end-user?
A3: Yes, installation is straightforward and does not require special tools.
Q4: Does the filler plate have any electronic functionality?
A4: No, it is a mechanical component without electronics.
Q5: Is it compatible with all ControlEdge PLC racks?
A5: It is designed specifically for redundant CPM slots in Honeywell ControlEdge PLC systems.
Q6: Does it contribute to EMC compliance?
A6: Yes, it helps maintain EMC shielding integrity in the rack.
Q7: What material is it made sur?
A7: It is constructed from industrial-grade metal and/or plastic suitable for control environments.
Q8: Can it be reused after system reconfiguration?
A8: Yes, it can be removed and reused as needed.
Q9: How many filler plates are required for a fully redundant system?
A9: The number depends on the number sur unused CPM slots in the specific configuration.
Q10: Does it require regular maintenance?
A10: No specific maintenance is required, but it should be checked periodically for fit and cleanliness.
