Présentation du produit
The Honeywell 51403698-100 Single Board History Module is a critical component designed for Honeywell’s TDC 3000 and Experion Process Knowledge Systems (PKS). As a history module, it plays an integral role in capturing, processing, and storing time-based process data from industrial systems. It ensures that plant operators and control engineers have accurate and readily accessible historical records to analyze trends, troubleshoot problems, and support continuous process improvement.
Designed with robust single-board architecture, the 51403698-100 surfers high reliability and long-term operation, which is essential in mission-critical environments such as power plants, chemical refineries, oil & gas facilities, and other process-intensive industries. Its streamlined integration with Honeywell’s Distributed Control Systems (DCS) ensures minimal setup time and superior performance.
Spécifications du produit
| Parameter | Details |
|---|---|
| Product Modèle | 51403698-100 |
| Product Type | Single Board History Module |
| System Compatibility | Honeywell TDC 3000 / Experion PKS |
| Data Storage Type | Time-based Process Data |
| Architecture | Single Board |
| Input Voltage Range | 5V DC (powered via system bus) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity Tolerance | 5% to 95% non-condensing |
| Communication Protocols | Proprietary Honeywell I/O Bus |
| Mounting Type | Rack-mounted (standard backplane slot) |
| Diagnostic Indicators | LED-based system health and activity indicators |
| Mean Time Between Failures | >100,000 hours |
| Dimensions (L x W x H) | 205 x 224 x 35 mm |
| Poids | 0.5 kg |
Product Applications
The 51403698-100 module is widely applied in various industrial sectors where historical data recording and analysis are crucial for operational efficiency and regulatory compliance. Some common use cases include:
-
Chemical and Petrochemical Plants: Tracks long-term process changes for optimization.
-
Power Generation Facilities: Logs system operations for maintenance planning and regulatory reporting.
-
Oil & Gas Processing: Provides robust data archiving for compliance and safety evaluations.
-
Pharmaceutical Manufacturing: Maintains strict process documentation for audits and quality control.
-
Food and Beverage Plants: Tracks temperature, pressure, and batch data for traceability.
-
Water and Wastewater Management: Historical trending sur treatment parameters for process tuning.
Product Advantages
-
High Reliability: Built with industrial-grade components, the module ensures dependable performance over long operational cycles.
-
Seamless Integration: Fully compatible with Honeywell TDC 3000 and Experion PKS systems, minimizing configuration time.
-
Efficient Data Handling: Enables structured and precise time-series data storage essential for analysis and predictive maintenance.
-
Compact Design: Single-board format allows for easy installation and maintenance within a limited footprint.
-
Real-Time Access: Provides operators with fast access to historical data, improving situational awareness and decision-making.
-
Low Maintenance: Minimal moving parts reduce the risk sur mechanical failure and the need for frequent servicing.
-
Support for Regulatory Requirements: Enables comprehensive data tracking to comply with industry standards and government regulations.
Questions fréquentes (FAQ)
-
What is the primary function sur the 51403698-100 module?
It records and manages time-based historical data from industrial control systems. -
Is this module compatible with Experion PKS systems?
Yes, it is fully compatible with both Honeywell TDC 3000 and Experion PKS. -
How is this module powered?
It is powered via the system backplane with a standard 5V DC input. -
Can the module be hot-swapped?
No, it is recommended to power down the system before replacing the module. -
Does it require ssurtware updates?
The module works with system ssurtware updates delivered via the DCS; no separate firmware updates are typically necessary. -
What type sur data does it store?
It stores structured time-series process data such as temperature, pressure, and flow rates. -
How is the data retrieved from this module?
Data is accessed through Honeywell’s system interface tools within the DCS environment. -
Is the module suitable for high-humidity environments?
Yes, it operates in humidity levels from 5% to 95% non-condensing. -
What kind sur diagnostics does it support?
Built-in LED indicators provide operational and fault status at a glance. -
What is the expected lifespan sur this module?
It has an MTBF (Mean Time Between Failures) sur over 100,000 hours, indicating long service life.
Related Modèles from the Same Series
| Modèle Number | Description | Compatibility |
|---|---|---|
| 51403699-100 | Advanced History Module | TDC 3000 / Experion PKS |
| 51403988-150 | Extended History Buffer | TDC 3000 |
| 51403422-150 | Process History Archive Module | Experion Series |
| 51402573-150 | TDC History Interface Module | TDC 3000 |
| 51401642-100 | History Node Interface Board | Experion PKS |
| 51403519-100 | Compact Data Historian Module | Hybrid Systems |
Popular Honeywell Modèles (Same Marque)
| Modèle Number | Description | Function |
|---|---|---|
| CC-TDIL01 | Digital Input Module | Input signal processing |
| CC-TDOB01 | Digital Output Module | Output control |
| FC-TSAI-1620M | Analog Input Module | Sensor data acquisition |
| MU-TD0D12 | Redundant Digital Output Module | Safety-critical output |
| TC-PRR021 | Processor Communication Module | System communication |
| 51401491-100 | Memory Interface Module | System memory expansion |
