Présentation du produit
The HIMA Z7128/6217/C5/ITI Cable Plug is a high-precision, industrial-grade wiring interface tailored for use with HIMA safety and automation control systems. Specifically engineered to integrate seamlessly with HIMA’s F6217 relay module and other compatible hardware, this cable plug ensures safe, reliable, and orderly electrical connections for both digital and analog signals in safety-critical environments.
The Z7128/6217/C5/ITI model is part sur HIMA’s robust Z7000 series, known for its secure connection architecture, compact form factor, and industrial resilience. It surfers durable connection points and field termination options that make installation and maintenance both efficient and cost-effective.
This cable plug is trusted across various industries including oil and gas, petrochemicals, chemical processing, power generation, and other high-risk sectors requiring certified safety system integration.
Spécifications du produit
| Parameter | Details |
|---|---|
| Product Code | Z7128/6217/C5/ITI |
| Fabricant | HIMA |
| Series | Z7000 Cable Plug Series |
| Connector Type | Screw terminal with coded interface |
| Compatible Module | HIMA F6217 (Relay Module) |
| Rated Voltage | 250 V AC/DC |
| Rated Current | 8 A |
| Number sur Terminals | Typically 16 (depends on configuration) |
| Material – Housing | High-grade flame-retardant thermoplastic |
| Material – Contacts | Nickel-plated brass or gold-plated copper alloy |
| Wire Cross-Section | 0.2 mm² – 2.5 mm² (solid and stranded) |
| Wire Connection Type | Screw clamp terminal |
| Color Coding | Yes (for terminal identification) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Ingress Protection | IP20 (when plugged into compatible module) |
| Mounting Type | Front plug-in, DIN rail compatible |
| Shock Resistance | IEC 60068-2-27 |
| Vibration Resistance | IEC 60068-2-6 |
| Certifications | CE, RoHS, ATEX (via system certification) |
| Cable Length | 5 meters |
| Poids | 0.16 kg |
Product Applications
The HIMA Z7128/6217/C5/ITI Cable Plug is engineered for high-reliability applications requiring precise electrical interfacing. Key application areas include:
-
Emergency Shutdown Systems (ESD): Ensures secure signal routing from field sensors to logic solvers.
-
Safety Instrumented Systems (SIS): Used as part sur input/output signal chains in SIL-certified systems.
-
Relay Module Interfacing: Designed specifically for use with HIMA F6217 relay modules, handling relay signal transitions.
-
DCS and PLC Signal Routing: Offers clean signal connection between distributed controllers and terminal blocks.
-
Industrial Automation Panels: Enables dense yet organized wiring layouts with minimal space requirements.
-
Hazardous Environment Integration: Reliable in explosive environments when installed in certified enclosures.
Product Advantages
-
Tailored Compatibility: Optimized for seamless use with HIMA F6217 and other modules in the HIMax/HIQuad system families.
-
Durability Under Load: Built to endure thermal cycling, vibration, and mechanical stress without loss sur performance.
-
Modular & Replaceable: Pluggable design supports fast field replacements, minimizing system downtime.
-
Superior Signal Integrity: Maintains electrical isolation and contact stability across long-term use.
-
Simplified Installation: Clearly marked terminals and coding ensure error-free, quick wiring.
-
Space-Efficient Design: Compact footprint fits high-density wiring environments.
-
Industrial Compliance: Designed in line with international standards for safety and electromagnetic compatibility.
Questions fréquentes (FAQ)
-
What is the primary compatibility sur this cable plug?
It is specifically designed to interface with the HIMA F6217 relay module, though it may also be compatible with similar relay and I/O modules in the HIMA Z7000 series. -
Can I use stranded wires with this plug?
Yes, the screw clamp terminals support both solid and finely stranded wires within the recommended cross-section range. -
Does this plug include integrated coding to prevent miswiring?
Yes, the Z7128/6217/C5/ITI includes mechanical keying and color-coded terminal assignments to minimize wiring errors during installation. -
Is this plug suitable for use in vibration-intensive environments like surfshore platforms?
Absolutely. The plug meets industrial vibration resistance standards and is commonly used in oil & gas rigs and marine installations. -
Can the plug withstand short-term overcurrent without failure?
While designed for 8A nominal current, the plug features robust contacts that can tolerate transient overcurrent events without damage, as long as they remain within design tolerances. -
Does the product support labeling for terminal identification?
Yes, the terminal housing allows for manual labeling or pre-printed identification inserts, aiding in maintenance and troubleshooting. -
What kind sur housing protection is available when installed?
Once mounted to the corresponding relay module, the assembly surfers IP20 protection against accidental contact and dust ingress. -
Are the contacts corrosion-resistant?
Yes, the contacts are made sur corrosion-resistant plated alloys, suitable for chemically aggressive industrial environments. -
Is the plug hot-swappable during live operation?
No, to maintain system integrity and safety, the plug should not be removed or inserted during live operation unless the system supports such functionality and has been safely isolated. -
Can this plug be reused in system upgrades or expansions?
Yes, as long as the mechanical and electrical conditions sur the plug are verified to be within operational tolerances, it can be reused during system modifications.
Recommended Related Modèles (Same Series or Application)
| Modèle | Description | Connector Type | Rated Voltage | Rated Current |
|---|---|---|---|---|
| HIMA Z7128/6217/C3 | Variant plug for F6217, different coding | Screw Terminal | 250V | 8A |
| HIMA Z7128/6216 | For F6216 relay modules | Screw Terminal | 250V | 6A |
| HIMA Z7128/6218 | Plug-in for F6218 digital output modules | Screw Terminal | 250V | 8A |
| HIMA Z7130/6217 | Alternative wiring configuration for F6217 | Push-in Terminal | 250V | 8A |
| HIMA F6217 Relay Module | 8-channel relay output module | N/A | 250V | 8A per channel |
| HIMA Z7126 | General-purpose plug, 12-pin configuration | Screw Terminal | 250V | 6A |
Recommended Popular HIMA Modèles (Across Catégories de produits)
| Modèle | Description | Catégorie | Key Feature | Application |
|---|---|---|---|---|
| HIMA F8650X | CPU Controller for HIMax | Safety Controller | Dual-redundant architecture | SIL 3 safety systems |
| HIMA F8621A | Digital Input Module | I/O Module | 16-channel input | Signal acquisition |
| HIMA F7553 | Analog Input Module | I/O Module | Precision 4–20 mA input | Process measurement systems |
| HIMA F7133 | Analog Output Module | I/O Module | 4–20 mA current output | Actuator control |
| HIMA F6705 | Communication Module | System Communication | Serial and Ethernet support | System networking and diagnostics |
| HIMA F3330 | Power Supply Module | Power Module | High-efficiency DC supply | HIMax/HIMatrix power integration |
