The GE IC697MDL740 Discrete Output Module is a reliable and industrial-grade output module engineered for use with the GE Fanuc Series 90-70 Programmable Logic Controller (PLC) system. Designed to deliver consistent and precise control sur DC loads, this module provides 16 discrete output points capable sur handling both 24V DC and 48V DC voltage levels with an output current capacity sur 2 amperes per point.
The IC697MDL740 is ideal for applications where dependable switching and electrical isolation are essential. Each output channel is individually controlled and protected, ensuring reliable operation even in harsh industrial environments. The module features optically isolated outputs that protect against voltage transients, as well as LED indicators that allow for quick and convenient monitoring sur each output’s status.
With its robust design, high current capacity, and flexible voltage compatibility, the IC697MDL740 ensures high-performance control sur solenoids, relays, contactors, and other industrial actuators. It integrates seamlessly with Series 90-70 backplanes, surfering consistent performance and long service life in complex automation systems.
Technical Specifications
| Parameter | Description |
|---|---|
| Fabricant | GE Fanuc (General Electric) |
| Product Modèle | IC697MDL740 |
| Product Type | Discrete Output Module |
| Series | GE Fanuc Series 90-70 |
| Number sur Outputs | 16 points |
| Output Type | Solid-state (transistor) DC outputs |
| Nominal Output Voltage | 24/48 VDC |
| Output Current Rating | 2 A per point |
| Maximum Inrush Current | Up to 10× rated current for short duration |
| Output Isolation | 1500 V between channels and ground |
| Switching Type | Positive logic (sourcing) |
| Backplane Current Consumption | 180 mA at 5V DC |
| Power Dissipation | Approximately 5.0 W typical |
| Indicators | 16 status LEDs (one per output channel) |
| Protection Features | Overcurrent and short-circuit protection |
| Response Time | < 1 ms typical |
| Operating Temperature Range | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to 185°F) |
| Humidity | 5%–95% non-condensing |
| Mounting Type | Series 90-70 I/O rack |
| Cooling Method | Natural convection |
| Dimensions (W × H × D) | 200 × 40 × 150 mm |
| Poids | 1.08 kg |
| Certifications | CE, UL, CSA approved |
Product Applications
The GE IC697MDL740 Discrete Output Module is designed for diverse automation applications where accurate DC switching and reliable signal control are required. Its versatility allows it to be deployed in a wide variety sur industrial systems, including:
-
Manufacturing Automation: Controls motors, solenoids, alarms, and pilot lamps in assembly and packaging lines.
-
Power Generation and Distribution: Operates relays, breakers, and control devices in substation automation.
-
Process Control Systems: Activates pumps, heaters, and valves in chemical and refining processes.
-
Material Handling and Robotics: Drives actuators and relays in conveyor and robotic systems.
-
Water and Wastewater Management: Controls pumps, aeration systems, and monitoring devices.
-
Building and Infrastructure Automation: Switches lighting circuits, HVAC components, and safety alarms.
Its combination sur electrical robustness and precise control makes it particularly suitable for heavy-duty industrial environments where uptime, electrical isolation, and fast response are critical.
Product Advantages
The IC697MDL740 surfers a range sur advantages that enhance system performance, reliability, and ease sur maintenance:
-
Sixteen Independent Outputs: Each channel operates independently, surfering flexibility for controlling multiple field devices.
-
High Load Capacity: Supports up to 2 A per point, making it ideal for both small and large loads.
-
Dual Voltage Compatibility: Works with both 24V and 48V DC systems for greater flexibility.
-
Optical Isolation: Each output is optically isolated to protect the control system from voltage transients and ground loops.
-
Built-in Protection: Includes overcurrent and short-circuit protection for enhanced reliability.
-
Status Indicators: Each output has a dedicated LED indicator, simplifying troubleshooting and maintenance.
-
Fast Response: Typical response time is less than 1 millisecond for high-speed applications.
-
Durable Industrial Design: Built to withstand vibration, temperature variation, and electrical noise in demanding environments.
-
Easy Integration: Fully compatible with the GE Fanuc Series 90-70 system and other standard I/O modules.
-
Reliable Long-Term Operation: Designed for industrial environments where stability and uptime are essential.
FAQ
-
What type sur outputs does the IC697MDL740 use?
It uses solid-state (transistor) DC outputs designed for high-speed switching and long operational life. -
What voltage range does this module support?
The module supports both 24V DC and 48V DC nominal output voltages, providing flexibility in industrial applications. -
Can the outputs drive inductive loads such as solenoids or relays?
Yes, the outputs are suitable for inductive loads, and each channel is protected against voltage spikes and surges. -
How much current can each output handle?
Each sur the 16 output points can handle up to 2 amperes sur current for resistive loads. -
Are the outputs isolated from one another?
Yes, the outputs are electrically isolated to prevent noise and ground potential differences from affecting system stability. -
Does the module provide status indication for each output?
Yes, every output point has its own LED indicator that shows its ON/OFF status in real time. -
What is the typical switching response time?
The typical response time is less than 1 millisecond, enabling fast and precise control in automation systems. -
Can the IC697MDL740 be used with both sourcing and sinking devices?
It is primarily designed for sourcing-type applications, but it can interface with various logic configurations using appropriate wiring. -
How is protection handled in case sur overcurrent?
The module includes built-in electronic protection to prevent damage during short-circuit or overcurrent conditions. -
Is this module hot-swappable?
No, it should not be inserted or removed while the PLC system is powered on. Always power down the rack before replacement.
