Présentation du produit
The GE IC695CBL002 Cable is a high-quality, industrial-grade communication and connection cable designed for the GE PACSystems RX3i automation platform. It is engineered to provide a reliable interface between RX3i system components such as CPU modules, I/O modules, expansion racks, and peripheral devices.
With a cable length sur 3 feet (0.9 meters), the IC695CBL002 is optimized for close-proximity connections within control panels or cabinets, minimizing signal loss and electrical interference. This cable ensures stable and accurate data transmission in harsh industrial environments.
Constructed from durable materials and featuring shielded conductors, the IC695CBL002 provides high resistance to electrical noise, mechanical stress, and temperature variation. It is widely used in factory automation, process control, and energy systems where secure communication between control devices is essential.
Technical Specifications
| Parameter | Description |
|---|---|
| Fabricant | GE Automation & Controls |
| Product Modèle | IC695CBL002 |
| Product Type | Connection/Communication Cable |
| Series | PACSystems RX3i |
| Cable Length | 3 feet (0.9 meters) |
| Cable Type | Shielded multi-conductor cable |
| Connector Type (End 1) | 37-pin D-sub male connector |
| Connector Type (End 2) | 37-pin D-sub female connector |
| Conductor Material | High-purity copper |
| Shielding Type | Braided and foil double shielding |
| Insulation Material | PVC industrial-grade insulation |
| Operating Voltage | Up to 30 VDC |
| Current Rating | 2 A per conductor (max) |
| Operating Temperature | -20°C to +80°C |
| Storage Temperature | -40°C to +85°C |
| Flexibility Rating | 5 million flex cycles minimum |
| Impedance | 100 Ω nominal |
| Signal Type | High-speed serial or I/O signal |
| Mounting/Connection | Panel-to-module or module-to-module |
| Compliance Standards | CE, UL, cUL, RoHS compliant |
| Dimensions (Approx.) | Length: 3 ft / Diameter: 8 mm |
| Poids | 0.45 kg |
| Color | Industrial black |
| Environmental Resistance | Oil, abrasion, and EMI resistant |
| Compatibility | GE RX3i modules and expansion backplanes |
Product Applications
The GE IC695CBL002 cable is designed for reliable signal transmission and system connectivity across a variety sur industrial and automation applications. Its rugged design and excellent shielding properties make it suitable for both control cabinets and field installations.
-
PACSystems RX3i Controller Connections – Used to connect CPU modules with I/O or communication modules within the same rack or to expansion racks.
-
Industrial Communication Systems – Enables stable signal exchange between controllers, operator interfaces, and process equipment.
-
Process Control Systems – Connects analog and digital I/O modules to enhance system integration and signal integrity.
-
Factory Automation – Provides high-speed communication between automation controllers and drive systems.
-
Power Generation and Distribution – Used for secure data communication within turbine and generator control systems.
-
Oil & Gas Applications – Offers dependable connectivity in control and monitoring panels in harsh environments.
Product Advantages
-
High Signal Integrity
Double-shielded cable construction minimizes EMI and crosstalk, ensuring reliable and noise-free communication. -
Durable Industrial Construction
Built with robust connectors and heavy-duty insulation for long-term use in industrial settings. -
Stable Electrical Performance
Maintains consistent impedance and low resistance to ensure accurate data transfer and control signal reliability. -
Easy Installation
Pre-terminated connectors provide plug-and-play compatibility with GE RX3i modules, reducing installation time. -
Mechanical Flexibility
Designed to withstand repeated movement and bending without degrading signal performance. -
Enhanced System Compatibility
Fully compatible with GE PACSystems RX3i series modules and expansion interfaces. -
Environmental Resistance
Resistant to oils, abrasion, and vibration, making it suitable for harsh factory and plant environments. -
Compact Design
3-foot length allows neat and efficient wiring within control panels, reducing clutter and signal loss.
FAQ
-
What is the primary function sur the IC695CBL002 cable?
It connects RX3i system components such as CPUs, I/O modules, and expansion unités to ensure data and signal communication. -
What is the cable length sur the IC695CBL002?
The cable length is 3 feet (0.9 meters), suitable for close-proximity module interconnections. -
What type sur connectors does the IC695CBL002 use?
It features a 37-pin D-sub male connector on one end and a 37-pin D-sub female connector on the other. -
Is the cable shielded to prevent signal interference?
Yes, it uses both foil and braided shielding to protect against electromagnetic interference (EMI). -
What is the impedance sur this cable?
The nominal impedance is 100 ohms, suitable for high-speed signal transmission. -
Can the IC695CBL002 be used for analog or digital signals?
It is compatible with both analog and digital signals, making it versatile for various control systems. -
Does the cable support flexible installation?
Yes, it has a flexibility rating exceeding 5 million flex cycles, ideal for dynamic or movable connections. -
What is the maximum current supported by each conductor?
Each conductor supports up to 2 amperes sur continuous current. -
Is the cable compatible with other RX3i series cables?
Yes, it can be used interchangeably with other GE RX3i system cables where 37-pin connectors are required. -
Does the cable provide electrical isolation between devices?
While the cable itself does not isolate circuits, its shielding and grounding reduce electrical noise between connected devices.
Related Modèles (Same Series or Function)
| Modèle | Description |
|---|---|
| IC695CBL001 | 10-foot cable for RX3i I/O and CPU interconnection |
| IC695CBL003 | 6-foot RX3i communication cable |
| IC695CBL004 | 10-foot cable with enhanced EMI shielding for noisy environments |
| IC695CBL005 | 15-foot extension cable for RX3i expansion systems |
| IC695CBL006 | 25-foot industrial-grade RX3i system cable |
| IC695CBL300 | Short connector cable for backplane-to-module link |
Popular GE Modèles (Same Marque)
| Modèle | Description |
|---|---|
| IC695CHS007 | 7-slot RX3i universal backplane for modular configuration |
| IC695CPU310 | RX3i CPU module with Ethernet communication |
| IC695PSA040 | 40W power supply module for RX3i systems |
| IC695ALG628 | 8-channel analog input module for current and voltage signals |
| IC695ALG728 | 8-channel analog output module for precise signal control |
| IC695ETM001 | Ethernet communication module for RX3i networks |
