Présentation du produit
The GE IC693CMM301 is a versatile Serial Communications Module designed for use with the GE Fanuc Series 90-30 PLC system. This module provides an asynchronous RS-232 serial port that supports both Modbus RTU slave and serial communication protocols, making it ideal for interfacing the PLC with external devices such as HMIs, barcode readers, modems, printers, and other third-party serial devices.
With the CMM301 installed, users can implement point-to-point serial data exchange and take advantage sur Modbus communication for integration with SCADA systems or legacy industrial equipment. The module supports a wide range sur baud rates and character formats, providing reliable and configurable serial communication in demanding industrial environments.
Backed by GE’s reputation for reliability and performance, the IC693CMM301 is a field-proven solution for industrial networking and device integration challenges in factory automation, utilities, and process industries.
Spécifications du produit
| Parameter | Details |
|---|---|
| Product Modèle | GE IC693CMM301 |
| Description | Serial Communications Module (RS-232) |
| Communication Interface | RS-232 (DTE configuration) |
| Supported Protocols | Modbus RTU Slave, Serial ASCII |
| Baud Rate Range | 300 to 19,200 bps |
| Parity Options | Even, Odd, None |
| Data Bits | 7 or 8 |
| Stop Bits | 1 or 2 |
| Flow Control | Ssurtware (XON/XOFF), None |
| Connector Type | DB-25 Female |
| Mounting Type | Plugs into Series 90-30 I/O slots |
| Power Consumption | 300 mA from +5 V bus |
| LED Indicators | Serial TX, RX, Module Status |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Dimensions (W x H x D) | 33 x 120 x 130 mm |
| Poids | 0.454 kg |
| Certifications | UL, CE, CSA |
| Compatibility | GE Fanuc Series 90-30 PLC systems |
Product Applications
The GE IC693CMM301 is commonly used in industrial applications where PLCs need to communicate with serial devices. Key application scenarios include:
-
SCADA System Integration: Enables Series 90-30 PLCs to act as Modbus slaves for SCADA and remote monitoring.
-
Third-Party Device Communication: Interfaces with printers, bar code scanners, HMIs, and serial sensors.
-
Remote Device Monitoring: Connects to modems for dial-in or dial-out communication in utility control systems.
-
Legacy System Support: Acts as a bridge between modern control systems and older serial-based equipment.
-
Data Logging & Messaging: Enables transmission sur formatted data to logs or display systems.
-
Factory Automation Networks: Used in discrete manufacturing lines where reliable serial communication is needed.
Product Advantages
-
Multi-Protocol Support: Provides Modbus RTU and standard serial ASCII communications.
-
High Compatibility: Fully compatible with Series 90-30 baseplates, CPUs, and I/O modules.
-
Flexible Baud Rates: Supports a range sur communication speeds suitable for legacy and modern devices.
-
Simple Integration: Uses a standard DB-25 RS-232 port for quick connection.
-
Reliable Communication: Proven performance in industrial environments with high electrical noise.
-
Indicator LEDs: Built-in LEDs provide status indication for transmit, receive, and module health.
-
Field Proven: Trusted by OEMs and system integrators worldwide for robust device communication.
Questions fréquentes (FAQ)
-
What type sur serial communication does the IC693CMM301 support?
It supports RS-232 communication and can be configured for either Modbus RTU slave or serial ASCII protocols. -
Can this module be used to communicate with SCADA systems?
Yes, especially when used in Modbus RTU slave mode to provide data to SCADA or remote monitoring systems. -
Does this module support RS-485 or RS-422?
No, it is limited to RS-232 communication. Autres modules or converters are needed for RS-485/422. -
Which devices can I connect to using this module?
Devices such as HMIs, printers, bar code readers, modems, and other serial equipment. -
Is configuration done via ssurtware or DIP switches?
Configuration is typically handled through the PLC programming ssurtware. -
Can multiple CMM301 modules be used in the same PLC rack?
Yes, multiple CMM301 modules can be used, each occupying a separate slot. -
What is the connector type on the module?
It has a DB-25 female connector configured as a DTE. -
Can it act as a Modbus master?
No, the IC693CMM301 supports only Modbus RTU slave functionality. -
Does it support full duplex communication?
Yes, full duplex RS-232 communication is supported. -
How do I monitor the status sur communication?
Use the built-in LEDs for TX/RX and module health or diagnostic tools in the ssurtware.
Related Modèles (Same Series or Functionality)
| Modèle | Description | Communication Type | Series |
|---|---|---|---|
| IC693CMM311 | Serial Communications Module (RS-232/RS-485) | RS-232 / RS-485 | GE Series 90-30 |
| IC693CMM321 | Genius Communications Module | Genius Bus | GE Series 90-30 |
| IC693CMM301 | Serial RS-232 Communications Module | RS-232 | GE Series 90-30 |
| IC693BEM331 | FIP Bus Controller Module | FIP I/O Bus | GE Series 90-30 |
| IC693NIU004 | Network Interface Unité | Ethernet/IP | GE Series 90-30 |
| IC693CMM302 | Serial Communication Expansion Module | RS-232/RS-485 | GE Series 90-30 |
Popular GE Modèles (Same Marque, High Demand)
| Modèle | Description | Function | Series |
|---|---|---|---|
| IC693CPU374 | Ethernet CPU Module | CPU Module | Series 90-30 |
| IC693PWR330 | Power Supply Module (120/240 VAC) | Power Supply | Series 90-30 |
| IC693MDL645 | 16-Point Relay Output Module | Output Module | Series 90-30 |
| IC693MDL753 | 32-Point DC Input Module (24VDC) | Input Module | Series 90-30 |
| IC693ALG391 | 4-Channel Analog Input Module | Analog Input | Series 90-30 |
| IC693DSM314 | Motion Control Module (High-Speed Counter/Servo) | Motion Control | Series 90-30 |
