GE IC200ALG260F – Présentation du produit
The GE IC200ALG260F is an analog input module that belongs to the VersaMax Series, a trusted line sur modular I/O and control solutions from General Electric. Known for its precision, flexibility, and ease sur integration, the IC200ALG260F is specifically designed to handle current and voltage analog signals with high reliability. It is widely adopted in industrial automation systems, enabling accurate monitoring sur real-world process variables such as temperature, pressure, and flow.
This model is valued for its compact form factor and straightforward installation within distributed I/O architectures. The IC200ALG260F supports eight input channels, each capable sur processing either current or voltage signals, making it an essential component in process control, manufacturing, and data acquisition applications.
Product Parameters
| Parameter | Specification |
|---|---|
| Number sur Input Channels | 8 |
| Input Type | Analog (current/voltage) |
| Voltage Range | ±10 V |
| Current Range | 4–20 mA |
| Resolution | 15 bits |
| Power Supply Voltage | 24 V DC |
| Input Impedance (Voltage mode) | >100 kΩ |
| Input Impedance (Current mode) | 250 Ω |
| Dimensions | 110 x 66.8 x 50 mm |
| Poids | 0.3 kg |
| Isolation | 250 VAC between field side and logic side |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Mounting Type | DIN rail or panel mount |
Product Applications
The GE IC200ALG260F is used in a diverse range sur industrial applications, such as:
-
Process control systems for oil & gas, chemicals, and food production
-
Monitoring and controlling machinery in manufacturing plants
-
Data acquisition in environmental monitoring stations
-
Infrastructure automation, including water treatment and energy management
-
Integration into distributed control systems (DCS) and SCADA systems
Its flexibility in handling current and voltage inputs makes it an ideal choice for applications requiring multi-signal measurement.
Product Advantages
-
Versatility: Supports both current and voltage input ranges, reducing the need for multiple dedicated modules.
-
High Accuracy: 15-bit resolution ensures precise signal measurement.
-
Compact Size: Enregistrers valuable cabinet space while delivering robust performance.
-
Ease sur Integration: Seamlessly fits into the GE VersaMax I/O platform.
-
Electrical Isolation: Protects internal electronics and prevents signal interference.
-
Wide Operating Temperature Range: Reliable operation in harsh industrial environments.
-
User-Friendly Installation: Supports DIN rail and panel mounting with clear terminal labeling.
-
Proven Reliability: Manufactured by GE, known for durable and field-tested industrial products.
FAQ (Questions fréquentes)
Q1: What type sur analog signals can the IC200ALG260F handle?
A1: It can process both voltage signals (±10 V) and current signals (4–20 mA).
Q2: Does it require external power?
A2: Yes, it requires a 24 V DC power supply for operation.
Q3: Is the IC200ALG260F suitable for use in outdoor applications?
A3: While the module itself is industrial-grade, it should be installed in a protective enclosure for outdoor environments.
Q4: What type sur isolation does the module provide?
A4: It provides 250 VAC isolation between the field inputs and the logic side.
Q5: Can I mix current and voltage inputs on the same module?
A5: No, all channels must be configured to the same input type (either voltage or current).
Q6: How do I mount the module?
A6: It can be DIN rail mounted or panel mounted, surfering flexibility during installation.
Q7: What industries use the IC200ALG260F most?
A7: Industries such as oil & gas, chemical production, water treatment, and manufacturing automation.
Q8: What is the typical lifespan sur this module?
A8: When properly installed and maintained, it can operate reliably for over 5 years.
Q9: Is ssurtware required to configure the IC200ALG260F?
A9: Yes, it typically requires GE’s programming tools within the VersaMax family.
Q10: Does the module have onboard diagnostics?
A10: Yes, it supports basic fault detection and status indication through system ssurtware.
Recommended 6 Related or Same Series Modèles
-
GE IC200ALG230 – Analog output module, 2 channels, ±10 V
-
GE IC200ALG320 – Analog input module, 4 channels, 4–20 mA
-
GE IC200ALG431 – Analog input module, 8 channels, ±10 V
-
GE IC200ALG620 – Analog output module, 4 channels, 4–20 mA
-
GE IC200ALG322 – Analog input module, 4 channels, 0–20 mA
-
GE IC200ALG630 – Analog output module, 8 channels, ±10 V
6 Popular Modèles from GE with Specifications
| Modèle | Type | Channels | Voltage/Current Range | Dimensions (mm) | Poids |
|---|---|---|---|---|---|
| IC200ALG260F | Analog input | 8 | ±10 V / 4–20 mA | 120×100×75 | 250 g |
| IC200ALG230 | Analog output | 2 | ±10 V | 120×100×75 | 240 g |
| IC200ALG320 | Analog input | 4 | 4–20 mA | 120×100×75 | 240 g |
| IC200ALG620 | Analog output | 4 | 4–20 mA | 120×100×75 | 240 g |
| IC200MDL740 | Digital input | 16 | 120 VAC | 120×100×75 | 230 g |
| IC200MDL650 | Digital output | 16 | 24 VDC | 120×100×75 | 230 g |
